Process Control Backplane Solution – BACHMANN BS205 | BS Series
Where This Product Is Used
The BACHMANN BS205 Backplane is a core rack infrastructure component deployed across demanding industrial environments where signal integrity, modular expandability, and long-term reliability are non-negotiable. Typical deployment sites include:
- Wind & Hydropower Plants — Backbone of BACHMANN M1 controller racks managing turbine control, grid synchronization, and condition monitoring.
- Oil & Gas Processing Facilities — Installed in DCS/PLC cabinets for upstream SCADA, compressor control, and safety instrumented systems (SIS).
- Pulp & Paper / Chemical Plants — Supports multi-axis I/O expansion in continuous process lines requiring high channel density.
- Power Generation & Substation Automation — Used in IEC 61850-compliant protection and control panels.
- Marine & Offshore Platforms — Rack-mounted in vibration-resistant enclosures for propulsion and ballast control systems.
- OEM Machine Builders — Integrated into custom automation cabinets requiring standardized BACHMANN M1 module slots.
Technical Specifications
- Part Number: BS205
- Manufacturer: BACHMANN electronic GmbH
- Series: BS / M1 Rack System
- Form Factor: Backplane for BACHMANN M1 rack
- Compatible Modules: BACHMANN M1 series CPU, I/O, communication, and power supply modules
- Mounting: DIN rail / 19″ rack panel mount
- Weight: 400 g
- Operating Temperature: 0 °C to +55 °C (refer to BACHMANN datasheet for extended range options)
- Compliance: CE, UL (verify current certification status with datasheet)
Note: Full electrical specifications (bus width, slot count, backplane voltage rails) are available upon request or in the official BACHMANN BS205 datasheet.
Why Engineers Specify This Model
- Proven M1 Ecosystem Compatibility — Designed exclusively for BACHMANN M1 architecture; eliminates integration risk when expanding or replacing existing racks.
- High-Density I/O Backbone — Supports multiple module slots in a compact footprint, reducing cabinet space and wiring complexity.
- Long Service Life — BACHMANN’s industrial-grade PCB construction ensures reliable operation in thermally and electrically demanding environments.
- Simplified Maintenance — Modular slot design allows hot-swap-capable modules (where supported) without full system shutdown.
- Genuine OEM Part — Sourced from authorized BACHMANN distribution channels; not a third-party substitute.
Complete System Bill of Materials
The BS205 Backplane is typically ordered alongside the following BACHMANN M1 components to build a complete control rack:
- BACHMANN MPC240 / MPC265 — M1 CPU Module
- BACHMANN DIO232 / AIO288 — Digital/Analog I/O Modules
- BACHMANN NT255 — Power Supply Module
- BACHMANN CM202 — Communication Module (PROFIBUS / CANopen)
- BACHMANN RM240 — Rack Mount Frame
Contact [email protected] for bundle pricing or complete rack BOM assistance.
