Bently Nevada 330903-00-24-50-02-00 3300 XL NSv Proximity Transducer System | Replacement, Equivalent & Selection Guide
The Bently Nevada 330903-00-24-50-02-00 is a high-precision eddy-current proximity transducer belonging to the 3300 XL NSv series, engineered for continuous non-contact vibration and position measurement in rotating machinery. At Konmask.com, we supply genuine and verified-equivalent units to support your predictive maintenance and machinery protection programs.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 330903-00-24-50-02-00 |
| Series | Bently Nevada 3300 XL NSv |
| Transducer Type | Eddy-Current Proximity Transducer |
| Cable Length | 24 inches (integral) |
| Extension Cable Length | 50 ft (15.2 m) |
| Thread Size | 8 mm |
| Measurement Range | 0–90 mil (0–2.29 mm) |
| Scale Factor | 200 mV/mil (7.87 V/mm) |
| Operating Temperature | −35°C to +121°C |
| Target Material | AISI 4140 steel (standard) |
| Output Signal | DC voltage (negative) |
| Connector | 2-pin MIL-C-5015 style |
| Agency Approvals | CE, FM, CSA (intrinsically safe options) |
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the 330903-00-24-50-02-00. Always verify gap voltage, scale factor, and cable length before substitution:
- Bently Nevada 330903-00-24-10-02-00 — Same transducer, 10 ft extension cable (shorter run)
- Bently Nevada 330903-00-24-30-02-00 — 30 ft extension cable variant
- Bently Nevada 330905-00-24-50-02-00 — 3300 XL 8 mm standard series, compatible driver/monitor
- Bently Nevada 330780-50-00 — 3300 5 mm proximity transducer (different thread; verify monitor compatibility)
- Epro PR6423/010-040 — Third-party equivalent, 8 mm eddy-current, verify scale factor 8 V/mm
- Metrix ST5484E — Alternative proximity system; confirm monitor input range before use
⚠ Note: Cross-brand substitutions require full system validation including driver, extension cable, and monitor compatibility. Contact our engineers at support@konmask.com for a free compatibility check.
Why Choose the Original Model
- Factory-calibrated scale factor — 200 mV/mil ensures direct plug-in compatibility with Bently Nevada 3300 series monitors (3300/16, 3300/20, 3500/42)
- NSv (Non-Standard velocity) optimized — Designed for low-frequency shaft vibration measurement in steam turbines, compressors, and pumps
- Integral cable design — Eliminates connector failure points in harsh industrial environments
- API 670 compliant — Meets machinery protection standard for critical rotating equipment
- Long field service life — Robust stainless-steel housing rated for high-temperature, high-vibration zones
Typical Applications
- Steam turbine shaft radial vibration monitoring
- Centrifugal compressor rotor position measurement
- Pump and motor bearing displacement monitoring
- Gearbox differential expansion measurement
- Turbine thrust position monitoring
- Petrochemical plant rotating machinery protection systems
System Compatibility
The 330903-00-24-50-02-00 transducer is designed to operate within the complete Bently Nevada 3300 XL NSv system, which includes:
- Driver/Oscillator: Bently Nevada 330180-X1-05 (3300 XL NSv driver)
- Extension Cable: Bently Nevada 330130-045-00-CN (50 ft, included in this configuration)
- Monitors: 3300/16, 3300/20, 3500/42M, 3500/42 (radial vibration monitors)
- System: Bently Nevada System 1 / System 1 Evolution (condition monitoring software)
Do not mix NSv transducers with standard 3300 XL drivers — the scale factor and gap voltage differ. Confirm driver part number before installation.
Selection Guide
Use the table below to decode the 330903-XX-XX-XX-XX-XX part number structure and select the correct variant for your application:
| Position | Code | Meaning |
|---|---|---|
| Series | 330903 | 3300 XL NSv 8 mm Proximity Transducer |
| Approval | 00 | Standard (no special agency approval) |
| Integral Cable | 24 | 24-inch integral cable |
| Extension Cable | 50 | 50 ft (15.2 m) extension cable |
| Connector | 02 | Standard 2-pin connector |
| Target | 00 | Standard AISI 4140 steel target |
Need a different cable length or agency approval? Contact us — we stock multiple configurations and can source to order.
Quality Assurance & Sourcing
- ✅ Genuine Bently Nevada units sourced from authorized distribution channels
- ✅ Each unit inspected and tested against OEM specifications before shipment
- ✅ Traceability documentation available upon request (COC, test reports)
- ✅ Secure anti-static packaging for safe international shipping
- ✅ Export compliance verified — HS Code 9031.80 (precision measurement instruments)
How to Order
- Confirm your part number: 330903-00-24-50-02-00
- Verify system compatibility (driver model, monitor model, cable run distance)
- Add to cart or contact us for bulk/project pricing
- Receive order confirmation with lead time and tracking
📧 support@konmask.com | 📞 +0086 19859288691
We respond within 1 business day. Expedited sourcing available for urgent shutdowns.
Replacement & Compatibility FAQ
Q: Can I use a standard 3300 XL transducer instead of the NSv version?
A: No. The NSv (Non-Standard velocity) series uses a different scale factor and requires a matched NSv driver. Mixing series will result in incorrect vibration readings and potential monitor alarms.
Q: Is the 330903-00-24-50-02-00 compatible with the Bently Nevada 3500 system?
A: Yes, when paired with the 3500/42M or 3500/42 monitor module and the correct NSv driver. Verify the monitor’s input configuration before installation.
Q: What is the gap voltage for this transducer?
A: The recommended gap voltage is approximately −10.0 VDC (corresponding to a 50 mil / 1.27 mm gap on AISI 4140 steel target).
Q: Can Konmask supply the complete 3300 XL NSv system (transducer + driver + cable)?
A: Yes. Contact us with your system requirements and we will quote the complete assembly.
Q: Do you offer a warranty?
A: All units carry a minimum 12-month warranty against manufacturing defects. Extended warranty options available for project orders.
