ebm-papst A4E350-AQ02-11 – High-Efficiency EC Axial Fan Module | A4E Series Platform
Engineering Background
The ebm-papst A4E350-AQ02-11 is a 350 mm diameter EC (electronically commutated) axial fan engineered for demanding industrial and HVAC applications. Built on ebm-papst’s proven A4E Series platform, this unit integrates a brushless DC motor with onboard AC/DC power conversion electronics, delivering superior energy efficiency and precise speed control compared to conventional AC induction fan motors.
Product Positioning
Designed for OEM integration into air-handling units, refrigeration condensers, industrial cooling systems, and telecom enclosures, the A4E350-AQ02-11 is the preferred choice for procurement engineers who require long service life, low acoustic signature, and compliance with international energy efficiency directives (ErP/EcoDesign). Konmask.com supplies this unit as a verified, traceable component with full manufacturer documentation support.
Complete Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | ebm-papst (ebm-papst Mulfingen GmbH & Co. KG) |
| Part Number / SKU | A4E350-AQ02-11 |
| Series | A4E Series – EC Axial Fan |
| Fan Diameter | 350 mm (13.8 in) |
| Motor Technology | EC (Electronically Commutated) Brushless DC |
| Voltage Input | 200–277 V AC, 50/60 Hz (single-phase) |
| Power Consumption | Refer to official ebm-papst datasheet |
| Speed Control | 0–10 V DC analog signal / PWM compatible |
| Airflow Direction | Axial |
| Protection Class | IP44 (motor) |
| Insulation Class | F (155 °C) |
| Ambient Temperature | -20 °C to +60 °C |
| Weight | Approx. 3.5 kg |
| Country of Origin | Germany |
| Certifications | CE, UL (refer to datasheet) |
Note: Always verify final specifications against the official ebm-papst product datasheet before design-in. Contact Konmask.com for the latest revision datasheet.
Proven Application Environments
- HVAC & Air Handling Units (AHU): Supply and return air fans in commercial and industrial HVAC systems requiring ErP-compliant efficiency.
- Refrigeration & Cold Storage: Condenser and evaporator fan duty in walk-in coolers, display cases, and industrial refrigeration racks.
- Industrial Process Cooling: Cabinet cooling, heat exchanger fans, and machine tool enclosure ventilation.
- Telecom & Data Center Infrastructure: Precision cooling in outdoor telecom cabinets and edge computing enclosures.
- OEM Equipment Integration: Direct drop-in replacement or new design integration for equipment manufacturers requiring a compact, high-efficiency axial fan module.
Engineering Advantages
- EC Motor Efficiency: Up to 70% more energy-efficient than comparable AC shaded-pole motors, reducing total cost of ownership over the product lifecycle.
- Integrated Electronics: Onboard power conversion and motor control electronics eliminate the need for external VFDs or motor starters, simplifying system BOM and wiring.
- Precise Speed Control: 0–10 V DC or PWM input enables seamless integration with BMS (Building Management Systems) and PLC-based control architectures.
- Low Acoustic Emission: Optimized blade geometry and EC motor commutation minimize tonal noise, critical for occupied-space HVAC applications.
- Extended Service Life: Brushless motor design eliminates brush wear; rated for continuous duty operation in harsh industrial environments.
- ErP / EcoDesign Compliance: Meets EU Regulation 327/2011 and global equivalent energy efficiency mandates for fans >125 W.
System Architecture & Signal Flow
The A4E350-AQ02-11 operates as a self-contained fan module. AC mains power (200–277 V, 50/60 Hz) is rectified and converted internally to DC by the integrated power electronics. The EC motor controller receives a 0–10 V DC speed reference signal from the building automation system or PLC output module. The controller modulates motor commutation frequency to achieve the commanded speed setpoint, providing closed-loop speed regulation independent of supply voltage variation. Fault status and speed feedback signals (where applicable) are available via the motor’s signal connector for integration into supervisory control systems.
Sourcing & Quality Verification
- All ebm-papst components supplied by Konmask.com are sourced through verified distribution channels with full traceability to manufacturer lot codes.
- Each unit is inspected for physical integrity, label authenticity, and packaging condition prior to dispatch.
- Original manufacturer documentation (datasheet, declaration of conformity) is available upon request.
- Konmask.com does not supply counterfeit, refurbished, or remarked components. All stock is new and unused.
Procurement Process
- Submit Inquiry: Contact Konmask.com via email at support@konmask.com or call +0086 19859288691 with your required quantity and delivery timeline.
- Quotation: Receive a formal quotation with unit price (HKD/USD), lead time, and shipping options within 1 business day.
- Order Confirmation: Issue a purchase order referencing part number A4E350-AQ02-11. Payment terms and shipping method confirmed at this stage.
- Dispatch & Tracking: Units are dispatched with full shipping documentation. Tracking number provided upon shipment.
- After-Sales Support: Technical support and warranty claim assistance available through Konmask.com for the duration of the manufacturer warranty period.
Technical FAQ
Q: Can the A4E350-AQ02-11 be operated on a 110 V AC supply?
A: No. This unit is rated for 200–277 V AC input. Operation below the rated voltage range is not supported and will void the warranty. For 110 V applications, consult ebm-papst for an alternative model.
Q: Is a separate motor starter or VFD required?
A: No. The EC motor integrates all power conversion and speed control electronics. A 0–10 V DC control signal from your BMS or PLC is sufficient for full speed modulation.
Q: What is the expected service life?
A: ebm-papst EC fans are designed for >40,000 hours of continuous operation under rated conditions. Refer to the official datasheet for L10 bearing life data.
Q: Is this unit a direct replacement for an existing AC fan?
A: The A4E350-AQ02-11 is a 350 mm axial fan module. Mechanical fit, airflow direction, and electrical interface must be verified against your existing installation. Contact Konmask.com engineering support for cross-reference assistance.
Q: What certifications does this unit carry?
A: CE marking and UL recognition are standard. Refer to the ebm-papst declaration of conformity for the specific directives covered. Konmask.com can provide documentation upon request.
