Industrial Automation Wiring Solution – Belden AF100 9688 0101000 | Wire & Cable Series
Where This Product Is Used
The Belden AF100 9688 0101000 is a high-performance industrial wire and cable designed for demanding automation environments. Engineers and system integrators specify this cable across a wide range of applications:
- PLC Control Panels – Internal wiring for programmable logic controller enclosures requiring reliable signal integrity and flexible routing.
- DCS & SCADA Systems – Distributed control system field wiring where noise immunity and consistent impedance are critical.
- Motor Drive & VFD Installations – Connecting variable frequency drives to motors in manufacturing lines, HVAC, and pump stations.
- Robotics & Machine Tool Wiring – Flexible cable routing in articulated arms, CNC machines, and automated assembly equipment.
- Process Plant Instrumentation – Analog and digital signal transmission in oil & gas, chemical, water treatment, and food processing facilities.
- Building Automation Systems (BAS) – Sensor and actuator wiring in smart building infrastructure.
Technical Specifications
| Part Number | AF100 9688 0101000 |
| Brand | Belden |
| Series | AF100 / 9688 |
| Product Type | Industrial Wire & Cable |
| Application | Industrial Automation, Control Systems, PLC/DCS Wiring |
| Conductor Material | Bare Copper |
| Insulation | PVC / Polyethylene (per Belden 9688 series standard) |
| Shielding | Foil + Braid Shield (100% coverage) |
| Temperature Rating | -20°C to +80°C |
| Voltage Rating | 300V RMS |
| Flame Rating | UL 13 / CSA FT4 |
| Country of Origin | USA |
| Weight | 500 g (per unit) |
Note: Specifications are based on Belden 9688 series datasheet. Confirm exact parameters with official Belden documentation for your application.
Why Engineers Specify This Model
- Proven Belden Quality – Belden is a globally recognized leader in signal transmission solutions with 100+ years of engineering heritage.
- Superior EMI/RFI Shielding – Foil + braid construction ensures clean signal transmission even in electrically noisy industrial environments.
- Flexible & Durable – Engineered for both fixed installation and flex-cycle applications in tight cable trays and conduit runs.
- UL/CSA Listed – Meets North American safety standards for industrial and commercial installations.
- Drop-in Replacement – Compatible with existing Belden 9688-series installations, simplifying MRO procurement.
- Long Reel Availability – Available in standard cut lengths and bulk reels to minimize waste and reduce per-meter cost.
Complete System Bill of Materials
When specifying the Belden AF100 9688 0101000, engineers typically pair it with the following components for a complete wiring solution:
- DIN Rail Terminal Blocks (e.g., Phoenix Contact UTTB 2.5)
- Cable Glands & Strain Relief Fittings (M20 / PG13.5)
- Ferrite Core EMI Suppressors (for VFD applications)
- Cable Duct & Trunking (Panduit or equivalent)
- Heat Shrink End Caps & Ferrules (0.5–2.5 mm²)
- PLC I/O Modules (Siemens S7, Allen-Bradley, Mitsubishi FX series)
- Shielded Connector Backshells (for D-sub and M12 connectors)
Compliance & Industry Standards
- UL Listed – UL 13 (Power-Limited Circuit Cable)
- CSA Certified – FT4 Flame Test
- RoHS Compliant – Restriction of Hazardous Substances Directive
- NEC Article 725 – Class 2 / Class 3 Circuit Wiring
- IEC 60332 – Flame Propagation (international installations)
Quality Assurance & Sourcing
At Konmask.com, every Belden cable unit is:
- Sourced directly from authorized Belden distributors or verified industrial surplus channels.
- Inspected for label authenticity, reel markings, and conductor continuity before dispatch.
- Stored in climate-controlled warehousing to preserve insulation integrity.
- Shipped with original manufacturer documentation where available.
We specialize in hard-to-find and discontinued Belden part numbers for MRO and project procurement teams.
How to Source This Part
- Add to Cart – Select quantity and proceed to checkout directly on this page.
- Request a Quote – For bulk orders (>100m or project quantities), email support@konmask.com for volume pricing.
- Urgent Requirement – Call or WhatsApp +0086 19859288691 for same-day stock confirmation and expedited shipping options.
- Global Shipping – We ship worldwide via DHL, FedEx, and UPS with full export documentation.
Application-Specific FAQ
Q: Can this cable be used in a VFD/motor drive application?
A: Yes. The shielded construction of the Belden 9688 series provides effective attenuation of high-frequency noise generated by variable frequency drives. Ensure the shield is grounded at one end (drive end) per best practice.
Q: Is this cable suitable for outdoor or direct burial installation?
A: The standard AF100 9688 0101000 is rated for indoor/conduit use. For outdoor or direct burial, consult Belden’s outdoor-rated variants with UV-resistant jackets.
Q: What is the minimum bend radius?
A: Typically 6× the cable OD for fixed installation and 10× OD for flex applications. Refer to the Belden 9688 series datasheet for exact values.
Q: Can I get a cut-to-length order?
A: Yes. Contact us at support@konmask.com with your required length and we will provide a custom quote.
Q: Is this a genuine Belden product?
A: All cables sold on Konmask.com are sourced from verified supply chains. We provide traceability documentation upon request.
