Genuine WOODWARD SST-DN3-PCI-2 DeviceNet PCI Interface Card | SST Series – Verified Source
The WOODWARD SST-DN3-PCI-2 is a high-performance DeviceNet Master/Slave PCI interface card widely deployed in industrial automation systems across energy, turbine control, and process industries. As a legacy-compatible yet mission-critical component, this card is increasingly difficult to source through standard distribution channels — making it a prime target for counterfeit substitutes and grey-market replicas that can cause catastrophic control system failures.
At Konmask, every SST-DN3-PCI-2 unit we supply undergoes a documented 4-step verification process before shipment. We source exclusively from verified industrial channels and maintain full traceability records for each unit. Our commitment to genuine, verified, and authentic parts is the foundation of every transaction — backed by documentation you can inspect before you buy.
Technical Specifications
- Part Number: SST-DN3-PCI-2
- Brand / OEM: WOODWARD (formerly SST / Molex)
- Interface: DeviceNet (CAN-based, ISO 11898)
- Bus Type: PCI (32-bit, 5V / 3.3V universal)
- Node Capability: Master and/or Slave (configurable)
- Max Network Nodes: 64 nodes per network
- Baud Rates: 125 kbps / 250 kbps / 500 kbps
- I/O Data: Up to 512 bytes input / 512 bytes output
- Explicit Messaging: Supported
- Driver Support: Windows XP/7/10, Linux (kernel 2.6+)
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -40°C to +85°C
- Power Consumption: ≤ 2.5W (from PCI slot)
- Dimensions: Standard PCI half-length card
- Weight: ~1,150 g (packaged)
- Certifications: CE, FCC Class A, RoHS compliant
Specifications verified against WOODWARD / SST official documentation and product datasheet SST-DN3-PCI-2 Rev. C.
Our 4-Step Quality Verification Process
- Step 1 — Visual & Marking Inspection: Each unit is examined under magnification for PCB markings, component placement, silkscreen accuracy, and label authenticity. Counterfeit units frequently exhibit misaligned text, incorrect font weights, or missing revision codes — all checked against OEM reference samples.
- Step 2 — Functional Power-On Test: The card is installed in a test rig and powered on. We verify PCI enumeration, DeviceNet port initialization, LED status indicators, and driver handshake using SST’s official diagnostic utility. Results are logged and retained.
- Step 3 — Communication Protocol Verification: A live DeviceNet network test is performed at all three baud rates (125/250/500 kbps). Master scan list configuration, explicit messaging, and I/O polling are validated against expected OEM behavior.
- Step 4 — Documentation Package Assembly: Upon passing all tests, we compile a shipment package including: Certificate of Conformance (COC), Functional Test Report, Product Photos (pre-shipment), Packing List, and Country of Origin (COO) Declaration. Available upon request prior to order confirmation.
Key Features & Benefits
- Dual Master/Slave Operation: Configurable as DeviceNet Master, Slave, or both simultaneously — maximizing system design flexibility per ODVA DeviceNet Specification Vol. 1.
- High-Throughput I/O: Supports up to 512 bytes in each direction, meeting IEC 61158 fieldbus performance requirements for demanding process control applications.
- Universal PCI Compatibility: 32-bit 5V/3.3V universal edge connector ensures compatibility with legacy and modern industrial PCs without additional adapters.
- Robust Firmware Architecture: Onboard processor offloads DeviceNet protocol stack from the host CPU, reducing latency and improving determinism in real-time control loops.
- Comprehensive SDK & Driver Ecosystem: Compatible with SST’s DNP/DNM API libraries, enabling rapid integration into SCADA, HMI, and custom automation software environments.
- Long-Term Availability Commitment: Konmask maintains buffer stock of legacy SST cards specifically to support installed-base maintenance, MRO procurement, and emergency replacement scenarios.
Typical Applications
- Turbine & Engine Control: WOODWARD governor and fuel control systems using DeviceNet for actuator and sensor communication in power generation plants.
- Oil & Gas Automation: Wellhead control panels and compressor skids where DeviceNet connects field instruments to DCS/PLC host controllers.
- Automotive Assembly Lines: Robot controller integration and conveyor PLC networks requiring high-speed, deterministic DeviceNet I/O scanning.
