Molex PCU-DPIO – General-Purpose Digital I/O Module | PCU Automation Platform
Engineering Background
The Molex PCU-DPIO is a digital process I/O module designed for the PCU (Process Control Unit) automation platform. Molex, a global leader in electronic components and connectivity solutions, engineered the PCU-DPIO to deliver reliable, high-density digital signal interfacing in demanding industrial environments. This module serves as the critical bridge between field-level sensors/actuators and the central control logic, enabling precise, real-time process monitoring and control.
Product Positioning
Targeted at procurement engineers and system integrators working in process automation, discrete manufacturing, and infrastructure control, the PCU-DPIO offers a proven, drop-in solution for expanding or replacing I/O capacity within existing PCU-series control architectures. Its general-purpose design supports a broad range of signal types, reducing the need for application-specific modules and simplifying spare-parts inventory.
Complete Technical Specifications
- Model / SKU: PCU-DPIO
- Manufacturer: Molex
- Module Type: Digital Process I/O (Input/Output)
- Platform Series: PCU (Process Control Unit)
- I/O Architecture: General-purpose digital, mixed DI/DO
- Signal Interface: Digital discrete signals (24 VDC typical)
- Isolation: Optically isolated I/O channels (channel-to-bus)
- Mounting: DIN rail / backplane slot mount (PCU rack compatible)
- Operating Temperature: 0°C to +60°C (storage: -40°C to +85°C)
- Humidity: 5% to 95% RH, non-condensing
- Weight: Approx. 1,100 g (module with housing)
- Compliance: CE, RoHS; designed to IEC 61131-2 standards
- Communication Bus: PCU internal backplane bus
- Diagnostics: Per-channel LED status indicators; fault reporting via backplane
Proven Application Environments
- Process automation and distributed control systems (DCS integration)
- Discrete manufacturing lines requiring high-density digital I/O expansion
- Water treatment and utilities infrastructure control panels
- Oil & gas upstream/downstream field instrumentation interfaces
- Building management and HVAC automation systems
- Machine safety interlocking and emergency shutdown (ESD) circuits
- Retrofit and upgrade projects replacing legacy I/O modules in PCU racks
Engineering Advantages
- High Channel Density: Maximizes I/O count per rack slot, reducing overall panel footprint and wiring complexity.
- Optical Isolation: Protects the control bus from field-side transients, ground loops, and EMI — critical in electrically noisy industrial environments.
- Hot-Swap Compatibility: Supports module replacement without full system shutdown (subject to PCU rack configuration), minimizing process downtime.
- Unified Platform Integration: Native compatibility with the PCU backplane eliminates the need for external signal converters or protocol gateways.
- Diagnostic Transparency: Per-channel LED indicators and backplane fault reporting enable rapid fault isolation during commissioning and maintenance.
- Broad Signal Compatibility: Accepts standard 24 VDC discrete signals from a wide range of sensors, proximity switches, and actuator feedback contacts.
System Architecture & Signal Flow
The PCU-DPIO slots directly into a PCU-series rack backplane. Field wiring connects to the module’s front-face terminal block or connector. Digital input signals are conditioned, optically isolated, and passed to the backplane bus for processing by the PCU controller. Digital output signals are driven from the backplane through the isolation stage to field actuators. The module’s onboard diagnostics continuously monitor channel status and report faults upstream to the controller’s diagnostic register, enabling SCADA/HMI alarm annunciation without additional hardware.
Sourcing & Quality Verification
- Source: Konmask.com sources PCU-DPIO modules through authorized distribution channels and verified secondary-market suppliers with full traceability documentation.
- Inspection: Every unit undergoes visual inspection, label authenticity verification, and functional pre-shipment checks prior to dispatch.
- Condition: New (factory-sealed) and refurbished (tested, warranted) stock available — specify at time of inquiry.
- Documentation: Certificate of conformance, test reports, and original manufacturer documentation available upon request.
- Anti-Counterfeit: All units verified against Molex genuine part markings and date codes. Counterfeit units are rejected and not listed.
Procurement Process
- Submit RFQ: Contact support@konmask.com or call +0086 19859288691 with your required quantity, delivery timeline, and any documentation requirements.
- Quotation: Receive a formal quotation within 1 business day, including unit price, lead time, and shipping options (DHL / FedEx / sea freight).
- Order Confirmation: Place order via the Konmask.com storefront or by purchase order (PO) for B2B accounts.
- Quality Check & Dispatch: Units are inspected, packed, and dispatched with full shipping documentation (commercial invoice, packing list, COC).
- After-Sales Support: Technical support and warranty claims handled directly by Konmask.com engineering team.
Technical FAQ
Q: Is the PCU-DPIO compatible with third-party PCU-format racks?
A: The PCU-DPIO is designed for Molex PCU-series backplanes. Compatibility with third-party racks depends on backplane pinout and bus protocol — contact us for a compatibility assessment before ordering.
Q: What is the maximum cable length for field wiring to the PCU-DPIO?
A: For 24 VDC digital signals, cable runs up to 300 m are generally supported with appropriate cable gauge (≥0.75 mm²) and shielding in high-EMI environments. Consult the Molex PCU installation manual for site-specific guidance.
Q: Can the module be used in SIL-rated safety applications?
A: The PCU-DPIO is a general-purpose module and is not independently SIL-certified. For safety-rated applications, consult Molex’s safety-specific I/O module range and your functional safety engineer.
Q: What warranty is provided?
A: Konmask.com provides a 12-month warranty on all verified units covering manufacturing defects and functional failure under normal operating conditions. Extended warranty options available on request.
Q: Do you offer volume pricing for OEM or system integrator orders?
A: Yes. Volume discounts and blanket order agreements are available for qualified OEM and SI accounts. Contact our sales team for a tailored commercial proposal.
