AVAGO AFCT-5715APZ 1.25Gbps Multimode SFP Fiber Transceiver | Replacement, Equivalent & Selection Guide
The AVAGO AFCT-5715APZ is a 1.25Gbps multimode SFP (Small Form-factor Pluggable) fiber optic transceiver designed for Gigabit Ethernet and industrial data communication applications. Widely deployed in automation networks, industrial switches, and PLC communication backbones, this module delivers reliable optical performance in demanding environments.
Technical Specifications
- Part Number / SKU: AFCT-5715APZ
- Manufacturer: AVAGO Technologies (now Broadcom)
- Form Factor: SFP (LC Duplex)
- Data Rate: 1.25 Gbps (Gigabit Ethernet)
- Fiber Type: Multimode Fiber (MMF)
- Wavelength: 850 nm (VCSEL)
- Typical Reach: Up to 550 m (OM2) / 300 m (OM1)
- Connector: LC Duplex
- Operating Temperature: 0°C to +70°C (Commercial)
- Supply Voltage: 3.3V
- Transmit Power: -9.5 to -3 dBm (typical)
- Receive Sensitivity: ≤ -17 dBm
- Standards Compliance: IEEE 802.3z 1000BASE-SX, SFP MSA
- RoHS Compliant: Yes
- Weight: ~100 g (with packaging)
Compatible Replacement & Equivalent Models
The following modules are functionally equivalent or drop-in replacements for the AFCT-5715APZ. Always verify host system compatibility before substitution:
- AVAGO AFCT-5715ALZ — Extended temperature variant (-40°C to +85°C)
- AVAGO AFCT-5715PZ — Standard commercial grade equivalent
- Finisar FTLF8524P2BNV — 1.25G 850nm MMF SFP, LC duplex, compatible replacement
- Cisco GLC-SX-MMD — 1000BASE-SX SFP, DOM-enabled, widely used equivalent
- HP / HPE J4858C — 1000BASE-SX SFP, multimode, LC connector
- Intel E10GSFPSR — Compatible in select industrial switch platforms
- Generic / Third-party 1000BASE-SX SFP — Verify MSA compliance and host lock-out policy
Note: Third-party replacements may require disabling vendor lock-out (e.g., Cisco “service unsupported-transceiver” command). Contact us for compatibility verification.
Why Choose the Original AFCT-5715APZ
- Proven Reliability: AVAGO/Broadcom optical components are industry-standard in automation and telecom infrastructure.
- Guaranteed Compatibility: Original modules eliminate firmware rejection risks in Cisco, HP, and industrial switch platforms.
- Stable Supply Chain: Sourced from authorized distributors and verified secondary market channels.
- Warranty & Traceability: Full date code and lot traceability available upon request.
- Long Service Life: VCSEL-based design ensures consistent optical output over extended operational periods.
Typical Applications
- Industrial Ethernet backbone links in PLC and DCS networks
- Factory automation fiber uplinks (PROFINET, EtherNet/IP)
- Managed industrial switches (Hirschmann, Moxa, Siemens SCALANCE)
- Data center top-of-rack 1GbE fiber connections
- Building automation and SCADA communication networks
- Campus network fiber distribution layer
- Surveillance and security network fiber segments
System Compatibility
The AFCT-5715APZ is compatible with SFP slots on the following platforms (non-exhaustive):
- Cisco: Catalyst 2960/3560/3750/4500/6500 series; ASR/ISR routers
- HP/HPE: ProCurve / Aruba 2530, 2920, 5400R series
- Siemens: SCALANCE X-300/X-400 series industrial switches
- Moxa: EDS-500/600 series managed switches
- Hirschmann: MACH / RS series industrial switches
- Allen-Bradley / Rockwell: Stratix 5700/8000 series
- Juniper: EX2200/EX3300/EX4200 series
Always confirm SFP slot type (SFP vs SFP+) and host firmware version before installation.
Selection Guide
Use the following criteria to confirm the AFCT-5715APZ is the right module for your application:
- Data Rate: Required ≤ 1.25 Gbps → ✅ AFCT-5715APZ suitable
- Fiber Type: Multimode (OM1/OM2) available → ✅ Suitable; for singlemode, select AFCT-5715SMZ or equivalent SMF variant
- Link Distance: ≤ 550 m → ✅ Suitable; >550 m requires singlemode (1310nm/1550nm) SFP
- Temperature Range: 0–70°C → ✅ Standard; for -40 to +85°C, select AFCT-5715ALZ (industrial temp)
- Host Compatibility: Verify SFP MSA compliance and vendor lock-out policy of your switch/router
- Connector: LC Duplex required → ✅ Confirmed
- DOM Support: Not required for basic links; if DOM needed, select DOM-enabled equivalent
Quality Assurance & Sourcing
- Source: Authorized distributors and verified excess inventory channels
- Inspection: Each unit visually inspected; optical power tested where applicable
- Authenticity: Date code and manufacturer markings verified; counterfeit screening applied
- Packaging: Anti-static ESD bag + protective dust caps; original or equivalent OEM packaging
- Documentation: Certificate of Conformance (CoC) available on request
- Returns: 30-day return policy for unused, unopened units
How to Order
- SKU: AFCT-5715APZ
- MOQ: 1 piece (bulk pricing available for qty ≥ 10)
- Lead Time: In-stock items ship within 1–3 business days; contact us for large quantity lead times
- Payment: T/T, PayPal, credit card via Shopify Payments
- Shipping: DHL / FedEx / UPS international express; local courier for domestic CN orders
- Custom Quote: Email support@konmask.com with quantity and delivery requirements
Replacement & Compatibility FAQ
Q: Can I use a third-party SFP instead of the AFCT-5715APZ?
A: Yes, in most cases. Ensure the replacement is 1000BASE-SX, LC duplex, 850nm MMF, and MSA-compliant. Some Cisco/HP platforms may require a CLI command to allow third-party modules.
Q: What is the difference between AFCT-5715APZ and AFCT-5715ALZ?
A: The ALZ variant supports extended industrial temperature (-40°C to +85°C), while the APZ is rated for commercial range (0°C to +70°C). Electrically and optically identical.
Q: Is the AFCT-5715APZ compatible with SFP+ slots?
A: SFP+ slots are backward-compatible with SFP modules in most platforms. Verify with your switch vendor documentation.
Q: Do you provide test reports or CoC?
A: Yes. Certificate of Conformance and basic optical test data are available upon request for orders ≥ 5 pcs.
Q: Can I return the module if it doesn’t work in my system?
A: Yes, within 30 days for unused/unopened units. Contact support@konmask.com before returning.
