Basler SIA1600-14FM – High-Resolution Line-Scan CCD Camera | SIA Series Platform
Engineering Background
The Basler SIA1600-14FM is a precision line-scan CCD camera engineered for demanding industrial machine vision applications. Built on Basler’s proven SIA (Sensor Integration Architecture) platform, this camera delivers exceptional image fidelity across wide-format inspection fields — making it the preferred choice for flat-panel display inspection, PCB AOI, solar cell metrology, and continuous-web quality control.
Product Positioning
Part number 0000104714-07 represents a factory-configured variant of the SIA1600-14FM optimized for integration into custom OEM inspection frames. With a sensor active area of 400mm (L) × 190mm (W) and the KXL06050V-N2-S40 sensor assembly, this unit bridges the gap between standard area-scan cameras and full-width line-scan arrays — delivering both spatial coverage and pixel-level precision without compromise.
Complete Technical Specifications
| Manufacturer | Basler AG |
| Part Number | 0000104714-07 |
| Model | SIA1600-14FM |
| Sensor Assembly | KXL06050V-N2-S40 |
| Sensor Type | CCD (Charge-Coupled Device) |
| Active Sensor Area | 400mm (L) × 190mm (W) |
| Series / Platform | SIA Series |
| Interface | Camera Link / GigE (confirm with datasheet) |
| Pixel Depth | 14-bit |
| Mount | F-Mount (FM suffix) |
| Operating Temperature | 0°C to +50°C |
| Weight | 4,100 g |
| Condition | New / Surplus / Refurbished (specify on order) |
| Country of Origin | Germany |
Proven Application Environments
- Flat-panel display (FPD) surface defect inspection
- PCB automated optical inspection (AOI)
- Solar cell and photovoltaic module metrology
- Continuous-web printing and coating quality control
- Semiconductor wafer edge and surface scanning
- Large-format document and film digitization
- Glass and film substrate uniformity measurement
Engineering Advantages
- Wide-format coverage: 400mm active length eliminates the need for multi-camera stitching in most flat-panel inspection setups.
- 14-bit dynamic range: Captures subtle grayscale gradients critical for detecting micro-defects in transparent or reflective substrates.
- SIA platform modularity: Sensor assembly (KXL06050V-N2-S40) is field-replaceable, reducing total cost of ownership for long-lifecycle production lines.
- F-Mount compatibility: Broad lens ecosystem support — compatible with Nikon F, Schneider, and Rodenstock industrial optics.
- Basler SDK integration: Native support for pylon SDK, Basler BCON, and third-party frame grabbers via Camera Link.
System Architecture & Signal Flow
The SIA1600-14FM integrates directly into a standard machine vision pipeline:
- Illumination → Line or area light source (coaxial or structured)
- Optics → F-Mount telecentric or macro lens assembly
- SIA1600-14FM → CCD sensor captures image data at 14-bit depth
- Frame Grabber / Interface → Camera Link or GigE transmission to host PC
- Vision Software → Basler pylon, Halcon, VisionPro, or custom SDK
- Output → Pass/Fail signal, defect map, or measurement data to PLC/SCADA
Sourcing & Quality Verification
- All units sourced from authorized Basler distributors or verified OEM surplus channels.
- Each camera undergoes functional power-on verification and sensor integrity check prior to shipment.
- Original Basler serial number and firmware version preserved — no third-party modifications.
- Packaging: anti-static foam insert, original or equivalent protective case.
- Documentation: Basler datasheet, calibration record (if available), and Konmask inspection report included.
Procurement Process
- Submit inquiry with quantity, required condition (new/surplus/refurbished), and delivery timeline.
- Konmask confirms stock availability and provides formal quotation within 24 hours.
- Payment via T/T, PayPal, or trade assurance — net terms available for qualified accounts.
- Export documentation (commercial invoice, packing list, CO) provided for cross-border shipments.
- Lead time: 3–7 business days for in-stock units; 2–4 weeks for sourced/refurbished units.
Technical FAQ
Q: Is the KXL06050V-N2-S40 sensor assembly available separately?
A: Yes, contact us with your serial number for sensor-only replacement pricing.
Q: What frame grabber is recommended for Camera Link operation?
A: Basler recommends Matrox Solios, Euresys Grablink, or National Instruments PCIe-1433 for full Camera Link Base/Medium/Full configurations.
Q: Can this camera be integrated with Cognex or Keyence vision systems?
A: Yes, via Camera Link interface and standard GeniCam protocol. Custom integration support available upon request.
Q: What is the warranty policy?
A: 90-day functional warranty on all units. Extended warranty available — inquire at time of order.
Q: Do you provide export compliance documentation?
A: Yes. ECCN classification, HS code, and EAR99 determination available for all Basler products.
