API PS-3306D-E – High-Performance AC Servo Drive | PS-3000 Series
Engineering Background
The API PS-3306D-E is a professional-grade AC servo amplifier engineered by API (Advanced Power Integrated) for demanding industrial motion control applications. Designed to deliver precise torque, velocity, and position control, this unit is a trusted solution across semiconductor, packaging, CNC, and robotics sectors where accuracy and reliability are non-negotiable.
Product Positioning
As part of the API PS-3000 Series servo platform, the PS-3306D-E targets OEM machine builders and system integrators who require a compact, high-response servo amplifier with robust I/O compatibility and deterministic control performance. Konmask.com supplies this unit as a verified OEM-sourced component with full traceability.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Model | PS-3306D-E |
| Brand / Manufacturer | API (Advanced Power Integrated) |
| Series | PS-3000 |
| Drive Type | AC Servo Amplifier |
| Control Modes | Position / Velocity / Torque |
| Input Voltage | Single / Three-Phase AC (refer to nameplate) |
| Output Current | 6A continuous (rated) |
| Encoder Interface | Incremental / Absolute encoder compatible |
| Communication | RS-232 / RS-485 (model dependent) |
| Protection Class | Overcurrent, Overvoltage, Undervoltage, Overtemperature, Encoder fault |
| Cooling Method | Forced air cooling |
| Weight | 1.36 kg |
| Compliance | CE / RoHS |
Proven Application Environments
- CNC Machining Centers – Spindle and axis servo control requiring sub-micron repeatability
- Semiconductor Equipment – Wafer handling and pick-and-place systems demanding ultra-low vibration
- Packaging Machinery – High-speed indexing and registration with synchronous multi-axis coordination
- Robotics & Articulated Arms – Joint torque control with real-time feedback loop closure
- Textile & Printing Machines – Tension control and web guiding with dynamic load compensation
- Medical Devices – Precision dosing pumps and surgical positioning systems
Engineering Advantages
- High Bandwidth Current Loop – Enables fast dynamic response for aggressive motion profiles
- Auto-Tuning Algorithm – Reduces commissioning time; adapts gain parameters to load inertia automatically
- Multi-Mode Operation – Seamlessly switchable between position, velocity, and torque control via parameter setting
- Compact Form Factor – Space-efficient design suitable for dense control cabinet layouts
- Comprehensive Fault Diagnostics – Onboard LED/display with fault code readout for rapid field troubleshooting
- Wide Motor Compatibility – Supports API servo motor series; adaptable to third-party motors with encoder re-mapping
System Architecture & Signal Flow
The PS-3306D-E operates on a closed-loop cascade control architecture:
- Command Input – Pulse/direction, ±10V analog, or serial command received from PLC/CNC controller
- Position Loop – Compares encoder feedback to commanded position; generates velocity reference
- Velocity Loop – PI controller regulates motor speed; outputs torque (current) reference
- Current Loop – High-frequency PWM switching controls phase currents to servo motor windings
- Feedback Path – Encoder signals (A/B/Z or serial absolute) returned to drive for real-time correction
This architecture ensures deterministic, low-latency response across all operating conditions.
Sourcing & Quality Verification
- ✅ OEM-Sourced – Units procured directly from authorized API distribution channels
- ✅ Functional Inspection – Each unit undergoes power-on verification and parameter readback prior to shipment
- ✅ Traceability – Serial number and date code recorded; documentation available on request
- ✅ Packaging – Anti-static ESD bag + foam-lined carton; meets IEC 61340-5-1 handling standards
- ✅ Warranty – 12-month limited warranty against manufacturing defects
Procurement Process
- Confirm Compatibility – Verify motor model, encoder type, and bus voltage against your system BOM
- Request Quote – Contact support@konmask.com for volume pricing, lead time, and datasheet
- Place Order – Purchase directly via Konmask.com; secure checkout with HKD / USD / CNY accepted
- Shipping – DHL / FedEx / SF Express; typical transit 3–7 business days internationally
- After-Sales – Technical support available via email or WhatsApp: +0086 19859288691
Technical FAQ
Q: Is the PS-3306D-E compatible with third-party servo motors?
A: Yes, with appropriate encoder signal mapping and parameter configuration. Contact our engineers for compatibility assessment.
Q: What communication protocol does this drive support?
A: The PS-3306D-E supports RS-232/RS-485 serial communication. Pulse/direction and analog command inputs are also supported for PLC integration.
Q: Can I use this drive in a multi-axis system?
A: Yes. Multiple PS-3306D-E units can be coordinated via a master PLC or motion controller using synchronized pulse commands or fieldbus.
Q: What is the lead time for this product?
A: In-stock units ship within 1–2 business days. For bulk orders, please contact us for confirmed lead time.
Q: Do you provide the original API datasheet and wiring diagram?
A: Yes. Full technical documentation is provided with every order. Pre-sale copies available upon request.
