Industrial HMI Touch Screen Solution — DELTA DOP-A10TCTD | DOP-A Series
Where This Product Is Used
The DELTA DOP-A10TCTD is a 10-inch TFT LCD human-machine interface (HMI) panel deployed across demanding industrial environments where reliable operator interaction is non-negotiable. Typical deployment scenarios include:
- Factory Automation & Assembly Lines — Real-time machine status visualization, parameter input, and alarm acknowledgment on production floors.
- Water & Wastewater Treatment Plants — SCADA-integrated operator terminals for pump control, flow monitoring, and process setpoint adjustment.
- Food & Beverage Processing — Hygienic-environment panel interfaces for batch recipe management and conveyor speed control.
- Packaging Machinery — Touchscreen operator panels for format changeover, speed regulation, and fault diagnostics.
- Building Automation & HVAC — Central operator interface for chiller plants, AHU control loops, and energy monitoring dashboards.
- Power Distribution & Energy Management — Substation HMI terminals for breaker status, load monitoring, and protection relay interaction.
- Plastics & Injection Molding — Mold parameter entry, cycle time tracking, and temperature profile visualization.
- Textile & Printing Equipment — Operator control panels for tension control, color registration, and speed synchronization.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | DOP-A10TCTD |
| Brand | DELTA Electronics |
| Series | DOP-A |
| Display Size | 10.1″ TFT LCD |
| Resolution | 1024 × 600 pixels (WSVGA) |
| Touch Type | Resistive / Capacitive (TCTD variant) |
| Brightness | 400 cd/m² |
| Colors | 65,536 colors |
| CPU | ARM Cortex-A8, 600 MHz |
| Memory (RAM) | 128 MB DDR3 |
| Flash Storage | 256 MB |
| Communication Ports | RS-232, RS-485, USB Host, USB Device, Ethernet (RJ-45) |
| Supported Protocols | Modbus RTU/TCP, DELTA DVP, DELTA AH, Mitsubishi, Siemens S7, Allen-Bradley DF1, and 300+ PLC drivers |
| Power Supply | 24 VDC ±20% |
| Power Consumption | ≤ 15 W |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -20°C to 60°C |
| Humidity | 10% to 90% RH (non-condensing) |
| Protection Rating | IP65 (front panel) |
| Panel Cutout | Refer to DELTA DOP-A10TCTD installation drawing |
| Weight | Approx. 2,140 g |
| Certifications | CE, UL, RoHS |
Specifications are subject to manufacturer revision. Always verify against the official DELTA DOP-A10TCTD datasheet before final design-in.
Why Engineers Specify This Model
- Broad PLC Compatibility — Native drivers for DELTA, Mitsubishi, Siemens, Omron, Allen-Bradley, and 300+ additional PLCs eliminate custom gateway hardware and reduce panel BOM cost.
- IP65 Front Panel Sealing — Suitable for wash-down environments and dusty factory floors without additional enclosure engineering.
- DOPSoft Programming Environment — Drag-and-drop screen editor with built-in recipe management, data logging, alarm history, and trend display objects reduces HMI development time.
- Dual USB Ports — Enables on-site firmware updates, recipe uploads, and data export via USB flash drive without a laptop connection.
- Ethernet Connectivity — Supports remote monitoring, VNC viewer access, and SCADA integration over standard TCP/IP networks.
- Proven DOP-A Platform — Widely deployed across Asia-Pacific and global OEM machine builders; extensive field history and community support.
- Compact Depth Profile — Shallow rear projection minimizes panel depth requirements in space-constrained control cabinets.
