B&R X67DO1332 Digital Output Module | Replacement, Equivalent & Selection Guide
The B&R X67DO1332 is a high-performance digital output module designed for the X67 I/O system, engineered for demanding industrial automation environments. This page provides full technical specifications, compatible replacement options, application guidance, and sourcing information to help engineers and procurement teams make confident selection decisions.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | X67DO1332 |
| Manufacturer | B&R (Bernecker + Rainer) |
| Module Type | Digital Output Module |
| I/O System | X67 (IP67-rated field I/O) |
| Output Channels | 12 × digital outputs |
| Output Type | Transistor (PNP, sourcing) |
| Rated Output Current | 0.5 A per channel |
| Supply Voltage | 24 V DC (18–30 V DC) |
| Protection Rating | IP67 |
| Communication | POWERLINK / X2X Link |
| Mounting | Direct field mounting, M12 connectors |
| Operating Temperature | -25 °C to +60 °C |
| Weight | Approx. 400 g |
| Certifications | CE, UL (refer to B&R datasheet for full list) |
Note: Always verify specifications against the official B&R datasheet before final design-in.
Compatible Replacement & Equivalent Models
When the X67DO1332 is unavailable or a cost-optimized alternative is required, the following models may serve as functional equivalents. Compatibility must be validated against your specific system configuration.
| Model | Manufacturer | Output Channels | Output Type | Notes |
|---|---|---|---|---|
| X67DO1322 | B&R | 12 DO | PNP | Lower current rating per channel; verify load requirements |
| X67DO1372 | B&R | 12 DO | PNP | Higher current variant; drop-in compatible in most X67 racks |
| X20DO9322 | B&R | 12 DO | PNP | X20 system equivalent; requires X20 backplane |
| ET200SP DQ 8×24VDC/0.5A | Siemens | 8 DO | PNP | Cross-brand alternative; requires gateway or re-engineering |
| NX-OD3256 | OMRON | 32 DO | PNP | Higher density; suitable for redesign projects |
Important: Cross-brand replacements require engineering review of bus protocol, connector pinout, and software configuration. Konmask recommends using genuine B&R modules for production-critical systems.
Why Choose the Original Model
- Seamless Integration: Native X2X Link and POWERLINK support ensures plug-and-play compatibility within B&R X67 systems without additional configuration.
- IP67 Field-Hardened Design: Fully sealed for direct machine mounting in wet, dusty, or vibration-prone environments — no control cabinet required.
- Proven Reliability: Designed and validated to B&R’s industrial lifecycle standards, with long-term availability and firmware support.
- Diagnostic Transparency: Per-channel diagnostics accessible via Automation Studio reduce downtime and simplify fault isolation.
- Regulatory Compliance: CE and UL certifications support global machine builder requirements.
Typical Applications
- Machine tool and CNC automation — controlling solenoids, actuators, and indicator lights
- Packaging and conveyor systems — valve and motor starter control at field level
- Automotive assembly lines — distributed I/O for body-in-white and paint shop equipment
- Food & beverage processing — IP67 protection for washdown environments
- Intralogistics and AGV systems — decentralized output control near drive units
- Press and forming machinery — high-cycle digital output switching
System Compatibility
The X67DO1332 is designed exclusively for the B&R X67 I/O system and is compatible with the following:
- Controllers: B&R APC910, APC2100, CP series, and all X20 CPUs with X2X Link master
- Bus Systems: POWERLINK (V1/V2), X2X Link
- Software: B&R Automation Studio 4.x and later
- Power Supply Modules: X67PS1300, X67PS2100 series
- Mounting: Compatible with all X67 field bus modules and X67 bus controllers
Not compatible with X20 backplanes or third-party PROFIBUS/EtherNet/IP systems without a protocol gateway.
Selection Guide
Use the following criteria to confirm the X67DO1332 is the right module for your application:
- Output count: Do you need exactly 12 digital outputs at field level? If fewer outputs suffice, consider X67DO0822 (8 DO). If more are needed, evaluate X67DO1372 or a multi-module configuration.
- Load current: Each channel supports up to 0.5 A. For loads exceeding this, use an interposing relay or select a higher-current variant.
- Environment: IP67 rating is mandatory for direct machine mounting. For cabinet-mounted applications, X20 series modules may offer a more cost-effective solution.
- Bus protocol: Confirm your controller supports X2X Link or POWERLINK. Legacy PROFIBUS systems require a gateway module.
- Firmware version: Verify Automation Studio project compatibility before ordering a replacement module.
Quality Assurance & Sourcing
- Genuine Parts: All B&R modules supplied by Konmask.com are sourced from authorized distributors or verified surplus channels with full traceability.
- Inspection: Units undergo visual inspection, label verification, and where applicable, functional testing prior to dispatch.
- Packaging: Original or equivalent ESD-safe packaging to prevent transit damage.
- Documentation: CE declarations and test reports available upon request.
- Warranty: 12-month warranty against manufacturing defects. Contact support for terms.
How to Order
- Confirm the exact model number: X67DO1332 (check the module label or B&R project configuration).
- Specify quantity and required delivery timeline.
- Contact Konmask via the form below or email [email protected] for stock confirmation and lead time.
- For urgent requirements, call +0086 19859288691 for same-day response.
- Add to cart and proceed to checkout, or request a formal quotation for B2B procurement.
Replacement & Compatibility FAQ
Q: Can I replace the X67DO1332 with an X67DO1322 directly?
A: In most cases yes, but the X67DO1322 has a lower per-channel current rating. Verify your load current before substituting.
Q: Is the X67DO1332 compatible with Siemens S7 controllers?
A: No. The X67DO1332 uses B&R’s proprietary X2X Link/POWERLINK protocol. A protocol gateway is required for use with Siemens systems, which is generally not recommended for production environments.
Q: Can I use this module in a cabinet-mounted application?
A: Yes, though the IP67 rating is optimized for field mounting. For cabinet use, B&R X20 series modules may be more cost-effective.
Q: What is the lead time for the X67DO1332?
A: Lead time varies by stock availability. Contact Konmask for current inventory status. Expedited sourcing is available for urgent requirements.
Q: Do you supply refurbished or remanufactured units?
A: Konmask supplies genuine new and verified surplus units only. All surplus units are inspected and tested. Refurbished units are clearly labeled as such.
