Bently Nevada 330909-00-50-10-01-05 – Eddy Current Proximity Probe | 3300 NSv Platform
The Bently Nevada 330909-00-50-10-01-05 is a high-precision eddy current proximity probe engineered for continuous, non-contact shaft vibration and position measurement in rotating machinery. As a core sensing element of the 3300 NSv (Non-contacting Vibration) System, this probe delivers the measurement accuracy and long-term reliability demanded by power generation, petrochemical, and heavy industrial applications.
Procurement engineers specify this probe for API 670-compliant machinery protection systems where measurement integrity and system interoperability are non-negotiable.
Complete Technical Specifications
- Part Number: 330909-00-50-10-01-05
- Series / Platform: Bently Nevada 3300 NSv
- Sensor Type: Eddy Current Proximity Probe
- Probe Tip Diameter: 5 mm (standard)
- Cable Length: 5 m (integral armored cable)
- Sensitivity: 200 mV/mil (7.87 V/mm)
- Linear Range: 0.25 mm – 2.25 mm (10 mil – 90 mil)
- Frequency Response: DC to 10,000 Hz (–3 dB)
- Operating Temperature: –35°C to +177°C (–31°F to +350°F)
- Target Material: AISI 4140 steel (standard); compatible with most ferromagnetic and non-ferromagnetic metals
- Connector: Integral coaxial, mates with 3300 NSv extension cable
- Housing Material: Stainless steel, hermetically sealed
- Ingress Protection: IP67
- Compliance: API 670, CE, RoHS
- Weight: 220 g (probe + cable assembly)
- Country of Origin: USA
Proven Application Environments
- Steam and gas turbines (radial vibration, axial position, differential expansion)
- Centrifugal compressors and pumps (shaft orbit, eccentricity)
- Gearboxes and electric motors (bearing journal monitoring)
- Hydro turbines and large rotating equipment per API 670 / ISO 10816
- Offshore platforms and LNG facilities requiring SIL-rated protection loops
Engineering Advantages
- Non-contact measurement: Zero mechanical wear; suitable for continuous 24/7 operation over multi-year intervals
- Wide temperature range: Maintains calibration accuracy across cryogenic to high-heat process environments
- Hermetic sealing: Resists moisture, process fluids, and aggressive atmospheres without signal degradation
- Direct 3300 NSv compatibility: Plug-and-play with 3300 NSv drivers, extension cables, and Bently Nevada System 1 software — no re-calibration required
- API 670 compliance: Meets machinery protection standard for critical and essential machinery classifications
System Architecture & Signal Flow
The 330909-00-50-10-01-05 operates as the field-sensing element in a three-component eddy current measurement chain:
- Probe (330909-00-50-10-01-05) — generates oscillating electromagnetic field; detects target displacement via impedance change
- Extension Cable (330130 series) — transmits raw probe signal with minimal loss over distances up to 9 m total system length
- Driver / Proximitor (3300 XL 8mm or NSv Driver) — conditions signal, outputs –24 VDC bias and 200 mV/mil proportional voltage to monitoring system
Total system cable length (probe + extension) must not exceed the driver’s rated specification. Verify driver part number compatibility before ordering extension cables.
Sourcing & Quality Verification
- All units sourced from authorized Bently Nevada / Baker Hughes distribution channels or verified surplus with full traceability documentation
- Each probe inspected for physical integrity, connector condition, and cable continuity prior to shipment
- Calibration certificates and original packaging available upon request for critical-service applications
- Lot traceability records maintained for 5 years in compliance with ISO 9001 quality management requirements
Procurement Process
- Confirm target material, total cable length requirement, and driver model before ordering
- Submit RFQ via support@konmask.com or call +0086 19859288691 for volume pricing and lead time
- Standard lead time: 3–7 business days (in-stock); 2–4 weeks (factory order)
- Export documentation (CO, packing list, commercial invoice) provided for international shipments
- Payment terms: T/T, PayPal, trade credit (approved accounts)
Technical FAQ
Q: Is the 330909-00-50-10-01-05 compatible with the older 3300 XL 8mm driver?
A: The 3300 NSv probe series is designed for NSv drivers. Cross-compatibility with 3300 XL drivers requires verification of driver firmware version and system configuration. Contact our engineering team for a compatibility assessment.
Q: Can this probe measure non-ferromagnetic targets (e.g., titanium, aluminum)?
A: Yes, but sensitivity and linear range will differ from the standard AISI 4140 calibration. A target-specific calibration factor must be applied. Bently Nevada provides calibration data for common non-standard target materials.
Q: What is the maximum operating temperature for the cable jacket?
A: The integral cable is rated to +177°C. For higher ambient temperatures at the cable routing path, specify a high-temperature extension cable (330130-XX-XX series).
Q: Do you supply the complete 3300 NSv measurement chain (probe + extension + driver)?
A: Yes. Konmask.com stocks the full 3300 NSv component set. Contact us with your system BOM for a consolidated quotation.
