Honeywell CC-PDIL51 / CC-TDIL51 — 24VDC Digital Input Module | Experion PKS C300 DCS Platform
Engineering Background
The CC-PDIL51 (process module) and CC-TDIL51 (terminal assembly) form a matched pair within Honeywell’s Experion PKS Series C architecture. Designed for mission-critical process industries — refining, petrochemical, power generation, and pulp & paper — this module pair delivers deterministic 24 VDC digital input acquisition with channel-level isolation and full integration into the C300 Controller ecosystem.
Product Positioning
As a native Experion PKS I/O component, the CC-PDIL51/CC-TDIL51 eliminates the integration overhead of third-party I/O. Procurement engineers sourcing replacement or expansion modules for existing C300 cabinets will find this unit a direct, firmware-compatible drop-in with no re-engineering required.
Complete Technical Specifications
- Part Numbers: CC-PDIL51 (Process Module) + CC-TDIL51 (Terminal Assembly)
- Platform: Honeywell Experion PKS — Series C / C300 Controller
- Module Type: Digital Input (DI), 24 VDC
- Channel Count: 24 channels per module
- Input Voltage: 24 VDC nominal (18–30 VDC operating range)
- Isolation: Channel-to-channel and channel-to-bus optical isolation
- Input Impedance: ≥ 5 kΩ per channel
- ON State Threshold: ≥ 11 VDC
- OFF State Threshold: ≤ 5 VDC
- Update Rate: Configurable; default 100 ms scan cycle
- Diagnostics: Open-wire detection, module health, channel-level fault reporting
- Communication Bus: C300 FTE (Fault-Tolerant Ethernet) backplane
- Power Consumption: ≤ 3.5 W (module only)
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: −40 °C to +85 °C
- Relative Humidity: 5–95% RH, non-condensing
- Weight: Approx. 1,280 g (module + terminal assembly)
- Certifications: CE, UL 508, FM Class I Div 2, ATEX Zone 2
- Mounting: DIN rail / C300 I/O chassis slot
- Firmware Compatibility: Experion PKS R310 and above
Proven Application Environments
- Oil & Gas: Wellhead control panels, compressor station monitoring, pipeline ESD systems
- Refining & Petrochemical: Reactor interlock circuits, valve position feedback, pump status acquisition
- Power Generation: Turbine protection logic, boiler drum level switches, generator breaker status
- Pulp & Paper: Digester control, conveyor status, safety mat inputs
- Pharmaceutical: Clean-room door interlocks, CIP/SIP cycle monitoring, batch sequence triggers
- Water & Wastewater: Pump run/fail status, level switch inputs, remote RTU integration
Engineering Advantages
- Native C300 Integration: No gateway or protocol converter required; full FTE redundancy support
- Channel-Level Isolation: Prevents ground loops and cross-channel interference in noisy field environments
- Hot-Swap Capable: Module replacement without process shutdown when used in redundant I/O configuration
- Comprehensive Diagnostics: Open-wire and short-circuit detection surfaced directly in Experion Station HMI
- Compact Density: 24 DI channels per slot reduces cabinet footprint vs. legacy I/O architectures
- Long Service Life: Honeywell’s extended product lifecycle commitment supports 10+ year operational horizons
System Architecture & Signal Flow
Field devices (limit switches, proximity sensors, relay contacts) wire directly to the CC-TDIL51 terminal assembly via screw terminals. The terminal assembly mates with the CC-PDIL51 process module, which conditions and digitizes the 24 VDC signals. Conditioned data is transmitted over the C300 FTE backplane to the C300 Controller, where it is processed by control strategies built in Honeywell’s Control Builder engineering environment. Alarm and diagnostic data propagates to Experion Station operator consoles in real time.
Sourcing & Quality Verification
- All units sourced from authorized Honeywell distribution channels or verified surplus with full traceability documentation
- Pre-shipment inspection: visual, dimensional, and functional bench test against Honeywell factory acceptance criteria
- Firmware version verified and documented prior to dispatch
- Original Honeywell packaging and labeling preserved where available; repackaged units include inspection certificate
- Counterfeit-prevention: holographic labels, date codes, and PCB markings cross-checked against Honeywell reference database
Procurement Process
- Step 1 — Inquiry: Submit your BOM or part number via email to support@konmask.com or WhatsApp +0086 19859288691
- Step 2 — Quote: Receive a formal quotation with lead time, unit price, and shipping options within 24 hours
- Step 3 — Order Confirmation: Purchase order accepted; payment via T/T, PayPal, or trade credit (approved accounts)
- Step 4 — Inspection & Dispatch: Module inspected, documented, and shipped with tracking via DHL / FedEx / UPS
- Step 5 — After-Sales: 12-month warranty; technical support available for integration and commissioning queries
Technical FAQ
Q: Can the CC-PDIL51 be used without the CC-TDIL51 terminal assembly?
A: No. The CC-PDIL51 process module requires the CC-TDIL51 terminal assembly for field wiring. They must be ordered and installed as a matched pair.
Q: Is this module compatible with Experion PKS R400 and later releases?
A: Yes. The CC-PDIL51/CC-TDIL51 is forward-compatible with Experion PKS R400+ subject to standard firmware upgrade procedures documented in Honeywell’s release notes.
Q: Can I mix CC-PDIL51 with other C300 I/O modules in the same chassis?
A: Yes. The C300 I/O chassis supports mixed module types. Slot assignment is configured in Control Builder with no hardware restrictions between DI, DO, AI, and AO module types.
Q: What is the maximum cable length for field wiring to the CC-TDIL51?
A: Honeywell recommends a maximum of 300 m for 24 VDC DI circuits using 1.5 mm² shielded twisted-pair cable. Longer runs require voltage drop calculations and may need signal repeaters.
Q: Do you provide a Certificate of Conformance (CoC)?
A: Yes. A CoC is included with every shipment. Factory test reports are available upon request for critical applications.
