Applied Materials 0100-AE108 Cardcage Assembly | Replacement, Equivalent & Selection Guide
The Applied Materials 0100-AE108 is a SAM (System Assembly Module) Cardcage Assembly used in semiconductor wafer processing equipment. This guide helps engineers identify compatible replacements, equivalent part numbers, and make informed sourcing decisions for maintenance, upgrade, or emergency replacement scenarios.
Technical Specifications
- Manufacturer: Applied Materials (AMAT)
- Primary Part Number: 0100-AE108
- Cross-Reference P/Ns: 0190-35208 / 0100-35054 / 0063451100048
- Assembly Designation: TLC511 F SAM
- Module Type: Cardcage Assembly (CARDCAGE ASSY MODULE)
- Weight: Approx. 2.6 kg
- Origin: United States
- Condition Available: New OEM / Refurbished / Tested Used
Compatible Replacement & Equivalent Models
The following part numbers are known cross-references or functional equivalents for the 0100-AE108 SAM Cardcage Assembly:
- 0190-35208 — Direct AMAT cross-reference assembly variant
- 0100-35054 — Alternate AMAT assembly revision
- 0063451100048 — OEM sub-assembly reference number
- TLC511 F SAM — Internal AMAT system designation
Always verify firmware revision, connector pinout, and backplane compatibility before substituting. Contact our engineering team for cross-reference validation.
Why Choose the Original Model
- OEM Precision: Designed and validated specifically for Applied Materials process chambers — no adaptation required.
- Firmware Compatibility: Factory-matched firmware ensures seamless integration with existing AMAT control systems.
- Reduced Downtime Risk: Eliminates compatibility guesswork that can extend unplanned maintenance windows.
- Warranty Integrity: Using OEM parts preserves equipment service agreements and audit trails.
- Long-Term Availability: Konmask maintains stock of legacy AMAT modules to support older fab equipment still in production.
Typical Applications
- CVD (Chemical Vapor Deposition) system control backplanes
- Etch chamber process controller card racks
- PVD (Physical Vapor Deposition) equipment module assemblies
- Semiconductor fab equipment maintenance and spare parts programs
- Legacy AMAT platform upgrades and refurbishment projects
System Compatibility
The 0100-AE108 SAM Cardcage Assembly is compatible with the following Applied Materials platforms (verify with your system BOM before ordering):
- Applied Materials Centura® platform systems
- Applied Materials Producer® CVD systems
- Applied Materials Endura® PVD platforms
- Applied Materials DPS (Decoupled Plasma Source) etch systems
- Legacy TLC-series controller architectures
Selection Guide
Use the following criteria to confirm the correct part for your application:
- Step 1 — Identify your system: Confirm the AMAT platform model and chamber type from your equipment nameplate or BOM.
- Step 2 — Match the P/N: Cross-reference 0100-AE108 against your system’s spare parts list. Acceptable alternates: 0190-35208, 0100-35054.
- Step 3 — Verify revision: Check PCB revision and firmware version compatibility with your system software release.
- Step 4 — Confirm connector type: Validate backplane connector configuration matches your cardcage slot specification.
- Step 5 — Request a quote: Contact Konmask with your system serial number for final compatibility confirmation and pricing.
Quality Assurance & Sourcing
- All modules are inspected upon receipt and tested for electrical continuity and functional integrity.
- Refurbished units undergo full board-level cleaning, component inspection, and functional burn-in testing.
- Traceability documentation available upon request (lot records, test reports).
- Sourced from certified industrial surplus channels, OEM overstock, and decommissioned fab equipment.
- Packaging: ESD-safe anti-static bags with foam cushioning for international shipping.
How to Order
- Email: [email protected] with your P/N, quantity, and required condition (new / refurbished / tested used).
- Phone/WhatsApp: +0086 19859288691 — available for urgent sourcing inquiries.
- Online: Add to cart or use the quote request form on this page.
- Lead time: In-stock items ship within 2–5 business days. Special-order items: 7–21 days.
- Export documentation (commercial invoice, packing list, COO) provided for international orders.
Replacement & Compatibility FAQ
Q: Can 0190-35208 directly replace 0100-AE108?
A: In most configurations, yes — both are AMAT SAM cardcage assemblies. However, firmware revision and backplane slot position must be verified before installation.
Q: Is a refurbished unit reliable for production use?
A: Yes, when properly tested. Konmask refurbished modules pass functional burn-in and are backed by a 90-day replacement warranty.
Q: Do you provide installation support?
A: We provide technical documentation and remote guidance. On-site installation support can be arranged through our partner network.
Q: What if my exact P/N is not in stock?
A: Contact us — we can source equivalent assemblies or arrange expedited procurement from our global supplier network.
Q: Can this module be repaired rather than replaced?
A: Board-level repair is available for select failures. Submit your module for evaluation and we will provide a repair vs. replace recommendation.
