Danfoss 130B6016 DT/7 – Drive Control Board | VLT Series Frequency Converter Platform
Engineering Background: The Danfoss VLT® series has been a cornerstone of industrial variable-speed drive technology for decades, deployed across water treatment, HVAC, marine, and process automation sectors worldwide. The 130B6016 DT/7 is the dedicated drive control board (also referred to as the control card or logic board) engineered for VLT® frequency converters, responsible for signal processing, parameter management, and closed-loop feedback coordination.
Product Positioning: Designed for maintenance engineers and procurement specialists who require a verified OEM-equivalent replacement to restore drive functionality with zero compromise on performance or compatibility. This board eliminates the need for full drive replacement, significantly reducing downtime cost and capital expenditure.
Complete Technical Specifications
- Part Number / SKU: 130B6016 DT/7
- Manufacturer: Danfoss (Denmark)
- Product Series: VLT® Frequency Converter Platform
- Component Type: Drive Control Board (Logic / Control Card)
- Board Revision: DT/7
- Form Factor: PCB module, plug-in / screw-mount
- Weight: Approx. 300 g
- Country of Origin: Denmark
- Condition: New / Refurbished OEM-grade (specify at inquiry)
- Compatibility: Danfoss VLT® series frequency converters (confirm frame size and firmware version before ordering)
- Communication Interface: Supports standard Danfoss fieldbus options (RS-485, FC protocol) depending on drive configuration
- Operating Temperature: -10°C to +50°C (derate above 45°C per Danfoss guidelines)
- Storage Temperature: -25°C to +65°C
- Humidity: 5–95% RH, non-condensing
- Protection Class: IP20 (board-level; enclosure protection depends on drive chassis)
- Certifications: CE, UL (per parent drive platform)
Proven Application Environments
- Municipal water supply & wastewater treatment pump drives
- HVAC fan and compressor variable-speed control systems
- Marine propulsion and auxiliary drive systems
- Industrial conveyor and material handling automation
- Process industry: chemical, food & beverage, pharmaceutical
- Building automation and energy management systems
- OEM machine builders using Danfoss VLT® platform drives
Engineering Advantages
- Drop-in Replacement: Maintains original drive parameter sets and fieldbus configuration without re-commissioning the full drive
- Reduced MTTR: Board-level swap cuts mean-time-to-repair versus full drive replacement
- OEM-Grade Components: Sourced from verified supply channels; no counterfeit risk
- Firmware Compatibility: Matched to DT/7 revision; confirm firmware version with your drive’s nameplate before ordering
- Long-Term Availability: Stocked to support legacy VLT® installations beyond standard product lifecycle
System Architecture & Signal Flow
The 130B6016 DT/7 control board interfaces directly with the drive’s power section via the internal bus connector. It manages:
- Reference signal processing: Analog (0–10 V / 4–20 mA) and digital setpoint inputs
- Closed-loop PID control: Feedback from process sensors for pressure, flow, or speed regulation
- Fault diagnostics: Real-time monitoring of overcurrent, overvoltage, thermal, and communication faults
- Parameter storage: Non-volatile memory retains drive configuration across power cycles
- Fieldbus gateway: Bridges process controller (PLC/DCS) commands to the drive’s power electronics
Sourcing & Quality Verification
- All boards are inspected upon receipt: visual PCB inspection, component verification, and functional bench test where applicable
- Traceability documentation available on request (batch records, test reports)
- Packaging: anti-static ESD bag + foam-lined carton for safe international transit
- Lead time: typically 3–7 business days from confirmed order; expedited options available
- Warranty: 12 months from shipment date against manufacturing defects
Procurement Process
- Confirm compatibility: Provide your drive’s full nameplate data (model, serial number, firmware version) via email or WhatsApp
- Request quotation: We respond within 1 business day with pricing, lead time, and availability
- Place order: Secure checkout via Konmask.com or proforma invoice for B2B accounts
- Shipment & tracking: DHL / FedEx / UPS express with full tracking; customs documentation included
- After-sales support: Technical assistance available post-installation
Technical FAQ
Q: Is the 130B6016 DT/7 compatible with all VLT® drive frame sizes?
A: Compatibility depends on the specific VLT® product series and power range. Please share your drive’s model number for confirmation before ordering.
Q: Can I retain my existing drive parameters after replacing this board?
A: Yes, if you back up parameters via the LCP (Local Control Panel) or MCT 10 software before replacement. The new board accepts parameter upload upon commissioning.
Q: Do you supply new or refurbished boards?
A: Both options are available. Specify your requirement at inquiry. All units pass functional inspection regardless of condition grade.
Q: What is the minimum order quantity?
A: MOQ is 1 piece. Volume pricing available for orders of 5+ units.
Q: Can you provide a certificate of conformity or test report?
A: Yes, documentation is available upon request for B2B and project procurement.
