Allen-Bradley 1756-OV16E DC Fused Sinking Output Module – ControlLogix Series
When a critical output module fails on the plant floor, the consequences are immediate and costly: conveyor lines halt, robotic arms freeze mid-cycle, and production supervisors face unplanned downtime that can cost thousands of dollars per hour. In high-stakes discrete manufacturing environments — automotive assembly, food & beverage packaging, material handling — the output module is the final command link between the PLC and the physical world. Without a reliable, fuse-protected sinking output module, a single short circuit can cascade into a full line shutdown, damaging both equipment and delivery commitments.
The Allen-Bradley 1756-OV16E is Rockwell Automation’s answer to that challenge within the ControlLogix platform — one of the most widely deployed programmable automation controller (PAC) architectures in global discrete and process manufacturing. As a 16-point, DC fused sinking output module, the 1756-OV16E occupies a critical position in the ControlLogix 1756 I/O family: it delivers field-level output control with individual electronic fuse protection per output point, dramatically reducing fault propagation risk. Trusted by system integrators and OEMs across North America, Europe, and Asia-Pacific, this module is a cornerstone component in safety-conscious, high-availability control system designs.
Technical Specifications
- Catalog Number: 1756-OV16E
- Series: ControlLogix 1756
- Module Type: DC Fused Sinking Output
- Number of Output Points: 16
- Output Voltage Range: 10–30V DC
- Output Current per Point: 1A (max)
- Fuse Protection: Individual electronic fuse per output point
- Backplane Current (5V DC): 4mA
- Backplane Current (24V DC): 105mA
- Isolation: 100% tested, group isolation between field side and backplane
- Wiring: Removable terminal block (RTB), 20-pin
- Indicators: Per-point LED status indicators
- Operating Temperature: 0–60°C (32–140°F)
- Certifications: UL, CE, C-Tick
- Weight: Approx. 300g
Note: All specifications are sourced from Rockwell Automation official documentation. Konmask.com does not fabricate or modify published specifications.
Key Features & Benefits
- Individual Electronic Fuse Protection: Each of the 16 output points is independently fuse-protected, preventing a single field-side fault from disabling the entire module — a critical advantage in high-uptime environments.
- Sinking Output Architecture: Compatible with NPN-type field devices (sensors, solenoids, actuators), making it the standard choice for Asian and European machine builders using NPN wiring conventions.
- LED Diagnostics per Point: Real-time visual status for each output channel accelerates fault isolation during commissioning and maintenance, reducing MTTR (Mean Time to Repair).
- Hot-Swap Capable: Supports removal and insertion under power (RIUP) within the ControlLogix chassis, enabling module replacement without full system shutdown.
- Removable Terminal Block (RTB): Pre-wired RTBs can be swapped independently of the module, simplifying field replacement and reducing rewiring time.
- Compact 1-Slot Form Factor: Fits any standard 1756 ControlLogix chassis slot, maximizing I/O density in space-constrained panels.
Industry & Equipment Applications
- Automotive Manufacturing: Body welding lines, paint shop conveyors, assembly robot end-effector control
- Food & Beverage: Filling machine valve control, packaging line actuator outputs, CIP system solenoid control
- Material Handling: Sortation system diverter control, conveyor drive enable signals, warehouse AGV interface
- Oil & Gas / Petrochemical: Wellhead control panel outputs, compressor station valve actuation
- Pharmaceutical: Batch process valve sequencing, cleanroom HVAC damper control
- Water & Wastewater: Pump station output control, chemical dosing valve actuation
System Integration & Compatible Parts
The 1756-OV16E is designed for seamless integration within the Rockwell Automation ControlLogix ecosystem. Compatible and commonly paired components include:
- Chassis: 1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17
- Power Supplies: 1756-PA72, 1756-PB72, 1756-PB75
- Controllers: 1756-L71, 1756-L72, 1756-L73, 1756-L74, 1756-L75, 1756-L81E, 1756-L82E, 1756-L83E, 1756-L84E, 1756-L85E
- Communication Modules: 1756-EN2T, 1756-EN2TR, 1756-CN2, 1756-DNB
- Wiring Accessories: 1756-TBCH (cage clamp RTB), 1756-TBS6H (spring clamp RTB)
- Related Output Modules: 1756-OB16E (sourcing), 1756-OB16I (isolated), 1756-OA16 (AC output)
Our Quality Assurance Process
At Konmask.com, every Allen-Bradley 1756-OV16E module offered undergoes a rigorous multi-stage verification process before shipment:
- Source Verification: Modules are sourced exclusively from authorized distributors, certified surplus dealers, or directly from Rockwell Automation-approved channels.
