Beckhoff CX1020-0000 Basic CPU Module | Replacement, Equivalent & Selection Guide
The Beckhoff CX1020-0000 is a DIN-rail-mounted Embedded PC serving as the central processing unit of the CX1020 series. Designed for demanding industrial automation environments, it runs Windows CE or Windows XP Embedded and integrates seamlessly with TwinCAT PLC/NC/CNC software. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers and procurement teams make informed decisions.
Technical Specifications
- Part Number: CX1020-0000
- Manufacturer: Beckhoff Automation
- Series: CX1020 Embedded PC
- CPU: Intel Celeron M ULV 600 MHz
- RAM: 256 MB DDR SDRAM (expandable)
- Storage: Compact Flash slot (CF card not included)
- Operating System: Windows CE 6.0 / Windows XP Embedded
- Software: TwinCAT 2 / TwinCAT 3 compatible
- Fieldbus: Via CX1020-N0xx extension modules (EtherCAT, PROFIBUS, CANopen, etc.)
- Power Supply: 24 V DC (via CX1100-0004 power supply unit)
- Dimensions (W×H×D): 58 mm × 100 mm × 91 mm
- Weight: approx. 360 g
- Operating Temperature: 0 °C … +55 °C
- Protection Class: IP 20
- Mounting: DIN rail (EN 60715)
- Certifications: CE, UL, ATEX (Zone 2)
Compatible Replacement & Equivalent Models
When the CX1020-0000 is discontinued or unavailable, the following Beckhoff models offer functional equivalence or direct upgrade paths:
- CX1020-0000 — Original model (this listing)
- CX1030-0000 — Higher-performance CPU (Intel Celeron M 1 GHz), pin-compatible housing
- CX5010-0110 — Next-generation Embedded PC, Intel Atom, TwinCAT 3 optimized
- CX5020-0110 — Dual-core Atom, recommended upgrade for CX1020 in new designs
- CX8090 — Compact controller with integrated EtherCAT master, suitable for smaller I/O counts
- CX9020-0100 — ARM Cortex-A8, ultra-compact, ideal for cost-sensitive replacements
Note: Always verify fieldbus extension module compatibility (CX1020-N0xx) when substituting with CX5xxx or CX9xxx series.
Why Choose the Original CX1020-0000
- Proven long-term stability in 24/7 industrial environments
- Native TwinCAT 2 support — no software migration required for legacy systems
- Modular CX1020 ecosystem: CPU, power supply, and fieldbus modules are independently replaceable
- Compact DIN-rail form factor minimizes cabinet space
- Wide fieldbus support via plug-in extension modules (EtherCAT, PROFIBUS DP, CANopen, DeviceNet, Interbus)
- Deterministic real-time performance for motion control and PLC tasks
Typical Applications
- Machine automation and motion control (CNC, robotics)
- Building automation and HVAC control systems
- Process control in chemical, pharmaceutical, and food industries
- Energy management and power distribution monitoring
- Test & measurement systems requiring real-time data acquisition
- Retrofit and modernization of legacy SIMATIC / Modicon PLC installations
System Compatibility
- Power Supply Module: CX1100-0004 (24 V DC, with integrated I/O terminal)
- Fieldbus Extensions: CX1020-N000 (EtherCAT), CX1020-N010 (PROFIBUS DP), CX1020-N030 (CANopen), CX1020-N040 (DeviceNet)
- I/O Terminals: All Beckhoff EL/KL series Bus Terminals
- HMI: CX1020-N060 (DVI/USB) for external monitor connection
- Software: TwinCAT 2.11 R3 and above; TwinCAT 3.1 (limited support)
- SCADA / HMI Integration: OPC UA, ADS protocol, Modbus TCP
Selection Guide
Use the table below to select the right CX-series CPU for your application:
- Legacy TwinCAT 2 system, no change needed: → CX1020-0000 (this model) or CX1030-0000
- New design, TwinCAT 3, moderate I/O: → CX5010-0110 or CX5020-0110
- Cost-sensitive, small I/O count (<128 points): → CX9020-0100 or CX8090
- High-performance motion (4+ axes): → CX5130-0120 or CX5140-0120 (Intel Core i7)
- Hazardous area (ATEX Zone 2): → CX1020-0000 (certified) — verify with Beckhoff for CX5xxx ATEX variants
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels
- Each module undergoes visual inspection and functional verification before shipment
- Original manufacturer packaging preserved where available
- Traceability documentation (batch/lot records) available on request
- Warranty: 12 months from shipment date against manufacturing defects
How to Order
- Confirm your required part number: CX1020-0000
- Specify quantity and required delivery timeline
- Contact us via email or phone for stock availability and lead time
- Receive proforma invoice → confirm payment → shipment with tracking
- For urgent requirements, expedited shipping options are available
Email: [email protected]
Phone / WhatsApp: +0086 19859288691
Website: https://Konmask.com
Replacement & Compatibility FAQ
Q: Can the CX1030-0000 directly replace the CX1020-0000?
A: Yes. The CX1030-0000 uses the same housing and connector layout. It offers a faster CPU (1 GHz vs 600 MHz) and is a drop-in hardware replacement. TwinCAT projects may require recompilation.
Q: Is the CX1020-0000 compatible with TwinCAT 3?
A: Limited support only. TwinCAT 3 requires a minimum of 1 GHz CPU. For full TwinCAT 3 functionality, upgrade to CX5010 or higher.
Q: What CF card is recommended for the CX1020-0000?
A: Beckhoff recommends industrial-grade CF cards (SLC NAND). Minimum 512 MB for Windows CE; 2 GB+ for Windows XP Embedded.
Q: Can I use third-party fieldbus modules with the CX1020-0000?
A: No. The CX1020 fieldbus slot is proprietary to Beckhoff CX1020-N0xx series modules.
Q: What is the end-of-life status of the CX1020-0000?
A: Beckhoff has announced the CX1020 series as discontinued. Spare parts and replacements remain available through authorized distributors and surplus suppliers like Konmask.com.
