EMERSON KJ3002X1-BF1 12P1732X042 RTD Input Module | Replacement, Equivalent & Selection Guide
The EMERSON KJ3002X1-BF1 (Part No. 12P1732X042) is a dedicated RTD (Resistance Temperature Detector) input module designed for the DeltaV™ Distributed Control System. It provides high-accuracy temperature measurement for process-critical applications in oil & gas, chemical, power, and pharmaceutical industries. This page serves as a comprehensive selection and replacement reference for engineers and procurement teams.
Technical Specifications
- Manufacturer: Emerson Electric / Fisher-Rosemount
- Part Number: KJ3002X1-BF1
- Reference Number: 12P1732X042
- Module Type: RTD Input Module
- Platform: DeltaV™ DCS (S-series / M-series)
- Input Channels: 8 channels (differential RTD inputs)
- Supported Sensor Types: PT100, PT200, PT500, PT1000, Ni100, Ni120, Cu10
- Measurement Range: −200°C to +850°C (sensor-dependent)
- Accuracy: ±0.1°C typical
- Resolution: 0.01°C
- Communication: DeltaV I/O bus (proprietary)
- Power Supply: Supplied via DeltaV carrier/backplane
- Isolation: Channel-to-channel and channel-to-bus isolation
- Operating Temperature: 0°C to +60°C
- Humidity: 5% to 95% RH, non-condensing
- Certifications: CE, FM, CSA (refer to official datasheet for current approvals)
- Form Factor: DeltaV I/O card, standard carrier-mount
- Weight: Approx. 200 g
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or functional equivalents. Always verify electrical, firmware, and bus compatibility before substitution.
- EMERSON KJ3002X1-BA1 — Earlier revision of the same RTD input module; functionally equivalent, check firmware compatibility.
- EMERSON KJ3002X1-BC1 — Mid-revision variant; same channel count and sensor support.
- EMERSON KJ3002X1-BE1 — Alternate approved revision; confirm with DeltaV system version.
- EMERSON KJ3002X1-BG1 — Later revision with potential firmware enhancements; backward compatible in most DeltaV versions.
- EMERSON KJ3002X1-BH1 — Current production revision (verify availability); drop-in replacement in DeltaV S-series.
- Third-party RTD Input Modules — Some third-party DeltaV-compatible I/O modules exist; however, Emerson does not officially certify non-OEM modules for DeltaV. Use with caution and consult your system integrator.
Note: Revision letters (BA1, BC1, BF1, BG1, BH1) indicate hardware/firmware revisions. Functional differences are typically minor, but always cross-reference with your DeltaV system version and Emerson’s compatibility matrix.
Why Choose the Original Model
- OEM Guaranteed Compatibility: Designed and validated exclusively for the DeltaV DCS platform — no integration risk.
- High Measurement Accuracy: ±0.1°C accuracy ensures reliable temperature control in critical process loops.
- Multi-Sensor Support: Supports PT100/PT200/PT500/PT1000, Ni100, Ni120, Cu10 — maximum flexibility for mixed installations.
- Proven Field Reliability: Widely deployed in refineries, chemical plants, and power stations globally.
- Full DeltaV Integration: Plug-and-play with DeltaV S-series and M-series carriers; recognized automatically by DeltaV Explorer.
- Regulatory Compliance: Meets CE, FM, and CSA requirements for hazardous and non-hazardous area installations.
