Bently Nevada 330910-02-10-70-01-00 – Dual-Channel Vibration Monitor | 3300 XY Series Platform
Engineering Background
The Bently Nevada 3300 XY Series represents the industry benchmark for continuous machinery protection in rotating equipment applications. Engineered for critical turbomachinery environments, this platform has been deployed across power generation, oil & gas, petrochemical, and heavy industrial facilities worldwide for over three decades.
Product Positioning
The 330910-02-10-70-01-00 is a dual-channel vibration monitor module designed for simultaneous XY radial vibration measurement. It provides real-time shaft displacement monitoring with configurable alarm and danger setpoints, making it the preferred choice for procurement engineers specifying API 670-compliant machinery protection systems.
Complete Technical Specifications
| Part Number | 330910-02-10-70-01-00 |
| Brand | Bently Nevada (Baker Hughes) |
| Series / Platform | 3300 XY Series |
| Module Type | Dual-Channel Vibration Monitor |
| Measurement Channels | 2 (X-axis & Y-axis radial vibration) |
| Transducer Compatibility | Bently Nevada 3300 Series proximity probes (eddy-current) |
| Input Signal Range | -18 VDC to -24 VDC (standard Bently Nevada probe driver output) |
| Measurement Range | 0–25 mil pp (0–635 µm pp) radial displacement |
| Frequency Response | DC to 10 kHz |
| Alarm Outputs | Alert & Danger relay outputs per channel (configurable) |
| Power Supply | 18–30 VDC |
| Operating Temperature | -40°C to +70°C |
| Enclosure / Form Factor | DIN-rail mountable module, 3300 rack-compatible |
| Compliance | API 670, CE, RoHS |
| Weight | Approx. 120 g |
| Country of Origin | United States |
Proven Application Environments
- Power Generation: Steam turbines, gas turbines, and generator shaft monitoring
- Oil & Gas: Compressor trains, centrifugal pumps, and pipeline booster stations
- Petrochemical: Reactor agitators, extruder drives, and critical process pumps
- Marine & Offshore: Propulsion shaft monitoring and auxiliary machinery protection
- Pulp & Paper / Mining: High-speed rotating equipment with continuous uptime requirements
Engineering Advantages
- Simultaneous XY Measurement: Captures both radial planes in a single module, eliminating phase lag between channels and enabling accurate orbit plot generation.
- API 670 Compliance: Meets the international standard for machinery protection systems, ensuring acceptance in EPC and owner-operator specifications.
- Configurable Setpoints: Alert and Danger thresholds are independently adjustable per channel to match specific machinery OEM limits.
- Plug-and-Play Rack Integration: Direct compatibility with existing 3300 Series racks minimizes installation engineering and commissioning time.
- High EMI Immunity: Designed for industrial environments with variable-frequency drives, switchgear, and high-current bus bars in proximity.
System Architecture & Signal Flow
The 330910-02-10-70-01-00 operates within the Bently Nevada 3300 rack architecture as follows:
- Proximity Probe (3300 Series, 8 mm or 5 mm tip) installed at shaft bearing journal → outputs –18 VDC to –24 VDC proportional signal.
- Extension Cable & Proximitor conditions the raw probe signal and delivers it to the monitor module input terminals.
- 330910-02-10-70-01-00 Monitor Module processes both X and Y channel signals simultaneously, applies configured gap voltage, and computes peak-to-peak displacement in real time.
- Relay Outputs (Alert / Danger) drive external annunciators, DCS hardwired inputs, or safety system trip logic.
- Buffered Output available for connection to data acquisition systems, DCS analog inputs, or portable analyzers for spectrum analysis.
Sourcing & Quality Verification
- All units sourced through verified industrial automation distributors and OEM-authorized channels.
- Each module undergoes incoming inspection: visual check, label verification, and functional power-on test prior to dispatch.
- Serialization and firmware revision documented and provided with shipment.
- Packaging: original OEM carton where available; otherwise ESD-safe anti-static packaging with foam cushioning.
- Certificate of conformance available upon request for regulated industries.
Procurement Process
- Submit RFQ — Contact support@konmask.com or call +0086 19859288691 with your part number and required quantity.
- Receive Quote — Pricing, lead time, and availability confirmed within 1 business day.
- Order Confirmation — Purchase order accepted; payment terms discussed (T/T, L/C, or online checkout).
- Quality Inspection & Dispatch — Module inspected, documented, and shipped via DHL / FedEx / UPS with full tracking.
- After-Sales Support — Technical assistance available for installation, commissioning, and warranty claims.
Technical FAQ
Q: Is the 330910-02-10-70-01-00 compatible with the Bently Nevada 3500 Series rack?
A: No. This module is designed exclusively for the 3300 Series rack architecture. For 3500 Series applications, please inquire about the equivalent 3500/42M or 3500/46M modules.
Q: Can this monitor be used with non-Bently Nevada proximity probes?
A: The module is optimized for Bently Nevada 3300 Series probes and Proximitors. Third-party probes with matching output characteristics (–18 to –24 VDC, 200 mV/mil sensitivity) may be compatible but require engineering validation.
Q: What is the typical lead time for this part number?
A: Ex-stock units ship within 3–5 business days. For larger quantities or specific firmware revisions, lead time is 2–4 weeks. Contact us for current availability.
Q: Do you provide a warranty?
A: Yes. All units carry a 12-month warranty against manufacturing defects from the date of shipment. Warranty claims are processed via RMA with full technical support.
Q: Can you supply the complete 3300 XY system including probes, extension cables, and Proximitors?
A: Yes. Konmask.com can supply complete 3300 Series system assemblies. Please provide your machinery drawing or probe installation specification for a complete BOM quotation.
