Stepper Motor Control Solution – ALPHA PD-4B | PD4B Driver Module
The ALPHA PD-4B (PD4B) Driver Module is a compact, high-reliability stepper motor drive unit engineered for precision motion control in industrial automation environments. Designed to interface seamlessly with mainstream PLC platforms, this module delivers consistent torque output, smooth micro-stepping performance, and robust protection features demanded by OEM machine builders and system integrators worldwide.
Where This Product Is Used
- CNC Machining Centers – Axis feed drives requiring precise step/direction control
- Automated Packaging Lines – Film indexing, label dispensing, and conveyor positioning
- Textile & Printing Machinery – Fabric tension control and print-head carriage drives
- Semiconductor & Electronics Assembly – Pick-and-place gantry and wafer-handling stages
- Medical & Laboratory Equipment – Syringe pumps, sample carousels, and dosing systems
- Robotics & Cartesian Systems – Multi-axis coordinated motion with PLC master control
Technical Specifications
- Model: PD-4B (PD4B)
- Brand: ALPHA
- Type: Stepper Motor Driver Module
- Control Interface: Step / Direction pulse input
- Micro-stepping: Selectable resolution (full, 1/2, 1/4, 1/8, 1/16)
- Protection: Over-current, over-temperature, short-circuit
- Mounting: DIN rail / panel mount compatible
- Weight: 1,150 g
- Origin: Industrial-grade manufacturing
Full datasheet available upon request. Contact support@konmask.com for detailed electrical specifications.
Why Engineers Specify This Model
- Drop-in Compatibility – Step/direction interface works with Siemens, Mitsubishi, Omron, Schneider, and Delta PLCs without additional signal conditioning
- Smooth Low-Speed Torque – Advanced current control algorithm minimizes resonance and audible noise at low RPM
- Compact Footprint – Fits tight control cabinet layouts without sacrificing thermal headroom
- Robust Protection Suite – Reduces unplanned downtime caused by wiring faults or motor stalls
- Proven ALPHA Platform – Consistent firmware and hardware revision history simplifies spare-parts management
Complete System Bill of Materials
For a fully operational stepper axis, engineers typically pair the PD-4B with:
- ALPHA-compatible stepper motor (NEMA 23 / 34 frame)
- 24 VDC or 48 VDC regulated power supply
- PLC with high-speed pulse output (e.g., Mitsubishi FX5U, Siemens S7-1200)
- Shielded motor cable (≤ 3 m recommended)
- Emergency-stop relay and safety interlock module
Konmask.com stocks complementary components — contact us for a complete BOM quotation.
Compliance & Industry Standards
- CE Marking – Low Voltage Directive (LVD) compliant
- RoHS – Restriction of Hazardous Substances compliant
- EMC – Designed to meet EN 61800-3 emission and immunity requirements
- UL recognition available on select variants (confirm at order)
Quality Assurance & Sourcing
Every ALPHA PD-4B unit supplied by Konmask.com undergoes incoming inspection including functional power-on test, label and serial-number verification, and packaging integrity check. We source exclusively from authorized distributors and verified OEM channels to eliminate counterfeit risk — a critical concern in the industrial automation aftermarket.
- Authenticity guaranteed with traceable lot documentation
- 30-day DOA (Dead on Arrival) replacement policy
- Secure anti-static packaging for international shipment
How to Source This Part
- Add to Cart – Click the purchase button above for immediate checkout
- Request a Quote – Email support@konmask.com for volume pricing (5+ units)
- Expedited Sourcing – Call or WhatsApp +0086 19859288691 for urgent project requirements
- Datasheet / Wiring Diagram – Available free on request; specify your PLC brand for application-specific guidance
Application-Specific FAQ
Q: Is the PD-4B compatible with Mitsubishi FX-series PLCs?
A: Yes. The step/direction pulse interface is directly compatible with FX3U/FX5U high-speed output modules. No additional signal converter is required.
Q: What is the maximum pulse frequency the PD-4B accepts?
A: Please refer to the official ALPHA datasheet or contact our technical team for confirmed electrical specifications for your application.
Q: Can I use the PD-4B in a servo-replacement retrofit?
A: The PD-4B is a stepper driver and is best suited for open-loop positioning applications. For closed-loop servo replacement, consider ALPHA’s servo drive series — contact us for a recommendation.
Q: Do you offer warranty on this module?
A: Yes. All units carry a 12-month warranty against manufacturing defects when operated within rated conditions.
Q: Can Konmask.com supply multiple units for a production line?
A: Absolutely. We handle OEM and MRO bulk orders. Contact us for lead time and volume pricing.
