Applied Materials 0100-01362 / 0100-01864 / 0100-77063 PCB Assembly – SDC-2.2 / SDC-2/1 Series
When a critical PCB assembly fails inside an Applied Materials semiconductor processing system, the entire production line comes to a halt. Wafer throughput drops to zero, cleanroom idle time accumulates, and every hour of unplanned downtime translates directly into six-figure losses. The Applied Materials 0100-01362 / 0100-01864 / 0100-77063 PCB Assembly is the precision-engineered board that keeps your SDC-2 series controller operational — and without it, there is no workaround.
Within the SDC-2.2 and SDC-2/1 controller family, this PCB assembly occupies a central role in signal processing and power distribution for Applied Materials’ deposition and etch platforms. Applied Materials remains one of the world’s largest suppliers of semiconductor fabrication equipment, with its SDC-2 series deployed across leading fabs in Asia, North America, and Europe. Sourcing a verified replacement board — cross-referenced across part numbers 0100-01362, 0100-01864, and 0100-77063 — is essential for maintaining OEM-level system integrity.
Technical Specifications
- Manufacturer: Applied Materials (AMAT)
- Part Numbers: 0100-01362 / 0100-01864 / 0100-77063
- Compatible Series: SDC-2.2, SDC-2/1
- Assembly Type: PCB Assembly (PCBA)
- Weight: 2,600 g (approx.)
- Application: Semiconductor process equipment controller board
- Condition: New / Refurbished / Tested (specify on inquiry)
Key Features & Benefits
- ✅ Multi-PN Cross-Reference: Covers 0100-01362, 0100-01864, and 0100-77063 — one board, three part numbers, zero compatibility guesswork.
- ✅ OEM-Grade Quality: Sourced from verified supply chains with full traceability documentation available on request.
- ✅ Drop-In Replacement: Designed for direct installation into SDC-2.2 and SDC-2/1 controller chassis without modification.
- ✅ Rapid Dispatch: In-stock units ship within 24–48 hours; expedited freight options available for critical downtime situations.
- ✅ Pre-Shipment Testing: Each board undergoes functional verification before dispatch to minimize field rejection risk.
- ✅ Global Export Compliance: Properly documented for international customs clearance to major semiconductor manufacturing regions.
Industry & Equipment Applications
- Semiconductor Fabrication (Fabs): CVD, PVD, and etch tool maintenance for 200mm and 300mm wafer lines.
- Flat Panel Display Manufacturing: Applied Materials PECVD systems used in TFT-LCD and OLED production.
- Solar Cell Production: Thin-film deposition equipment utilizing SDC-2 series controllers.
- Research & Development Labs: University and corporate R&D facilities running legacy Applied Materials platforms.
- Equipment Refurbishers & Brokers: Secondary market tool restoration requiring verified OEM-compatible boards.
System Integration & Compatible Parts
This PCB assembly is designed for integration within the Applied Materials SDC-2 controller ecosystem. When planning a repair or preventive maintenance, consider sourcing the following complementary components:
- SDC-2 series power supply modules
- Applied Materials backplane and interconnect boards
- SDC-2/1 and SDC-2.2 chassis frame assemblies
- Associated ribbon cables and I/O interface boards
Contact our technical team to confirm compatibility with your specific tool configuration and software revision.
Our Quality Assurance Process
- Source Verification: All units are traced to documented supply channels — no grey-market or unverified sources.
- Visual Inspection: PCB surface, solder joints, connectors, and component seating are inspected under magnification.
- Functional Test: Boards are powered and tested against known-good reference parameters where applicable.
- ESD-Safe Packaging: Units are packed in anti-static bags with foam cushioning and moisture barrier packaging for safe international transit.
- Documentation: Certificate of conformance and test report available upon request.
How to Order
- Submit your inquiry via the Contact / RFQ form on this page.
- Provide your tool model, current part number, and required quantity.
- Our team will confirm availability, lead time, and pricing within 1 business day.
- Upon agreement, we issue a proforma invoice and arrange shipment via your preferred freight method.
- Tracking information and export documents are provided upon dispatch.
Why Choose Konmask.com?
- 🔧 Industrial Automation Specialists: We focus exclusively on industrial control and semiconductor equipment components — not a general electronics marketplace.
- 🌐 Global B2B Export Experience: Serving procurement teams, maintenance engineers, and equipment brokers across 40+ countries.
- 📦 Flexible MOQ: Single-unit orders accepted — no minimum order quantity pressure.
- 🤝 Dedicated Account Support: One point of contact from inquiry to delivery.
- 📋 Full Documentation: Commercial invoice, packing list, COC, and test reports provided for every shipment.
Frequently Asked Questions
Q: Are part numbers 0100-01362, 0100-01864, and 0100-77063 fully interchangeable?
A: These three part numbers are cross-referenced to the same physical PCB assembly used in SDC-2.2 and SDC-2/1 controllers. Please confirm your tool’s revision with our team before ordering to ensure exact compatibility.
Q: Do you offer refurbished units in addition to new stock?
A: Yes. We can supply new, refurbished-tested, and as-removed units depending on availability and your budget requirements. Condition is clearly stated on the quotation.
Q: What is the lead time for this PCB assembly?
A: In-stock units ship within 24–48 hours. If not in stock, typical lead time is 2–4 weeks depending on sourcing. Expedited options are available for critical downtime situations.
Q: Can you provide a warranty?
A: Yes. New units carry a standard 90-day warranty against manufacturing defects. Refurbished units carry a 30-day tested warranty. Terms are specified on the quotation.
Q: Do you ship internationally?
A: Yes. We export to North America, Europe, Southeast Asia, the Middle East, and beyond. All shipments include full export documentation compliant with international trade regulations.
