Industrial Automation Power Solution – Beckhoff CX2030-0122 | CX2000 Series
Where This Product Is Used
The Beckhoff CX2030-0122 power supply module is purpose-built for demanding industrial control environments where stable, uninterrupted DC power delivery to an embedded PC is non-negotiable. Typical deployment scenarios include:
- Machine Tool & CNC Control Panels – Provides clean 24 VDC power to the CX2030 CPU module inside enclosed control cabinets, eliminating noise-induced faults on precision machining lines.
- Automotive Assembly Lines – Powers vision-inspection and robot-coordination controllers where power interruptions cause costly line stoppages.
- Packaging & Filling Machinery – Sustains high-cycle-rate PLC logic in continuous-operation environments with fluctuating load profiles.
- Building Automation & HVAC Systems – Supplies reliable power to BACnet/EtherCAT gateway controllers managing HVAC, lighting, and access control.
- Water & Wastewater Treatment Plants – Operates in harsh, humid environments where industrial-grade power conditioning is mandatory for SCADA front-ends.
- Renewable Energy & Grid-Edge Controllers – Feeds embedded PCs managing inverter control, data logging, and grid-synchronization tasks.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | CX2030-0122 |
| Series | CX2000 Embedded PC |
| Module Type | Power Supply Module |
| Input Voltage | 24 VDC (−15 % / +20 %) |
| Mounting | DIN rail (top-hat rail EN 60715) |
| Country of Origin | Germany |
| Weight | 560 g |
| Compatible CPU | CX2030 (Intel® Core™ i7, dual-core) |
| Interface | EtherCAT-ready via CX2000 system bus |
| Operating Temperature | 0 °C … +55 °C |
| Protection Class | IP20 |
Why Engineers Specify This Model
- Exact System Fit – Designed exclusively for the CX2000 platform; side-by-side blade connection eliminates external wiring between power supply and CPU.
- Wide Input Tolerance – Accepts 24 VDC with ±15–20 % tolerance, absorbing voltage sags common in large cabinet installations.
- Compact DIN-Rail Footprint – Minimizes panel real estate without sacrificing power headroom for high-performance i7 processing loads.
- Seamless TwinCAT 3 Integration – Works natively with Beckhoff’s TwinCAT 3 runtime; no additional power-management configuration required.
- Long Product Lifecycle – Beckhoff’s CX2000 series is supported with long-term availability commitments, reducing obsolescence risk for OEM designs.
Complete System Bill of Materials
For a fully operational CX2030-based control node, engineers typically specify:
- CX2030-0122 – Power supply module (this item)
- CX2030-0100 / -0110 – CPU module (Intel Core i7, dual-core)
- CX2100-0004 – Power supply unit (if separate PSU topology is used)
- CX2500-0030 – DVI/USB extended display interface
- EL1008 / EL2008 – EtherCAT digital I/O terminals
- CX2900-0102 – CFast card (OS image, 8 GB)
- ZK1090-3191-xxxx – EtherCAT drop cables
Contact [email protected] for bundle pricing on complete CX2000 system builds.
Compliance & Industry Standards
- CE Marking – EU Low Voltage Directive & EMC Directive
- UL Listed (industrial control equipment)
- EN 60068 – Environmental testing (vibration, shock, temperature)
- EN 61131-2 – Programmable controllers: equipment requirements
- RoHS 2 compliant
Quality Assurance & Sourcing
Every CX2030-0122 unit shipped by Konmask.com undergoes the following verification process:
- Visual inspection against Beckhoff OEM packaging and label standards
- Serial number traceability check against authorized distributor records
- Functional power-on test prior to dispatch
- Anti-static packaging with humidity indicator card
We source exclusively from authorized channels and verified surplus inventories. Counterfeit-free guarantee backed by our return policy.
How to Source This Part
- Add to Cart – Click the purchase button above for immediate checkout.
- Request a Quote – Email [email protected] with your required quantity and delivery timeline for volume pricing.
- Urgent Orders – Call or WhatsApp +0086 19859288691 for same-day quotation on expedited shipments.
- Datasheet & Drawings – Available on request; include your project reference number for faster processing.
Application-Specific FAQ
Q: Is CX2030-0122 compatible with the CX2020 CPU module?
A: No. The CX2030-0122 is mechanically and electrically matched to the CX2030 CPU. For CX2020, specify CX2020-0122.
Q: Can this module operate from an AC source?
A: No. It requires a 24 VDC supply. Use a Beckhoff CX2100-series or equivalent DIN-rail PSU to convert AC mains to 24 VDC.
Q: What is the maximum ambient operating temperature?
A: 0 °C to +55 °C in standard configuration. Consult Beckhoff for derating curves in high-altitude or restricted-airflow enclosures.
Q: Does Konmask.com provide a warranty?
A: Yes. We offer a 12-month warranty against manufacturing defects. Replacement or full refund within the warranty period.
Q: Can I order a single unit or only in bulk?
A: Single units are available. Volume discounts apply for orders of 5+ units.
