ADLINK PCI-9810 16-Channel 12-Bit Multifunction DAQ Card – PCI-9810 Series
When a critical data acquisition node fails on the production floor, engineers face immediate blind spots — analog signals go unmonitored, process control loops lose feedback, and the entire line risks unplanned downtime. The ADLINK PCI-9810 eliminates that vulnerability by delivering reliable, high-resolution multifunction data acquisition in a standard PCI form factor that integrates seamlessly into existing industrial PC platforms.
Within the ADLINK PCI-9810 Series, the PCI-9810 occupies the entry-level multifunction position — offering 16 single-ended (or 8 differential) analog input channels at 12-bit resolution with a 100 kS/s aggregate sampling rate. This balance of channel density, resolution, and bus compatibility has made it a trusted choice for OEM machine builders and system integrators across Asia, Europe, and North America who require deterministic, cost-effective DAQ in PCI-slot-equipped industrial PCs.
Technical Specifications
- Model: PCI-9810
- Manufacturer: ADLINK Technology
- Bus Interface: 32-bit PCI (Universal PCI, 3.3 V / 5 V)
- Analog Input Channels: 16 single-ended / 8 differential
- A/D Resolution: 12-bit
- Sampling Rate: Up to 100 kS/s (aggregate)
- Input Range: ±10 V, ±5 V, ±2.5 V, ±1.25 V (software selectable)
- Analog Output: 2 channels, 12-bit DAC
- Digital I/O: 16-bit (8 in / 8 out), TTL compatible
- Counter/Timer: 1 × 16-bit counter/timer (8254 compatible)
- Trigger: Software, internal pacer, external digital trigger
- Operating Temperature: 0 °C to 60 °C
- Power Consumption: +5 V @ 500 mA (typical)
- Dimensions: Standard PCI half-length card
- OS Support: Windows XP/7/10, Linux (kernel driver available)
- Software: Compatible with ADLINK DAQPilot, LabVIEW, MATLAB
Key Features & Benefits
- 16-Channel Analog Input: Flexible single-ended or differential configuration maximizes channel utilization for multi-sensor applications.
- 12-Bit Resolution: Provides 4096 discrete levels for accurate signal representation in process monitoring and control.
- 100 kS/s Throughput: Sufficient for vibration pre-screening, temperature profiling, and slow-speed motion feedback.
- Onboard FIFO Buffer: Prevents data loss during host CPU latency spikes — critical for unattended long-duration logging.
- Universal PCI Compatibility: Operates in both 3.3 V and 5 V PCI slots, extending service life across legacy and modern IPC platforms.
- Integrated D/A Output: Two 12-bit analog output channels enable closed-loop control without additional hardware.
- Software Ecosystem: Plug-and-play with ADLINK DAQPilot SDK; compatible with NI LabVIEW and MathWorks MATLAB for rapid application development.
Industry & Equipment Applications
- Factory Automation: Analog sensor monitoring (pressure, temperature, flow) on PLC-supplemented IPC platforms.
- Machine Tool Industry: Spindle vibration pre-screening and axis position feedback logging.
- Energy & Utilities: Power quality monitoring and generator output signal acquisition.
- Laboratory & R&D: Automated test equipment (ATE) for component characterization and burn-in testing.
- Environmental Monitoring: Multi-channel sensor data logging for air quality, humidity, and temperature stations.
- Semiconductor & Electronics: Process parameter monitoring in SMT and PCB inspection lines.
System Integration & Compatible Parts
The PCI-9810 is designed for seamless integration within ADLINK’s DAQ ecosystem and broader industrial PC environments:
- Companion Cards: ADLINK PCI-9812 (12-bit, 4-ch high-speed), PCI-9816 (16-bit resolution upgrade)
- Breakout Accessories: ADLINK ACL-10168 screw-terminal board with DB-37 cable for field wiring
- Software SDK: ADLINK DAQPilot (Windows/Linux), compatible with NI-DAQmx migration paths
- IPC Platforms: Compatible with any industrial PC featuring a standard 32-bit PCI slot (Advantech, Siemens, Beckhoff IPC series)
- SCADA Integration: Tested with Wonderware InTouch, Ignition SCADA via OPC-DA/OPC-UA bridge drivers
Our Quality Assurance Process
- Source Verification: All ADLINK modules are sourced from authorized distributors or directly from ADLINK’s certified supply chain.
- Incoming Inspection: Each unit undergoes visual inspection, label verification, and date-code cross-check before warehousing.
- Functional Pre-test: Boards are bench-tested for PCI enumeration and basic I/O continuity prior to shipment.
- Anti-static Packaging: Shipped in ESD-safe bags with foam cushioning to prevent transit damage.
- Traceability: Full lot traceability records maintained for warranty and compliance purposes.
How to Order
- Submit your inquiry via the Contact Us form or email support@konmask.com.
- Provide your required quantity, delivery timeline, and destination country.
- Our team will respond within 24 business hours with availability confirmation and a formal quotation.
- Upon PO confirmation, we arrange export documentation, packaging, and shipment via your preferred freight method.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on automation components — PLC modules, DAQ cards, DCS parts — ensuring deep product knowledge.
- Global Export Experience: Serving buyers in 30+ countries with compliant export documentation and multi-carrier logistics.
- Responsive Quotation: Dedicated B2B inquiry handling with 24-hour response SLA.
- Obsolescence Support: We stock and source end-of-life and hard-to-find industrial components that OEMs no longer supply.
- Technical Pre-sales Support: Our engineers can advise on compatibility, replacement options, and system integration.
Frequently Asked Questions
- Q: Is the ADLINK PCI-9810 compatible with Windows 10 64-bit?
- A: Yes. ADLINK provides signed 64-bit drivers for Windows 10. Download the latest driver package from ADLINK’s official support portal or contact us for the installer.
- Q: Can the PCI-9810 be used as a replacement for the NI PCI-6023E?
- A: The PCI-9810 offers comparable channel count and resolution. However, software migration from NI-DAQmx to ADLINK DAQPilot API is required. Our technical team can assist with the migration assessment.
- Q: What is the minimum order quantity (MOQ)?
- A: We accept single-unit orders. Volume pricing is available for orders of 5 units or more — please request a formal quotation.
- Q: Do you provide a warranty?
- A: Yes. All units carry a 90-day functional warranty from the date of shipment. Extended warranty options are available upon request.
- Q: Can you ship to my country?
- A: We ship worldwide via DHL, FedEx, UPS, and sea freight. Export compliance documentation (commercial invoice, packing list, COO) is provided for all international shipments.
