Wafer Handling & Process Chamber Solution – Applied Materials 0022-44800 | Lift Assembly Series
Where This Product Is Used
The Applied Materials 0022-44800 Lift Assembly (cross-reference: 03112-LA24-BLC1 / 603625-102A) is a precision mechanical sub-assembly designed for wafer lift and transfer operations inside Applied Materials process chambers. It is commonly deployed in the following environments:
- CVD / PECVD Systems – Centura, Producer, and P5000 platforms requiring repeatable wafer placement on susceptors
- PVD / Sputter Systems – Endura platform wafer lift mechanisms for target-to-wafer gap control
- Etch Systems – DPS and MxP chamber wafer lift pins requiring precise vertical actuation
- 300 mm & 200 mm Fab Lines – High-volume production fabs running 24/7 where MTBF and part interchangeability are critical
- R&D & Pilot Lines – Process development labs requiring OEM-spec components for process repeatability
Technical Specifications
| Primary Part Number | 0022-44800 |
| Cross-Reference PN 1 | 03112-LA24-BLC1 |
| Cross-Reference PN 2 | 603625-102A |
| Assembly Type | Lift Assembly (LIFT ASSY) |
| OEM / Manufacturer | Applied Materials (AMAT) |
| Compatible Platforms | Centura, Endura, Producer, P5000, DPS, MxP |
| Wafer Size Compatibility | 200 mm / 300 mm (verify with chamber config) |
| Weight | 2,600 g (approx.) |
| Condition | New / Refurbished / Used — specify at inquiry |
| Lead Time | Contact for availability |
Why Engineers Specify This Model
- OEM Part Number Traceability – Three cross-referenced AMAT part numbers ensure correct BOM matching and procurement accuracy
- Precision Actuation – Engineered to maintain sub-millimeter wafer placement repeatability, critical for process uniformity
- Drop-In Replacement – Designed to fit existing chamber hardware without modification, minimizing downtime during PM cycles
- Material Compatibility – Constructed with process-compatible materials suitable for high-temperature and corrosive gas environments
- Reduced MTTR – Stocked as a complete assembly to eliminate field-level sub-component sourcing delays
Complete System Bill of Materials
This Lift Assembly is typically used alongside the following components in a complete chamber rebuild or PM kit:
- Lift Pin Set (ceramic / quartz, chamber-specific)
- Lift Pin Guide / Bushing Assembly
- Bellows Assembly (if pneumatic actuation)
- O-Ring Kit (chamber base flange)
- Susceptor / Heater Assembly
- Chamber Liner / Shield Set
- Actuator / Pneumatic Cylinder (platform-dependent)
Contact [email protected] for a complete PM kit quote.
Compliance & Industry Standards
- Designed and manufactured to SEMI S2 environmental, health, and safety guidelines
- Compatible with SEMI E1.9 mechanical interface standards for wafer handling
- Suitable for use in ISO Class 1–5 cleanroom environments
- RoHS-compliant materials available upon request
- Full material certification (CoC / CoO) available for regulated fab procurement
Quality Assurance & Sourcing
At Konmask.com, every Applied Materials spare part undergoes a structured sourcing and inspection process:
- Parts sourced from authorized OEM channels or verified surplus with full traceability documentation
- Visual and dimensional inspection prior to shipment
- Secure anti-static packaging with part number labeling for cleanroom-safe delivery
- Certificate of Conformance (CoC) provided upon request
- Serialized inventory tracking for lot traceability
How to Source This Part
- Submit an RFQ – Email [email protected] with your part number, quantity, and required condition (new / refurb / used)
- Receive a Quote – Our team will confirm availability, lead time, and pricing within 1 business day
- Place Your Order – Secure checkout via this product page or via PO for B2B accounts
- Shipping – Worldwide export from China; DHL / FedEx / UPS express options available; EXW / CIF / DAP Incoterms supported
- After-Sales Support – Technical support available for installation verification and compatibility questions
Application-Specific FAQ
Q: Is part number 03112-LA24-BLC1 the same as 0022-44800?
A: Yes. These are cross-referenced Applied Materials part numbers for the same Lift Assembly. 603625-102A is an additional revision/sub-assembly reference. Always verify against your chamber’s BOM before ordering.
Q: Which Applied Materials platforms use this Lift Assembly?
A: This assembly is associated with Centura and related AMAT platforms. Please provide your chamber model and configuration when submitting an RFQ for exact compatibility confirmation.
Q: Can this part be used in a 300 mm fab?
A: Compatibility depends on the specific chamber configuration. Contact us with your tool ID and chamber serial number for verification.
Q: Do you offer refurbished units?
A: Yes. Refurbished units are available at reduced cost with inspection reports. Specify your preference in the RFQ.
Q: What is the lead time?
A: Lead time varies by stock status. In-stock units ship within 2–5 business days. Contact us for current availability.