- Water & Wastewater Treatment: SCADA-connected pump stations and valve actuator networks operating under IEC 61511 functional safety guidelines.
- Discrete Manufacturing: Machine tool controllers and packaging line PLCs communicating with distributed I/O blocks via DeviceNet Master polling.
- Building Automation & Utilities: HVAC control systems and energy management platforms integrating legacy DeviceNet field devices with modern supervisory software.
Compatible System Components
- WOODWARD 505 / 505E Digital Governor Controllers
- WOODWARD MicroNet TMR / MicroNet Plus Control Modules
- Allen-Bradley / Rockwell 1756-DNB DeviceNet Bridge Modules
- SST-DN3-104-2 / SST-DN3-PCIE-2 (PCIe successor variant)
- DeviceNet Tap / Drop Cable Assemblies (Belden 3082A or equivalent)
- ODVA-compliant DeviceNet Power Supplies (24VDC, ≥ 8A)
- SST Network Configuration Tool (NCT) Software Suite
- Third-party DeviceNet slaves: Turck, Pepperl+Fuchs, Banner Engineering I/O blocks
Global Sourcing & Shipping Capabilities
- Primary Service Regions: Mainland China, Southeast Asia (Vietnam, Thailand, Indonesia), Middle East (UAE, Saudi Arabia), Europe (Germany, Netherlands, Poland), and North America (USA, Canada, Mexico).
- Packaging Standard: Anti-static ESD bag → foam-lined inner box → double-wall corrugated outer carton. Fragile / Electronics labeling applied. Conforms to ISTA 2A transit testing standards.
- Logistics Options: DHL Express (2–5 days), FedEx International Priority, sea freight LCL/FCL for bulk orders, and China Post Registered Air Mail for budget-sensitive shipments.
- Export Documentation: Commercial Invoice, Packing List, COO Declaration, and HS Code 8537.10 classification provided as standard. Letter of Credit (L/C) and T/T payment terms accepted.
- Lead Time: In-stock units ship within 1–3 business days of payment confirmation. Pre-order units: 7–15 business days depending on sourcing channel.
Certifications & Compliance Statement
- CE Marking — EMC Directive 2014/30/EU
- FCC Part 15 Class A — Unintentional Radiator
- RoHS 3 Compliant — Directive 2011/65/EU + Amendment 2015/863/EU
- ODVA DeviceNet Conformance Tested
- ISO 9001:2015 Supply Chain Quality Management (Konmask internal process)
Konmask Quality Commitment: We do not list, sell, or knowingly source counterfeit, refurbished-as-new, or specification-deviated components. Every unit sold under the Konmask brand is accompanied by verifiable documentation. If any unit fails to perform as specified within the warranty period, we provide full replacement or refund — no dispute required.
How to Order
- Step 1 — Submit Inquiry: Contact us via the product page, email [email protected], or WhatsApp/WeChat +0086 19859288691 with your required quantity, delivery timeline, and destination country.
- Step 2 — Receive Quotation & Documentation Preview: Within 24 hours, we will send a formal quotation, pre-shipment photos, and available test report / COC for your review. No payment required at this stage.
- Step 3 — Confirm & Ship: Upon order confirmation and payment, your unit is re-inspected, packaged, and dispatched with full export documentation. Tracking number provided same day.
Sample units and third-party inspection arrangements available for qualified buyers. Contact us to discuss.
Authenticity & Trust FAQ
-
Q: How can I verify the unit is genuine WOODWARD / SST?
A: We provide pre-shipment photos of the physical unit including PCB markings, serial number label, and revision code. You may cross-reference these against WOODWARD’s official part documentation or request a video inspection call before payment. -
Q: What is your warranty policy?
A: All units carry a 12-month warranty from date of shipment against manufacturing defects and functional failure under normal operating conditions. DOA (Dead on Arrival) units are replaced or refunded within 5 business days of confirmed return. -
Q: Can you provide a functional test report before I order?
A: Yes. For in-stock units, a functional test report and Certificate of Conformance (COC) are available upon request at no additional charge. For pre-order units, documentation is generated upon receipt and prior to shipment.
