The ABB 3BHE027632R0101 Main Board is a core controller board deployed in ABB’s AC800M distributed control system (DCS) platform. It is specified by process engineers and control system integrators across the following industries and applications:
- Power Generation: Turbine governor control, boiler management systems (BMS), and plant-wide SCADA integration in coal, gas, and hydroelectric facilities.
- Oil & Gas: Upstream wellhead automation, midstream pipeline SCADA, and downstream refinery process control loops.
- Pulp & Paper / Chemical: Continuous process control requiring high-availability redundant CPU architectures.
- Water & Wastewater: Pump station automation, SCADA telemetry, and treatment plant PLC/DCS hybrid architectures.
- Marine & Offshore: Vessel automation and offshore platform control systems certified to marine standards.
Technical Specifications
| Part Number | 3BHE027632R0101 |
| Manufacturer | ABB Ltd. |
| Product Family | AC800M DCS Platform |
| Module Type | Main Board / CPU Controller Board |
| SKU | 3BHE027632R0101 |
| Weight | 3,200 g (approx.) |
| Communication | MMS / IEC 61850 / Profibus / Modbus (platform-dependent) |
| Operating Temperature | 0 °C to +55 °C (storage: −25 °C to +70 °C) |
| Power Supply | 24 V DC (via backplane) |
| Certifications | CE, UL, cUL (refer to ABB datasheet for full listing) |
| Condition | New / Refurbished / Tested — specify on inquiry |
Note: Full electrical and firmware specifications are available in the ABB AC800M Hardware Manual. Contact us for the applicable datasheet.
Why Engineers Specify This Model
- Platform Continuity: Direct drop-in replacement for existing AC800M installations — no re-engineering of I/O wiring or control logic required.
- High Availability Architecture: Supports redundant CPU configurations for SIL-rated and mission-critical process loops.
- Proven Field Record: Deployed globally in thousands of power and process plants with documented MTBF performance.
- Firmware Compatibility: Compatible with ABB Control Builder M software suite; firmware version confirmed prior to shipment.
- Long Service Life: ABB’s extended lifecycle support policy makes this board a reliable long-term investment for brownfield upgrades.
Complete System Bill of Materials
The 3BHE027632R0101 Main Board is typically ordered alongside the following AC800M system components. Konmask can source the complete BOM:
- AC800M Controller Unit (PM864A / PM865A / PM866A)
- AC800M Power Supply Module (SD821 / SD822 / SD823)
- S800 I/O Modules (AI810, AO810, DI810, DO810, etc.)
- CI854A / CI857 Communication Interface Modules
- TB820V2 ModuleBus Modem
- Redundancy Module (RM858A)
- Optical cables and backplane connectors
Contact support@konmask.com with your full BOM for a consolidated quote.
Compliance & Industry Standards
- IEC 61131-3 — Programmable controller programming languages
- IEC 61850 — Communication networks and systems in substations
- IEC 61511 / IEC 61508 — Functional safety (SIL-capable configurations)
- CE Marking — EU Low Voltage and EMC Directives
- UL / cUL Listed — North American safety certification
- RoHS Compliant — Restriction of Hazardous Substances
Quality Assurance & Sourcing
Konmask operates a structured quality assurance process for all industrial automation components:
- Visual Inspection: Board-level inspection for physical damage, corrosion, and counterfeit markers.
- Functional Test: Power-on and communication handshake verification where applicable.
- Traceability: Serial number and firmware version documented and provided with shipment.
- Packaging: ESD-safe anti-static bags with foam cushioning; export-grade carton for international shipments.
- Warranty: 90-day replacement warranty on verified functional units. Extended warranty available on request.
How to Source This Part
- Submit an Inquiry: Email support@konmask.com or call +0086 19859288691 with your part number and required quantity.
- Receive a Quote: We respond within 1 business day with pricing, lead time, and stock availability.
- Order Confirmation: Confirm the purchase order; we issue a proforma invoice.
- Shipment: Dispatched via DHL / FedEx / SF Express with full tracking. Export documentation (commercial invoice, packing list, COO) included.
- After-Sales Support: Technical support available post-delivery for integration questions.
Application-Specific FAQ
Q: Is the 3BHE027632R0101 compatible with my existing AC800M rack?
A: Yes — this main board is designed for the AC800M platform backplane. Confirm your controller unit model (PM864A/PM865A/PM866A) with us to ensure firmware alignment.
Q: Can this board be used in a redundant CPU configuration?
A: Yes. The AC800M platform supports 1:1 CPU redundancy. Both primary and redundant boards must carry matching firmware versions, which we verify before shipment.
Q: What is the lead time if the part is not in stock?
A: Typical lead time for sourced units is 3–10 business days depending on origin. Expedited sourcing is available for urgent shutdowns.
Q: Do you provide a test report or certificate of conformance?
A: Yes. A functional test report and certificate of conformance are available upon request for quality-critical procurement.
Q: Can Konmask supply the full AC800M system, not just this board?
A: Absolutely. We specialize in complete DCS system sourcing. Share your BOM and we will provide a consolidated quote.
