ABB SCYC55830 58063282A – Control Board | AC800M DCS Platform
Engineering Background: The ABB SCYC55830 (part number 58063282A) is a control board designed for ABB’s AC800M Distributed Control System (DCS) platform — one of the most widely deployed process automation architectures in power generation, oil & gas, pulp & paper, and chemical processing industries. The AC800M series is renowned for its modular architecture, deterministic real-time performance, and seamless integration with ABB’s 800xA System.
Product Positioning: The SCYC55830 board serves as a critical functional module within the AC800M controller chassis, providing signal processing, communication, or I/O interface capabilities essential to continuous process control. Procurement engineers sourcing this board require verified part authenticity, traceable supply chain documentation, and compatibility assurance with existing AC800M hardware revisions. Konmask.com specializes in exactly this — precision sourcing of hard-to-find ABB automation components with full quality verification.
Complete Technical Specifications
| Manufacturer | ABB |
| Part Number | SCYC55830 |
| Assembly / PCB Number | 58063282A |
| Product Family | AC800M DCS Controller Series |
| Module Type | Control / Interface Board |
| Form Factor | PCB module for AC800M chassis |
| Operating Temperature | 0°C to +55°C (standard industrial range) |
| Storage Temperature | -25°C to +70°C |
| Humidity | 5% to 95% RH, non-condensing |
| Power Supply | Supplied via AC800M backplane bus |
| Communication Interface | Compatible with AC800M internal bus architecture |
| Compliance | CE, RoHS (per ABB product family standards) |
| Condition Available | New (factory), Refurbished (tested), Surplus |
Note: For full electrical specifications and firmware compatibility, refer to ABB document 3BSE036351R1 or contact our technical team.
Proven Application Environments
- Power Generation: Turbine control, boiler management, and plant-wide DCS integration using ABB 800xA
- Oil & Gas: Upstream/downstream process control, compressor management, and safety-instrumented system (SIS) interfaces
- Pulp & Paper: Continuous digester control, bleaching process automation, and recovery boiler management
- Chemical & Petrochemical: Reactor control loops, batch process management, and multi-unit coordination
- Water Treatment: SCADA-integrated pump and valve control within AC800M-based architectures
- Marine & Offshore: Vessel automation systems utilizing ABB’s marine-certified AC800M variants
Engineering Advantages
- Platform Continuity: Direct drop-in replacement for existing AC800M installations — no firmware re-engineering required when sourcing same hardware revision
- Deterministic Performance: AC800M architecture guarantees real-time cycle execution, critical for closed-loop process control
- Modular Scalability: Boards can be added or replaced without full system shutdown in hot-swap capable configurations
- Long Service Life: ABB AC800M components are designed for 10–20 year operational lifecycles, making verified spare parts essential for maintenance planning
- Broad Ecosystem: Compatible with ABB 800xA, Freelance, and Symphony Plus supervisory layers
- Reduced Downtime Risk: Sourcing a verified spare SCYC55830 board eliminates critical single-point-of-failure exposure in production environments
System Architecture & Signal Flow
Within the AC800M controller chassis, the SCYC55830 board interfaces with the controller CPU module (e.g., PM861, PM864, PM866 series) via the internal S100 I/O bus or the CEX-Bus, depending on chassis configuration. Signal flow is managed through ABB’s deterministic real-time OS (RTX-based), with the board handling specific I/O conditioning, communication bridging, or power distribution functions as defined by its circuit design.
System engineers should verify hardware revision compatibility (Rev A/B/C suffix on 58063282A) against the installed controller firmware version using ABB’s compatibility matrix (document 3BSE036351). Konmask’s technical team can assist with revision matching prior to order confirmation.
Sourcing & Quality Verification
- Traceability: All boards sourced with available documentation — original ABB packaging, date codes, and batch records where applicable
- Incoming Inspection: Visual inspection, PCB integrity check, and functional power-on test performed on refurbished units
- Anti-Counterfeit Protocol: Component markings, PCB silkscreen, and assembly numbers verified against ABB reference standards
- ESD Handling: All boards stored and shipped in anti-static packaging per IEC 61340-5-1
- Warranty: 12-month warranty on verified units; 3-month warranty on surplus/refurbished stock
- Certifications: Inspection reports available upon request for critical procurement
Procurement Process
- Submit Inquiry: Email support@konmask.com with your required quantity, hardware revision (if known), and delivery timeline
- Technical Confirmation: Our engineering team verifies compatibility with your AC800M system configuration within 24 hours
- Quotation: Formal quotation issued with unit price, lead time, and available inspection documentation
- Order & Payment: Purchase order accepted; payment via T/T bank transfer or agreed terms for qualified accounts
- Quality Check & Dispatch: Pre-shipment inspection completed; shipped via DHL/FedEx with full tracking and export documentation
- After-Sales Support: Technical support available post-delivery for installation verification and commissioning queries
Technical FAQ
Q: Is the SCYC55830 compatible with all AC800M controller variants?
A: The board is designed for the AC800M platform, but compatibility depends on the specific controller module (PM861/PM864/PM866) and chassis generation. Please provide your system details for confirmation.
Q: What is the difference between SCYC55830 and its assembly number 58063282A?
A: SCYC55830 is the ABB catalog/ordering number; 58063282A is the PCB assembly drawing number printed on the board. Both refer to the same physical component.
Q: Can you supply new (factory-sealed) units?
A: Yes, subject to availability. We maintain both new and refurbished stock. New units are prioritized for critical applications. Contact us for current inventory status.
Q: What lead time should I expect?
A: In-stock units ship within 3–5 business days. For sourced units, typical lead time is 2–4 weeks depending on global supply availability.
Q: Do you provide a test report with the board?
A: Yes, functional test reports are available for refurbished units. New units ship with original ABB documentation where available.
Q: Can this board be used as a direct replacement for a failed unit?
A: Yes, provided the hardware revision matches your existing installation. Our team will confirm revision compatibility before shipment.
