Turbine Vibration Monitoring Solution — Bently Nevada 330910-10-22-10-01-CN | NSv Series
The Bently Nevada 330910-10-22-10-01-CN is a high-precision eddy-current proximity probe from the NSv (Non-contacting vibration) Series, engineered for continuous shaft displacement and radial vibration measurement in rotating machinery. Designed to integrate seamlessly with Bently Nevada 3500 and System 1 monitoring platforms, this probe delivers the sub-micron resolution and long-term stability demanded by power generation, oil & gas, and petrochemical operators worldwide.
Where This Product Is Used
The 330910-10-22-10-01-CN is specified by rotating-equipment engineers across the following critical applications:
- Steam & Gas Turbines — radial shaft vibration and position monitoring per API 670
- Centrifugal Compressors — real-time rotor orbit tracking and surge detection
- Pumps & Fans — bearing-clearance trending and imbalance detection
- Gearboxes — gear-mesh frequency analysis and shaft eccentricity measurement
- Hydro Turbines — axial thrust and radial displacement monitoring
- Marine Propulsion Systems — continuous shaft-line health surveillance
Technical Specifications
| Part Number | 330910-10-22-10-01-CN |
| Brand | Bently Nevada (Baker Hughes) |
| Series | NSv Proximity Probe |
| Sensing Technology | Eddy-current (non-contacting) |
| Probe Length | 22 mm (per SKU suffix) |
| Cable Length | 10 ft (3.05 m) integral cable |
| Thread Size | M10 × 1.0 |
| Target Material | Steel / Inconel / Stainless Steel |
| Operating Temperature | −35 °C to +177 °C |
| Output Signal | −24 VDC (nominal), mV/mil linear output |
| Sensitivity | 200 mV/mil (7.87 V/mm) |
| Linear Range | 0 to 90 mil (0 to 2.29 mm) |
| Connector | CN (Chinese market connector variant) |
| Weight | 160 g |
| Compatible Driver/Monitor | Bently Nevada 3500 Series, 3300 Series |
Why Engineers Specify This Model
- API 670 Compliant — meets the industry standard for machinery protection systems without additional calibration
- CN Connector Variant — factory-terminated for Chinese domestic installations, eliminating field-wiring adapters and reducing installation time
- Sub-micron Resolution — detects shaft displacement changes as small as 0.5 µm, enabling early-warning fault detection before catastrophic failure
- Wide Temperature Range — qualified for hot-section turbine environments up to 177 °C without signal drift
- Plug-and-Play with 3500 Rack — pre-calibrated to Bently Nevada driver electronics; no field scaling required
- Long-term Stability — hermetically sealed tip and Teflon-jacketed cable resist oil, steam, and chemical ingress
Complete System Bill of Materials
A fully functional NSv proximity measurement loop requires the following components:
- Proximity Probe: 330910-10-22-10-01-CN (this item)
- Extension Cable: 330130-080-00-00 (8 m) or 330130-045-00-00 (4.5 m)
- Proximitor Driver: 330180-X1-05 (3300 XL 8 mm) or 3500/42M module
- Monitor Rack: Bently Nevada 3500 Rack with 3500/20 Power Supply
- Mounting Hardware: M10 probe holder bracket (customer-supplied or Konmask-sourced)
Contact support@konmask.com to source the complete loop as a kit.
Compliance & Industry Standards
- API 670 — Machinery Protection Systems
- API 670 Annex D — Eddy-Current Probe Calibration
- IEC 60079 — Equipment for Explosive Atmospheres (consult datasheet for ATEX/IECEx zone rating)
- ISO 10816 / ISO 20816 — Mechanical Vibration Evaluation
- CE Marking (EU Declaration of Conformity available on request)
- RoHS Compliant
Quality Assurance & Sourcing
Every 330910-10-22-10-01-CN unit shipped by Konmask.com is:
- Sourced directly from authorized Bently Nevada / Baker Hughes distribution channels or verified OEM-surplus stock
- Inspected against OEM datasheet specifications prior to dispatch
- Supplied with original manufacturer packaging and traceable lot documentation where available
- Backed by Konmask’s 12-month quality guarantee against manufacturing defects
How to Source This Part
- Request a Quote — email support@konmask.com with your required quantity and delivery timeline
- Confirm Compatibility — share your existing driver model and cable length; our engineers will verify loop compatibility at no charge
- Receive Proforma Invoice — typically within 24 business hours
- Arrange Payment & Shipping — DHL / FedEx express worldwide; sea freight available for bulk orders
- Track & Receive — full shipment tracking provided; average lead time 3–7 business days for in-stock units
Application-Specific FAQ
Q: Is the 330910-10-22-10-01-CN compatible with the Bently Nevada 3500/42M Vibration Monitor?
A: Yes. The NSv probe is factory-calibrated for use with 3500-series drivers. Verify the driver gap voltage range (−10 V to −18 V) matches your installation gap.
Q: What is the difference between the -01-CN and -01-00 suffix?
A: The -CN suffix denotes a Chinese-market connector variant with a localized termination standard. Electrically and mechanically, the probe is identical to the -01-00 international variant.
Q: Can this probe be used on non-ferrous targets such as titanium or aluminum?
A: The standard NSv probe is calibrated for steel targets. Non-ferrous target use requires a target-material correction factor or a custom-calibrated probe. Contact us for details.
Q: What is the recommended installation gap for this probe?
A: The nominal installation gap is 50 mil (1.27 mm), corresponding to the midpoint of the linear range. Refer to Bently Nevada Installation Manual 141536-01 for torque specifications.
Q: Do you offer expedited shipping to mainland China?
A: Yes. We ship via DHL Express and SF International with typical transit times of 2–4 business days to major Chinese cities.
