Drive & Motor Control Solution — ANSALDO 211QS50003B | Power Trigger Board
Where This Product Is Used
The ANSALDO 211QS50003B Power Trigger Board is a critical firing/trigger interface module deployed in high-power industrial drive systems. Engineers and maintenance teams specify this board in the following environments:
- AC/DC Variable Speed Drives (VSDs) — thyristor and SCR-based drive cabinets requiring precise gate pulse generation for controlled rectification and inversion.
- Rolling Mill & Steel Plant Drive Systems — ANSALDO-branded drive systems used in hot and cold rolling lines where precise torque and speed control is mandatory.
- Marine Propulsion Control Panels — shipboard drive systems utilizing ANSALDO power electronics for propulsion motor management.
- Paper & Pulp Machine Drives — section drives on winders, coaters, and calenders where synchronized multi-axis control depends on reliable trigger timing.
- Mining Hoist & Conveyor Drives — high-inertia load applications demanding robust, repeatable firing angle control.
- Water Treatment & Pump Station Drives — large pump motor drives in municipal and industrial water infrastructure.
- OEM Drive Cabinet Rebuilds & Retrofits — replacement of failed trigger boards in legacy ANSALDO drive systems where OEM sourcing is discontinued or lead times are excessive.
Technical Specifications
| Part Number | 211QS50003B |
| Manufacturer | ANSALDO |
| Module Type | Power Trigger / Gate Firing Board |
| Function | SCR / Thyristor gate pulse generation and synchronization |
| Compatible Drive Families | ANSALDO series industrial AC/DC drives (confirm with your drive cabinet documentation) |
| Form Factor | PCB plug-in module |
| Weight (approx.) | 100 g |
| Condition Available | Surplus New / Tested Refurbished |
| Warranty | 12 months (Konmask standard) |
Note: Full electrical parameters (supply voltage, pulse width, output current) vary by drive revision. Contact our technical team with your drive cabinet nameplate data for confirmation.
Why Engineers Specify This Model
- OEM-Matched Firing Characteristics — The 211QS50003B is designed to ANSALDO’s original gate pulse timing specifications, ensuring compatibility with existing SCR stacks without re-tuning the drive controller.
- Drop-In Replacement — Identical connector footprint and board dimensions to the original, minimizing downtime during emergency replacement.
- Proven in High-Power Applications — Validated in multi-megawatt drive systems where trigger board failure causes full production stoppage.
- Reduced Commissioning Risk — Using the correct OEM trigger board eliminates the risk of mis-firing, SCR damage, or drive fault codes caused by incompatible aftermarket alternatives.
- Long-Term Availability via Konmask — Konmask maintains stock of legacy ANSALDO modules, providing a reliable supply chain for plants operating equipment beyond OEM support windows.
Complete System Bill of Materials
The 211QS50003B typically operates alongside the following ANSALDO drive system components. Konmask can source these parts — contact us for availability:
- ANSALDO SCR / Thyristor Power Stack Assembly
- ANSALDO Drive Control Board (Regulator PCB)
- ANSALDO Pulse Transformer / Gate Driver Board
- ANSALDO Feedback & Tachometer Interface Board
- ANSALDO Power Supply Board (auxiliary DC rails)
- ANSALDO Fault Detection & Protection Module
- Drive Cabinet Cooling Fan Assembly (compatible frame size)
Compliance & Industry Standards
- CE Marking — ANSALDO drive systems incorporating this board are designed to comply with applicable EU Low Voltage and EMC Directives.
- IEC 60146 — Semiconductor converters; general requirements and line commutated converters.
- IEC 61800 — Adjustable speed electrical power drive systems.
- RoHS Compliance — Confirm revision-specific RoHS status with Konmask at time of order.
- ISO 9001 Supply Chain — Konmask sources through ISO 9001-certified channels with full traceability documentation available on request.
Quality Assurance & Sourcing
Every ANSALDO 211QS50003B unit shipped by Konmask undergoes the following process:
- Visual Inspection — PCB, connectors, and components inspected for physical damage, corrosion, and counterfeit indicators.
- Functional Bench Test — Where applicable, boards are powered and tested for correct output pulse generation prior to dispatch.
- Anti-Static Packaging — Shipped in ESD-safe bags with foam cushioning to prevent transit damage.
- Traceability Documentation — Serial number, test record, and sourcing documentation provided upon request.
- 12-Month Warranty — All units carry Konmask’s standard 12-month warranty against defects in materials and workmanship.
How to Source This Part
- Confirm Part Number — Verify 211QS50003B against your drive cabinet’s BOM or the failed board’s label.
- Request a Quote — Email support@konmask.com or call +0086 19859288691 with your required quantity and delivery timeline.
- Technical Consultation — Our engineers can cross-reference your drive cabinet documentation to confirm compatibility before you commit to purchase.
- Order & Dispatch — Orders confirmed before cut-off are typically dispatched within 1–3 business days. Express shipping available for emergency breakdowns.
- Installation Support — Konmask provides basic installation guidance and can connect you with qualified drive service engineers if required.
Application-Specific FAQ
Q: Is the 211QS50003B compatible with all ANSALDO drive models?
A: The 211QS50003B is specific to certain ANSALDO drive families. Please share your drive cabinet model number or nameplate data with our team to confirm compatibility before ordering.
Q: Can this board be used as a direct replacement for a failed unit without recalibrating the drive?
A: In most cases, yes — provided the replacement is the same revision. Our team will advise on any revision differences and whether drive re-commissioning is required.
Q: Do you supply tested or untested units?
A: Konmask supplies both surplus-new and tested-refurbished units. Specify your preference at the time of inquiry. All units are inspected prior to dispatch.
Q: What is the lead time for emergency orders?
A: Subject to stock availability, emergency orders can be dispatched within 24–48 hours. Contact us immediately for breakdown situations.
Q: Can Konmask source other ANSALDO boards from the same drive system?
A: Yes. Konmask specializes in legacy industrial automation components. Provide your full BOM and we will advise on availability across all line items.