Complete System Bill of Materials
For a fully operational HMI control station based on the DOP-A10TCTD, engineers typically specify the following complementary components:
- PLC / Controller — DELTA DVP series (e.g., DVP32ES200T) or DELTA AH series for mid-range applications
- Communication Cable — RS-485 shielded twisted-pair cable or pre-made DELTA HMI-to-PLC cable assembly
- 24 VDC Power Supply — DELTA DRP series DIN-rail power supply (e.g., DRP024V060W1AZ), minimum 2A output
- Panel Enclosure — NEMA 4 / IP65-rated steel or stainless enclosure with appropriate cutout per DOP-A10TCTD template
- Ethernet Switch — Industrial managed switch for SCADA network integration (e.g., DELTA DVS series)
- USB Flash Drive — Industrial-grade USB drive for recipe backup and data logging export
- Programming PC & DOPSoft Software — DELTA DOPSoft (free download from DELTA website) on Windows 10/11 PC
- Grounding Hardware — DIN-rail grounding terminal blocks and panel earth bonding conductors
Compliance & Industry Standards
- CE Marking — Compliant with EU Low Voltage Directive (LVD) 2014/35/EU and EMC Directive 2014/30/EU
- UL Listed — Recognized under UL 508 (Industrial Control Equipment) for North American market deployment
- RoHS Compliant — Restriction of Hazardous Substances Directive 2011/65/EU; lead-free construction
- IP65 (IEC 60529) — Front panel dust-tight and protected against low-pressure water jets
- EMC Immunity — Designed to IEC 61000-4 series for industrial electromagnetic environment performance
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation components sourced through verified supply channels. Every DELTA DOP-A10TCTD unit we supply undergoes the following process:
- Authenticity Verification — Units are cross-referenced against DELTA Electronics authorized distributor documentation and serial number traceability records.
- Pre-shipment Functional Check — Power-on test and display verification performed before dispatch.
- Original Packaging — Shipped in manufacturer’s original anti-static packaging with all included accessories.
- Documentation Included — Quick installation guide and certificate of conformity provided with each unit.
- Warranty — 12-month warranty against manufacturing defects from date of shipment.
How to Source This Part
Konmask.com maintains stock of the DELTA DOP-A10TCTD and can fulfill both single-unit and volume orders. To place an order or request a formal quotation:
- Online Order — Add to cart and complete checkout. We accept T/T bank transfer, PayPal, and major credit cards.
- Email RFQ — Send your purchase order or BOM to support@konmask.com for volume pricing and lead time confirmation.
- Phone / WhatsApp — Contact our technical sales team at +0086 19859288691 for urgent requirements or application consultation.
- Lead Time — In-stock units ship within 1–3 business days. Ex-stock orders for large quantities: 5–15 business days depending on availability.
- Export & Customs — We provide commercial invoice, packing list, and certificate of origin for international shipments. HS Code: 8537.10 (indicative; buyer to verify for their jurisdiction).
Application-Specific FAQ
Q: Can the DOP-A10TCTD communicate with Siemens S7-1200 PLCs?
A: Yes. The DOP-A10TCTD includes a native Siemens S7 Ethernet driver. Connection is established via the RJ-45 Ethernet port using the S7 communication protocol. No additional gateway hardware is required.
Q: Is the DOP-A10TCTD suitable for outdoor installation?
A: The front panel is rated IP65, providing protection against dust and water jets. However, direct UV exposure and operating temperatures above 50°C are outside the rated specification. For outdoor use, install inside a ventilated, UV-resistant enclosure.
Q: What is the difference between DOP-A10TCTD and DOP-A10THTD?
A: The DOP-A10TCTD features a capacitive/resistive touch panel optimized for gloved-hand operation, while the DOP-A10THTD is the standard resistive-only variant. Specify TCTD for environments where operators wear protective gloves.
Q: Can I use the DOP-A10TCTD as a standalone data logger without a PLC?
A: Yes. The HMI supports internal data logging to its flash memory and USB drive using DOPSoft’s built-in data sampling objects. It can log analog and digital values from connected field devices independently.
Q: What programming software is required and is it free?
A: DELTA DOPSoft is the required programming environment. It is available as a free download from the official DELTA Electronics website and runs on Windows 10 and Windows 11.
Q: Do you provide technical support for integration?
A: Yes. Konmask.com’s technical team can assist with driver selection, communication parameter configuration, and basic DOPSoft screen setup guidance. Contact us at support@konmask.com.
