WOODHEAD SST-DN3-PCU-1 DeviceNet Interface Card | SST DeviceNet Platform
Engineering Background
The WOODHEAD SST-DN3-PCU-1 is a high-performance DeviceNet interface card engineered for seamless integration between host PCs and DeviceNet industrial networks. Developed under the SST (Spectrum System Technology) platform — now part of the Molex/Woodhead industrial connectivity portfolio — this card has established a proven track record in demanding factory automation environments where deterministic communication and robust I/O management are non-negotiable.
Product Positioning
Designed for system integrators, OEM machine builders, and plant automation engineers who require a reliable, standards-compliant DeviceNet master/slave interface. The SST-DN3-PCU-1 bridges the gap between Windows-based SCADA/HMI platforms and the DeviceNet field bus layer, enabling real-time device monitoring, configuration, and control without proprietary hardware lock-in.
Complete Technical Specifications
| Part Number | SST-DN3-PCU-1 |
| Brand / Manufacturer | WOODHEAD (SST / Molex) |
| Form Factor | PCI Bus Interface Card |
| Network Protocol | DeviceNet (CAN-based, IEC 62026-3) |
| Node Capacity | Up to 64 nodes per network |
| Data Rate | 125 kbps / 250 kbps / 500 kbps (auto-detect) |
| Operating Mode | Master (Scanner) / Slave (Adapter) |
| Host Interface | PCI 2.1 compliant, 32-bit, 33 MHz |
| OS Support | Windows XP / 7 / 10 (32/64-bit); VxWorks; QNX |
| Driver / API | SST DeviceNet API (DLL); EDS file support |
| Isolation | Optical isolation on DeviceNet port |
| Connector | 5-pin Open Style / Mini DeviceNet connector |
| Power Consumption | ≤ 1.5 W (from PCI bus) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Certifications | CE, UL, ODVA Conformance Tested |
| Dimensions | Standard PCI half-length card |
Proven Application Environments
- Automotive Assembly Lines — Real-time scanner control of DeviceNet I/O blocks, drives, and sensors across multi-zone conveyor systems.
- Food & Beverage Processing — Hygienic-area PLC-to-PC gateway for recipe management and batch control via DeviceNet.
- Semiconductor Fab Equipment — Deterministic communication with wafer-handling robots and process controllers.
- Material Handling & Logistics — Sorter and palletizer control with high-speed I/O polling over DeviceNet.
- Water Treatment & Utilities — Remote I/O monitoring for distributed pump and valve control networks.
- Machine Tool & CNC Integration — Spindle drive and servo parameter management via DeviceNet master scanning.
Engineering Advantages
- ODVA-Conformance Tested — Guaranteed interoperability with all certified DeviceNet devices; eliminates integration risk.
- Optical Isolation — Protects host PC from ground loops and transient surges common in industrial environments.
- Dual-Mode Operation — Single card operates as Master Scanner or Slave Adapter, reducing BOM complexity for multi-role deployments.
- Rich Software Ecosystem — SST API DLL integrates directly with LabVIEW, Visual C++, VB.NET, and third-party SCADA platforms.
- EDS File Support — Plug-and-play device configuration via standard Electronic Data Sheet files.
- Proven Longevity — Widely deployed since the early 2000s; extensive field history in mission-critical automation.
System Architecture & Signal Flow
The SST-DN3-PCU-1 installs into a standard PCI slot on the host PC motherboard. The on-board DeviceNet controller (CAN ASIC) manages all network timing, arbitration, and message queuing autonomously, offloading the host CPU. The SST API provides a memory-mapped I/O interface: the application writes output data to a shared dual-port RAM region; the card’s firmware executes the DeviceNet scan cycle and updates input data tables in real time. Optical isolation on the DeviceNet port decouples the PC ground reference from the field bus, ensuring signal integrity across long cable runs (up to 500 m at 125 kbps).
Signal Flow: Host Application → SST API DLL → PCI Bus → On-board CAN Controller → Optical Isolator → DeviceNet Network → Field Devices (I/O, Drives, Sensors)
Sourcing & Quality Verification
- Genuine Parts Only — Konmask.com sources SST-DN3-PCU-1 units exclusively from authorized distributors and verified industrial surplus channels with full traceability.
- Pre-shipment Inspection — Each unit undergoes visual inspection, label verification, and functional power-on check before dispatch.
- Counterfeit Prevention — Holographic labels, PCB revision markings, and firmware version checks are validated against OEM reference standards.
- Documentation Package — Certificate of conformance, original datasheet, and test report available upon request.
- Warranty — 90-day replacement warranty against DOA or latent defects.
Procurement Process
- Step 1 — Inquiry: Submit your part number, required quantity, and delivery timeline to support@konmask.com or via the product page.
- Step 2 — Quote: Receive a formal quotation with unit price, lead time, and shipping options within 1 business day.
- Step 3 — Order Confirmation: Approve the quote; Konmask issues a proforma invoice. Payment via T/T, PayPal, or credit card.
- Step 4 — Inspection & Dispatch: Unit inspected, packed with anti-static protection, and shipped via DHL / FedEx with tracking.
- Step 5 — After-Sales Support: Technical assistance for installation and driver configuration available post-delivery.
Technical FAQ
Q: Is the SST-DN3-PCU-1 compatible with Windows 10 64-bit?
A: Yes. SST provides a 64-bit driver package for Windows 10. Confirm the driver version (≥ v4.x) matches your OS build before installation.
Q: Can this card operate as both Master and Slave simultaneously?
A: No. The card operates in one mode at a time, selectable via the SST API initialization call. Mode switching requires a re-initialization of the network stack.
Q: What is the maximum cable length supported?
A: 500 m at 125 kbps; 250 m at 250 kbps; 100 m at 500 kbps — per DeviceNet specification IEC 62026-3.
Q: Does Konmask provide the SST software/driver CD?
A: Driver packages are available for download from the Molex/SST support portal. Konmask can provide the download link and installation guidance upon request.
Q: What is the lead time for this part?
A: Typically 3–7 business days for in-stock units. Contact us for urgent requirements.
Q: Is a new or refurbished unit available?
A: Konmask offers both new (factory-sealed) and tested-surplus units. Condition is clearly stated on the quotation.