- Visual Inspection: Physical examination of housing, label integrity, connector condition, and LED functionality.
- Firmware & Revision Check: Series letter and firmware revision are documented and disclosed to buyers prior to order confirmation.
- Functional Test (where applicable): Bench-tested in a live ControlLogix chassis to verify backplane communication and output point operation.
- Anti-Counterfeit Screening: Cross-referenced against known counterfeit indicators per Rockwell Automation’s published guidelines.
- Secure Packaging: ESD-safe packaging with moisture barrier bags and shock-absorbing foam for international transit.
How to Order
- Submit an inquiry via the “Get a Quote” button or email support@konmask.com
- Provide your required quantity, delivery timeline, and destination country
- Our technical team will confirm availability, series revision, and lead time within 24 hours
- Receive a formal quotation with payment terms (T/T, L/C, PayPal accepted)
- Upon payment confirmation, modules are inspected, packed, and dispatched with full tracking
For urgent requirements or large-volume orders, please contact us directly at +0086 19859288691 (WhatsApp/WeChat available).
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation Components — PLC, DCS, HMI, drives, and I/O modules from leading global brands
- ✅ Global Export Experience — Serving buyers in Southeast Asia, Middle East, Europe, and the Americas with compliant export documentation
- ✅ Technical Pre-Sales Support — Our engineers can advise on compatibility, firmware versions, and system integration before you commit to a purchase
- ✅ Competitive Pricing on Surplus & New Stock — Access to both new-in-box and certified surplus inventory at market-competitive prices
- ✅ Fast Response, Reliable Delivery — 24-hour quotation turnaround; DHL/FedEx/UPS express options available for time-critical projects
- ✅ After-Sales Warranty — 90-day functional warranty on all modules; DOA replacement policy
Frequently Asked Questions
Q: What is the difference between the 1756-OV16E and the 1756-OB16E?
A: Both are 16-point DC output modules for ControlLogix. The 1756-OV16E is a sinking (NPN) output module, meaning the load connects between the output terminal and the positive supply. The 1756-OB16E is a sourcing (PNP) output module. The choice depends on your field device wiring convention.
Q: Is the 1756-OV16E compatible with all ControlLogix chassis?
A: Yes. The 1756-OV16E fits any standard 1756 ControlLogix chassis (1756-A4 through 1756-A17) and is compatible with all ControlLogix controllers running RSLogix 5000 / Studio 5000 Logix Designer.
Q: Can this module be replaced while the system is running?
A: Yes. The 1756-OV16E supports Removal and Insertion Under Power (RIUP), allowing hot-swap replacement without shutting down the entire chassis — a key feature for high-availability production environments.
Q: What does “fused” mean in the context of this module?
A: “Fused” refers to individual electronic fuse protection on each output point. If an output is overloaded or short-circuited, only that point is disabled and flagged via LED — the remaining 15 outputs continue to operate normally. This significantly reduces fault impact compared to non-fused modules.
Q: Do you provide a certificate of conformance or test report?
A: Yes. Upon request, Konmask.com can provide inspection documentation, series/revision disclosure, and a functional test report for modules that have been bench-tested.
Q: What is the lead time for the 1756-OV16E?
A: Lead time depends on current stock levels. In-stock modules typically ship within 1–3 business days. For out-of-stock items, our sourcing team can usually locate and deliver within 7–15 business days. Contact us for real-time availability.
