Allen-Bradley 2097-V33PR5-LM / 2097-F6 EMC Line Filter – Kinetix 300 Drive System
When an industrial servo drive operates without a properly rated EMC line filter, the consequences extend far beyond a failed compliance audit. Conducted electromagnetic interference propagates back through the AC power bus, corrupting encoder feedback signals, tripping upstream protective relays, and — in worst-case scenarios — causing uncontrolled axis motion that halts an entire production line. For machine builders and plant engineers running Allen-Bradley Kinetix 300 servo drives, the 2097-V33PR5-LM / 2097-F6 Line Filter is not an optional accessory; it is the first line of defense between a clean power grid and a precision motion control system.
The 2097-V33PR5-LM (integrated filter variant) and its companion panel-mount module 2097-F6 occupy a well-defined position within the Kinetix 300 ecosystem — Rockwell Automation’s compact, single-axis EtherNet/IP servo drive platform designed for embedded machine applications. Rated for 200–240 V AC three-phase input, these filters are engineered to meet EN 61800-3 Category C2 EMC requirements, making them the preferred choice for OEM machine builders shipping equipment into CE-marked markets across Europe, Asia, and the Americas.
Technical Specifications
- Part Numbers: 2097-V33PR5-LM / 2097-F6
- Compatible Drive Series: Allen-Bradley Kinetix 300 (2097-Vxx series)
- Input Voltage: 200–240 V AC, Three-Phase
- EMC Standard: EN 61800-3 Category C2
- Filter Type: AC Line Filter (EMI/RFI suppression)
- Manufacturer: Rockwell Automation / Allen-Bradley
- Series: Kinetix 300 Drive System
- Form Factor: Panel-mount / Drive-integrated
Note: All specifications are sourced from Rockwell Automation official documentation. Contact us to confirm the exact revision level before ordering.
Key Features & Benefits
- CE / EMC Compliance Ready: Meets EN 61800-3 C2 limits out of the box — eliminates costly third-party EMC testing for machine builders.
- Plug-and-Play Integration: Designed specifically for the Kinetix 300 drive family; no external wiring adapters or custom mounting brackets required.
- Conducted Emission Suppression: Attenuates high-frequency noise on the AC supply line, protecting upstream PLCs, HMIs, and instrumentation from drive-generated interference.
- Compact Footprint: Optimized for space-constrained control panels common in packaging, semiconductor, and medical device machinery.
- Long Service Life: Passive filter design with no active components — minimal maintenance, maximum uptime.
- Global Market Access: Supports machine export to EU, UK, and other markets requiring IEC/EN EMC compliance.
Industry & Equipment Applications
- Packaging Machinery: High-speed pick-and-place, form-fill-seal, and cartoning lines where EMI can disrupt vision systems and servo coordination.
- Semiconductor & Electronics Manufacturing: Wafer handling, PCB assembly, and test equipment requiring ultra-clean power environments.
- Medical Device Production: Regulatory-compliant manufacturing lines where EMC certification is mandatory.
- Printing & Converting: Web tension control and registration systems sensitive to electrical noise.
- Robotics & Material Handling: Multi-axis gantry and SCARA robot cells powered by Kinetix 300 drives.
- Food & Beverage Processing: Hygienic machine designs requiring CE marking for export markets.
System Integration & Compatible Parts
The 2097-V33PR5-LM / 2097-F6 is designed to work within the complete Kinetix 300 motion control architecture. Typical companion components include:
- Kinetix 300 Servo Drives: 2097-V31PR0, 2097-V31PR2, 2097-V32PR0, 2097-V32PR2, 2097-V33PR1, 2097-V33PR3, 2097-V33PR5, 2097-V34PR3, 2097-V34PR5, 2097-V34PR6
- CompactLogix / MicroLogix Controllers: EtherNet/IP-based motion coordination
- MP-Series / TL-Series Servo Motors: Matched motor-drive combinations for Kinetix 300
- 2090-Series Motor Cables: Shielded power and feedback cables for EMC integrity
- Bulletin 140M Motor Protection Circuit Breakers: Upstream branch circuit protection
Always verify compatibility against the Kinetix 300 EtherNet/IP Indexing Servo Drive User Manual (Publication 2097-UM001) before finalizing your BOM.
Our Quality Assurance Process
- Source Verification: All units are sourced from authorized distributors or directly from Rockwell Automation-certified supply chains.
- Visual & Functional Inspection: Each unit undergoes incoming inspection for physical integrity, label authenticity, and date code verification.
- Anti-Counterfeit Screening: We cross-reference serial numbers and holographic labels against known-genuine references.
- Secure Packaging: ESD-safe packaging with moisture barrier bags and shock-absorbing foam for international shipment.
- Documentation: Certificate of conformance and test reports available upon request for regulated industries.
How to Order
- Submit your inquiry via the Contact Us form or email [email protected] with your required quantity and delivery timeline.
- Our technical team will confirm stock availability, lead time, and provide a formal quotation within 24 business hours.
- Upon PO confirmation, we arrange secure payment and dispatch with full tracking.
- Expedited shipping available for urgent production line requirements.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, servo, and motion control components — not a generalist electronics distributor.
- Global B2B Supply: Serving OEM machine builders, system integrators, and MRO procurement teams across 30+ countries.
- Technical Pre-Sales Support: Our engineers can assist with compatibility checks, cross-references, and application guidance.
- Competitive Lead Times: Extensive supplier network enables fast sourcing even for discontinued or long-lead items.
- Transparent Quotation: No hidden fees. Clear pricing, clear terms, clear delivery commitments.
Frequently Asked Questions
Q: What is the difference between 2097-V33PR5-LM and 2097-F6?
A: The 2097-V33PR5-LM is a Kinetix 300 drive variant with an integrated line filter module, while the 2097-F6 is a standalone external line filter designed to be used with standard (non-LM) Kinetix 300 drive variants. Both achieve equivalent EMC performance for the same drive power class.
Q: Is this filter required for CE marking?
A: Yes. Rockwell Automation’s CE Declaration of Conformity for the Kinetix 300 drive system specifies that the appropriate line filter must be installed to achieve EN 61800-3 Category C2 compliance. Operating without the filter will void CE compliance.
Q: Can I use the 2097-F6 with other Allen-Bradley drive families?
A: The 2097-F6 is rated and documented specifically for the Kinetix 300 (2097-V series) drive family. Use with other drive families is not supported by Rockwell Automation and may result in inadequate EMC attenuation or thermal issues.
Q: Do you supply new or refurbished units?
A: We supply new, factory-sealed units as standard. Reconditioned units may be available for select obsolete part numbers — please specify your requirement in your inquiry.
Q: What is your minimum order quantity (MOQ)?
A: MOQ is 1 piece. We accommodate both single-unit MRO replacements and bulk OEM orders.
Q: How long does international shipping take?
A: Standard international express (DHL/FedEx) typically delivers within 3–7 business days depending on destination. We provide full tracking upon dispatch.
