B&R X20AO4622 Analog Output Module – X20 System
When an analog output module fails mid-process, the consequences cascade instantly: actuators freeze at their last commanded position, control loops open, and the entire production line grinds to an uncontrolled halt. In continuous-process industries — chemical dosing, pressure regulation, flow control — even a few minutes of uncontrolled output can mean scrapped batches, equipment damage, or safety shutdowns. The B&R X20AO4622 is the precision link between your PLC logic and the physical world, converting digital control commands into accurate, stable analog signals that drive your field devices with confidence.
Within B&R’s X20 System — one of the most modular and widely deployed PLC platforms in global industrial automation — the X20AO4622 occupies a critical position as a high-channel-density analog output module. The X20 System is trusted by machine builders and system integrators across Europe, Asia, and the Americas for its deterministic performance, compact form factor, and seamless integration with B&R’s Automation Studio engineering environment. The X20AO4622 brings that same engineering pedigree to analog signal generation, making it a go-to choice for OEMs and end-users who demand accuracy and reliability in demanding environments.
Technical Specifications
- Model: X20AO4622
- Brand: B&R (Bernecker + Rainer)
- Series: X20 System
- Module Type: Analog Output Module
- Number of Channels: 4 analog output channels
- Output Signal Type: Current / Voltage (refer to official B&R datasheet for exact range)
- Backplane Bus: X2X Link (B&R proprietary high-speed bus)
- Form Factor: X20 compact modular design
- Operating Temperature: Per B&R X20 System specification
- Certifications: CE, UL (refer to official B&R documentation)
- SKU / Part Number: X20AO4622
Note: All specifications are sourced from official B&R documentation. Konmask.com does not modify or fabricate technical parameters. For the complete and authoritative datasheet, please contact us or refer to the B&R official product page.
Key Features & Benefits
- 4-Channel Analog Output: Drive multiple field devices simultaneously from a single compact module, reducing panel space and wiring complexity.
- High Signal Accuracy: Delivers stable, repeatable analog output signals critical for closed-loop control applications such as PID regulation.
- X2X Link Integration: Communicates over B&R’s deterministic X2X Link bus, ensuring synchronized, real-time data exchange with the CPU module.
- Compact X20 Form Factor: Snap-on modular design allows fast installation, replacement, and system expansion without rewiring the entire panel.
- Wide Industry Compatibility: Suitable for use in machines across process, packaging, energy, and manufacturing sectors.
- Automation Studio Support: Fully configurable within B&R’s Automation Studio IDE, enabling rapid commissioning and diagnostics.
- Robust Industrial Design: Built to withstand the vibration, temperature variation, and EMI conditions typical of industrial environments.
Industry & Equipment Applications
- Process Industry: Chemical dosing systems, flow control valves, pressure regulators, and temperature control loops.
- Packaging Machinery: Speed reference signals for servo drives and VFDs in filling, sealing, and labeling machines.
- Energy & Power: Generator control panels, UPS systems, and renewable energy inverter interfaces.
- Food & Beverage: Hygienic process lines requiring precise flow and pressure analog control.
- Automotive Manufacturing: Robotic welding and assembly lines with analog-controlled actuators.
- Water Treatment: Pump speed control and chemical feed systems requiring 4–20 mA or 0–10 V signals.
- Printing & Converting: Tension control and web guiding systems with analog reference outputs.
System Integration & Compatible Parts
The X20AO4622 is designed to operate within the B&R X20 System ecosystem. Compatible and commonly paired components include:
- X20 CPU Modules: e.g., X20CP1584, X20CP3585 — the controller that drives the X20AO4622 via X2X Link
- X20 Bus Controllers: e.g., X20BC0083 — for remote I/O expansion over POWERLINK or other fieldbus protocols
- X20 Power Supply Modules: e.g., X20PS9400 — provides the 24 VDC supply rail for the X20 backplane
- X20 Analog Input Modules: e.g., X20AI4622 — for closed-loop feedback pairing with the AO4622 output
- X20 Digital I/O Modules: e.g., X20DI9371, X20DO9322 — for mixed signal architectures in the same rack
Contact Konmask.com for a full BOM review or system compatibility check before ordering.
Our Quality Assurance Process
At Konmask.com, every B&R X20AO4622 unit we supply goes through a rigorous sourcing and verification process before it reaches your facility:
- Authorized & Verified Supply Chain: We source exclusively from traceable, reputable channels to ensure genuine B&R components.
- Visual & Label Inspection: Each unit is inspected for physical integrity, correct labeling, and authentic B&R markings.
- Functional Verification: Where applicable, modules are bench-tested to confirm basic operational status prior to shipment.
- Secure Anti-Static Packaging: All modules are shipped in ESD-safe packaging with appropriate cushioning to prevent transit damage.
- Documentation Provided: Certificate of conformity and packing list included with every shipment.
How to Order
- Submit an Inquiry: Contact us via email at support@konmask.com or call +0086 19859288691 with your required quantity and delivery timeline.
- Receive a Quotation: Our team will respond within 1 business day with pricing, lead time, and availability confirmation.
- Order Confirmation: Review and approve the proforma invoice. We accept T/T (bank transfer), PayPal, and other agreed payment methods.
- Shipment & Tracking: Your order is dispatched with full tracking information via DHL, FedEx, or UPS — your choice.
- After-Sales Support: Our technical team remains available post-delivery for integration questions or warranty claims.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, and automation hardware — not a generalist marketplace.
- Global B2B Export Experience: We serve system integrators, OEMs, and MRO buyers across Southeast Asia, the Middle East, Europe, and beyond.
- Fast Response, Reliable Delivery: Inquiries answered within 24 hours; most in-stock items ship within 3–5 business days.
- Competitive Pricing: Direct sourcing relationships allow us to offer market-competitive pricing without compromising on authenticity.
- Technical Pre-Sales Support: Our engineers can assist with compatibility checks, system design reviews, and part substitution advice.
- Trusted by Engineers Worldwide: Repeat customers from manufacturing plants, system integrators, and maintenance teams across 30+ countries.
Frequently Asked Questions
Q1: Is the B&R X20AO4622 a current output or voltage output module?
A: The X20AO4622 supports analog output — please contact us or refer to the official B&R datasheet for the exact signal range (current/voltage). We can provide the datasheet upon request.
Q2: Can the X20AO4622 be used as a standalone module without a B&R CPU?
A: No. The X20AO4622 communicates via the X2X Link backplane bus and requires a compatible B&R X20 CPU or bus controller to operate. It cannot function independently.
Q3: What software is required to configure the X20AO4622?
A: Configuration is performed using B&R Automation Studio, the official engineering environment for all X20 System components. The module is recognized automatically when added to the hardware configuration.
Q4: Do you supply new or refurbished units?
A: We supply both new (factory-sealed) and tested-used units depending on availability. The condition is clearly stated in the quotation. All units pass our quality inspection before shipment.
Q5: What is the lead time for the X20AO4622?
A: Lead time depends on current stock levels. In-stock units typically ship within 3–5 business days. For out-of-stock items, lead time is quoted individually — usually 2–4 weeks. Contact us for real-time availability.
Q6: Can Konmask.com provide a warranty for this module?
A: Yes. We offer a standard 90-day warranty against defects in materials and workmanship. Extended warranty options are available upon request.
Q7: Do you accept returns?
A: Yes, within 30 days of receipt for items in original, uninstalled condition. Please contact support@konmask.com to initiate a return authorization.