Typical Applications
- Temperature monitoring in oil & gas upstream/downstream processes
- Reactor temperature control in chemical and petrochemical plants
- Boiler and turbine temperature measurement in power generation
- Pharmaceutical batch process temperature validation (FDA 21 CFR Part 11 environments)
- Food & beverage pasteurization and CIP temperature loops
- HVAC and building automation systems integrated with DeltaV
- Water and wastewater treatment temperature monitoring
System Compatibility
- DCS Platform: Emerson DeltaV™ S-series, M-series
- Compatible Carriers: DeltaV 8-slot and 12-slot I/O carriers
- DeltaV Software: Compatible with DeltaV v10.x, v11.x, v12.x, v13.x, v14.x (verify with Emerson for latest version support)
- Controller Compatibility: MD, MD Plus, MQ, PK, SD, SX controllers
- Not Compatible With: DeltaV SIS (Safety Instrumented System) carriers; PROVOX or RS3 legacy systems
Selection Guide
Use the following criteria to confirm the KJ3002X1-BF1 is the right module for your application:
- Step 1 — Confirm DCS Platform: Verify your system is DeltaV S-series or M-series. This module is not compatible with other Emerson platforms (PROVOX, RS3, Ovation).
- Step 2 — Identify Sensor Type: Confirm your field sensors are RTD type (PT100, PT200, Ni100, etc.). For thermocouple inputs, consider the KJ3001X1 series instead.
- Step 3 — Count Input Channels: KJ3002X1-BF1 provides 8 RTD input channels. For higher channel density, evaluate multi-channel I/O solutions or additional modules.
- Step 4 — Check Revision Compatibility: Confirm your DeltaV version supports the BF1 revision. Older DeltaV versions may require earlier revisions (BA1, BC1).
- Step 5 — Verify Carrier Slot Availability: Ensure your I/O carrier has an available slot. The module occupies one standard DeltaV I/O slot.
- Step 6 — Hazardous Area Requirements: If installing in a classified hazardous area, confirm the module’s certifications meet your area classification (Zone 2 / Div. 2 or higher).
Quality Assurance & Sourcing
- Source: Konmask.com sources modules from authorized distributors, certified refurbishers, and verified surplus channels.
- Inspection: All units undergo visual inspection, label verification, and functional pre-check before shipment.
- Authenticity: We do not sell counterfeit or cloned modules. Provenance documentation available on request.
- Warranty: 90-day replacement warranty on all stocked units (terms apply).
- Lead Time: In-stock units ship within 1–3 business days. Out-of-stock items subject to sourcing lead time (typically 2–6 weeks).
- Export Compliance: Buyers are responsible for verifying import/export regulations applicable to their jurisdiction.
How to Order
- Confirm part number: KJ3002X1-BF1 / 12P1732X042
- Specify required quantity and preferred condition (new / refurbished / surplus).
- Contact us via email or phone for a formal quotation and lead time confirmation.
- Submit purchase order with delivery address and any special packaging/documentation requirements.
- Receive order confirmation, proforma invoice, and shipping tracking upon dispatch.
Contact: support@konmask.com | +0086 19859288691
Replacement & Compatibility FAQ
Q: Can I replace KJ3002X1-BF1 with KJ3002X1-BH1 (a newer revision)?
A: In most DeltaV installations, yes. Newer revisions are generally backward compatible. However, always verify with your DeltaV system version and Emerson’s compatibility matrix before substitution in a live system.
Q: Is KJ3002X1-BF1 compatible with DeltaV SIS (Safety Instrumented System)?
A: No. DeltaV SIS uses dedicated SIS I/O modules. The KJ3002X1-BF1 is a standard DeltaV I/O module and must not be used in SIS applications.
Q: Can this module be used with third-party DCS systems?
A: No. The KJ3002X1-BF1 communicates via Emerson’s proprietary DeltaV I/O bus and is not compatible with other DCS platforms (Honeywell, ABB, Siemens, Yokogawa, etc.).
Q: What is the difference between part number KJ3002X1-BF1 and reference number 12P1732X042?
A: KJ3002X1-BF1 is the Emerson catalog/ordering part number. 12P1732X042 is the internal reference/revision number. Both refer to the same physical module.
Q: Do you provide a certificate of conformance (CoC) or test report?
A: Yes, documentation is available upon request for most units. Please specify your requirements at the time of inquiry.
Q: Can I use PT1000 sensors with this module?
A: Yes, the KJ3002X1-BF1 supports PT1000 sensors in addition to PT100, PT200, PT500, Ni100, Ni120, and Cu10.
