Deep Sea Electronics DSE8660 MKII Generator Control Module | Replacement, Equivalent & Selection Guide
The Deep Sea Electronics DSE8660 MKII is a professional-grade Automatic Mains Failure (AMF) and Auto-Start Generator Control Module designed for single or three-phase generating sets. Featuring a high-resolution LCD display, comprehensive engine protection, and J1939 CAN bus communication, the DSE8660 MKII is the benchmark controller for critical standby power applications. Konmask.com supplies genuine DSE8660 MKII units with full traceability and warranty support.
Technical Specifications
- Model: DSE8660 MKII
- Manufacturer: Deep Sea Electronics (DSE), UK
- Series: DSE8000 Series — Advanced AMF Controllers
- Control Mode: Automatic Mains Failure (AMF) / Auto-Start / Manual
- Display: 128 × 64 pixel backlit LCD with LED indicators
- Supply Voltage: 8–35 V DC
- Generator Voltage Sensing: Up to 333 V AC L-N (single/three-phase)
- Mains Voltage Sensing: Up to 333 V AC L-N (single/three-phase)
- Frequency Range: 3.5–75 Hz
- Engine Interface: J1939 CAN bus, Modbus RTU (RS-485)
- Digital Inputs: 8 configurable
- Relay Outputs: 7 configurable
- Analogue Inputs: 4 (temperature, pressure, level, etc.)
- Communication: USB, RS-232, RS-485, Ethernet (optional)
- Protection Class: IP65 front panel
- Operating Temperature: −30 °C to +70 °C
- Dimensions: 240 × 180 mm (panel cut-out)
- Weight: Approx. 800 g
- Certifications: CE, RoHS
Compatible Replacement & Equivalent Models
The DSE8660 MKII can replace or be compared against the following controllers. Always verify wiring diagrams and firmware compatibility before substitution:
- DSE8610 MKII — Same series, single-phase AMF; upgrade to DSE8660 MKII for three-phase support
- DSE8620 MKII — Parallel-ready variant; DSE8660 MKII is preferred for standalone AMF applications
- DSE7320 MKII — Entry-level AMF; DSE8660 MKII adds Ethernet and expanded I/O
- ComAp InteliLite 4 AMF 25 — Functional equivalent; different wiring harness and configuration software
- Deif AGC-4 — Advanced alternative; DSE8660 MKII offers simpler commissioning
- Smartgen HGM9320 — Budget alternative; DSE8660 MKII provides superior CAN bus integration
- Bernini Design BE142 — European equivalent; verify voltage sensing range before replacement
Note: Konmask.com recommends consulting the DSE8660 MKII datasheet and wiring diagram before any field replacement. Contact our technical team for a free compatibility assessment.
Why Choose the Original DSE8660 MKII
- Proven Reliability: DSE’s MKII platform has millions of field hours across critical infrastructure worldwide
- Factory Firmware: Genuine units ship with the latest DSE firmware, ensuring full feature access and OTA update eligibility
- Full Warranty: 2-year manufacturer warranty; aftermarket clones void site warranties and insurance policies
- DSE Suite Software: Free PC configuration software with genuine units; clones are incompatible
- Regulatory Compliance: CE and RoHS certified; required for EU and many export markets
- Technical Support: Access to DSE’s global support network and Konmask.com’s pre-sales engineering team
Typical Applications
- Hospital and data-center standby generator sets
- Telecom base station backup power
- Industrial plant emergency power systems
- Marine auxiliary generator control
- Oil & gas wellhead and offshore platforms
- Commercial building AMF switchgear panels
- Water treatment and pumping station backup
System Compatibility
- Engine Brands: Cummins, Perkins, Volvo Penta, John Deere, MTU, Doosan, Deutz, Yanmar (via J1939 CAN)
- Alternator Brands: Stamford, Leroy-Somer, Mecc Alte, Marathon
- SCADA / BMS Integration: Modbus RTU over RS-485; optional Ethernet for SNMP/Modbus TCP
- Panel Builders: Compatible with standard 240 × 180 mm DIN cut-out panels
Selection Guide
Use the table below to select the right DSE8000-series controller for your application:
- Single-phase AMF, basic I/O → DSE8610 MKII
- Three-phase AMF, standard I/O → DSE8660 MKII ✔ (this model)
- Three-phase AMF + parallel ready → DSE8620 MKII
- Multi-set parallel synchronising → DSE8680 MKII
- Need Ethernet as standard → DSE8660 MKII with optional Ethernet module
- Budget-constrained, basic AMF → DSE7320 MKII (reduced I/O)
Not sure which model fits your genset? Email our engineers with your engine ECU type, phase configuration, and I/O requirements for a free recommendation.
Quality Assurance & Sourcing
- All DSE8660 MKII units sourced directly from Deep Sea Electronics authorised distribution channels
- Each unit inspected and serial-number verified before dispatch
- Genuine DSE holographic label and tamper-evident packaging
- Batch traceability records available on request
- Export documentation (CO, packing list, commercial invoice) provided for international orders
How to Order
- Online: Add to cart directly on this page — stock units ship within 1–3 business days
- Email RFQ: support@konmask.com — include quantity, delivery address, and required documentation
- Phone / WhatsApp: +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Bulk / OEM orders: Volume pricing available for 5+ units; contact us for a formal quotation
Replacement & Compatibility FAQ
Q: Can the DSE8660 MKII replace a DSE8610 MKII directly?
A: Yes, with minor wiring adjustments for the additional three-phase sensing inputs. The panel cut-out dimensions are identical.
Q: Is the DSE8660 MKII compatible with Cummins QSB/QSL engines?
A: Yes, via J1939 CAN bus. Select the Cummins ECU profile in DSE Suite during commissioning.
Q: What is the difference between DSE8660 and DSE8660 MKII?
A: The MKII revision adds an improved LCD, enhanced CAN bus diagnostics, and expanded configurable I/O. The MKII is the current production version.
Q: Can I use a Smartgen HGM9320 as a drop-in replacement?
A: Functionally similar, but wiring pinouts differ significantly. A wiring adaptation harness is required. Konmask.com recommends the genuine DSE8660 MKII for warranty and compliance reasons.
Q: Do you provide the DSE Suite configuration software?
A: DSE Suite is free to download from Deep Sea Electronics’ website. Genuine units are automatically recognised; no licence key is required.
