B&R X20 DO F322 Digital Output Module | Replacement, Equivalent & Selection Guide
The B&R X20 DO F322 is a digital output module designed for the X20 modular PLC system. Whether you are maintaining an existing automation line, sourcing a replacement for a failed unit, or evaluating equivalent alternatives, this page provides the technical depth and selection guidance you need to make a confident procurement decision.
Technical Specifications
- Model: X20 DO F322
- Brand: B&R (Bernecker + Rainer)
- Series: X20 Modular I/O System
- Module Type: Digital Output Module
- Output Type: Digital (solid-state / transistor outputs)
- Communication: X2X Link (B&R proprietary backplane bus)
- Mounting: DIN rail, X20 bus module required
- Operating Temperature: 0 °C to +55 °C
- Protection Class: IP20
- Power Supply: Via X20 bus module (internal bus)
- Standards: CE, UL (refer to official B&R datasheet for full certification list)
Note: All specifications are sourced from publicly available B&R documentation. Do not rely solely on this page for engineering design — always verify against the official B&R X20 DO F322 datasheet.
Compatible Replacement & Equivalent Models
When the X20 DO F322 is unavailable or discontinued, the following models may serve as functional replacements depending on your application requirements. Always verify electrical and software compatibility before substitution:
- B&R X20 DO 9322 — Standard digital output module in the same X20 family; verify channel count and output current ratings
- B&R X20 DO 6322 — Alternative channel configuration within X20 Series
- B&R X20 DO F332 — Higher-density output variant; check I/O mapping compatibility in Automation Studio
- Third-party X2X-compatible modules — Limited availability; firmware and bus compatibility must be confirmed with B&R engineering
Important: Replacement selection must account for output channel count, load current per channel, safety function ratings (SIL/PLe if applicable), and Automation Studio project configuration. Contact Konmask.com for application-specific guidance.
Why Choose the Original Model
- Guaranteed X2X Link compatibility — Native integration with B&R X20 CPU and bus modules without firmware workarounds
- Automation Studio plug-and-play — Module is natively recognized; no custom driver development required
- Safety-rated design — The F3xx suffix in B&R nomenclature typically indicates functional safety features; verify SIL rating in the official datasheet
- Long-term spare parts availability — B&R X20 Series has an extended product lifecycle commitment
- Consistent diagnostics — Full LED status indication and software-readable diagnostics via X2X Link
Typical Applications
- Machine tool control panels and actuator switching
- Conveyor and material handling systems
- Packaging machinery output control (solenoids, relays, indicators)
- Automotive assembly line automation
- Food & beverage processing equipment
- Pharmaceutical manufacturing lines requiring safety-rated I/O
- Printing and converting machinery
- Robotics and motion control auxiliary I/O
System Compatibility
The X20 DO F322 is designed exclusively for use within the B&R X20 modular I/O system. Key compatibility requirements:
- Bus Module: Requires a compatible X20 bus module (e.g., X20 BM01, X20 BM11) for power and data connection
- CPU Compatibility: Compatible with X20 Series CPUs communicating via X2X Link
- Software: B&R Automation Studio (version compatibility depends on firmware; check B&R release notes)
- Power Supply: X20 PS series power supply modules recommended
- Not compatible with: X67 (IP67) series, ACOPOS drive direct I/O, or third-party Modbus/PROFIBUS masters without gateway
Selection Guide
Use the following criteria to confirm the X20 DO F322 is the right module for your application:
- ✅ You need digital (discrete) outputs — not analog, not encoder, not communication
- ✅ Your system uses B&R X20 Series hardware with X2X Link backplane
- ✅ Your application may require functional safety — verify SIL/PLe rating in the official datasheet if safety is a requirement
- ✅ Output load matches module specifications — confirm voltage and current per channel
- ⚠️ If you need analog outputs — consider X20 AO series modules instead
- ⚠️ If you need higher channel density — compare with X20 DO F332 or X20 DO 9322
Not sure which module fits your system? Send your existing configuration file or hardware list to [email protected] and our engineers will advise.
Quality Assurance & Sourcing
- Authentic sourcing: All B&R modules supplied by Konmask.com are sourced through verified industrial supply channels
- Pre-shipment inspection: Each unit undergoes visual inspection, label verification, and packaging integrity check
- Traceability: Batch and serial number records maintained for every shipment
- Warranty: 12-month warranty against manufacturing defects (subject to terms)
- Anti-counterfeit: We do not supply refurbished or remarked units — all products are new-in-box unless explicitly stated
How to Order
- Confirm your required quantity and delivery timeline
- Send your inquiry to [email protected] with subject: “RFQ – X20 DO F322”
- Include your shipping destination, preferred Incoterms, and any certification requirements
- Receive a formal quotation within 1 business day
- Confirm order and receive proforma invoice
- Shipment arranged via DHL / FedEx / UPS or as agreed
You may also reach us directly: +0086 19859288691 (WhatsApp / WeChat / Phone)
Replacement & Compatibility FAQ
Q: Can I replace X20 DO F322 with X20 DO 9322 directly?
A: Functionally similar, but you must verify channel count, output current ratings, and update the hardware configuration in Automation Studio. The F-series suffix may indicate additional safety features not present in the standard DO 9322.
Q: Is the X20 DO F322 still in production?
A: B&R X20 Series has a long lifecycle commitment. Contact Konmask.com to check current availability and lead times.
Q: Can this module work with a SIEMENS or Mitsubishi PLC?
A: No. The X20 DO F322 uses B&R’s proprietary X2X Link protocol and is not compatible with third-party PLC backplanes without a dedicated gateway.
Q: Do you supply used or refurbished units?
A: No. Konmask.com supplies new-in-box units only, unless explicitly agreed in writing.
Q: How long does shipping take to Europe / USA / Southeast Asia?
A: Typically 3–7 business days via express courier. Contact us for exact lead times based on your destination.
Q: Can you provide a certificate of conformity or test report?
A: Yes, upon request. Please specify your documentation requirements when placing your inquiry.
