Process Control & HART Instrumentation Solution — EMERSON KJ3221X1-BA1 | DeltaV S-Series
The EMERSON KJ3221X1-BA1 (Part No. 12P2531X122) is a dedicated Analog Output HART Module engineered for the DeltaV S-Series distributed control system. Designed for precision signal conditioning and HART communication in demanding process environments, this module is the preferred choice of control engineers across refining, chemical, and power generation industries.
Where This Product Is Used
This module is deployed in mission-critical process automation applications where reliable 4–20 mA analog output with HART protocol communication is required:
- Oil & Gas Refineries — Control valve positioners, flow control loops, and pressure regulation in upstream/downstream processes.
- Chemical & Petrochemical Plants — Reactor temperature and feed rate control requiring precise analog output with device diagnostics via HART.
- Power Generation Facilities — Turbine control systems, boiler feed water regulation, and auxiliary process loops.
- Pulp & Paper Mills — Stock flow, pressure, and level control integrated into DeltaV DCS architectures.
- Water & Wastewater Treatment — Pump speed control, dosing systems, and valve actuation with remote HART diagnostics.
- Pharmaceutical Manufacturing — GMP-compliant process control loops requiring validated analog output modules.
- Food & Beverage Processing — CIP/SIP process control and temperature management in hygienic environments.
Technical Specifications
| Manufacturer | Emerson Electric / Fisher-Rosemount |
| Model Number | KJ3221X1-BA1 |
| Part Number | 12P2531X122 |
| Module Type | Analog Output HART Module |
| Compatible Platform | Emerson DeltaV S-Series DCS |
| Output Signal | 4–20 mA with HART Protocol (Rev. 5/6/7) |
| Output Channels | 8 Channels (typical for S-Series AO) |
| Communication | HART (Highway Addressable Remote Transducer) |
| Power Supply | Supplied via DeltaV S-Series carrier/backplane |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Weight | 3,200 g (shipping weight) |
| Compliance | CE, UL, FM, ATEX (refer to datasheet) |
Note: Always verify specifications against the official Emerson DeltaV S-Series datasheet for your specific revision. Contact us for the latest revision documentation.
Why Engineers Specify This Model
- Native DeltaV Integration — Plug-and-play compatibility with DeltaV S-Series carriers; auto-recognized by DeltaV Explorer with no manual configuration required.
- HART Pass-Through — Enables simultaneous 4–20 mA control and HART digital communication for remote device diagnostics, calibration, and asset management via AMS Device Manager.
- High Channel Density — Maximizes I/O per carrier slot, reducing cabinet footprint and wiring costs in large-scale DCS installations.
- Proven Field Reliability — Widely deployed in SIL-rated and non-SIL process loops; extensive installed base across global process industries.
- Hot-Swap Capable — Supports online replacement without process shutdown when used with redundant DeltaV configurations.
- AMS Integration — Full compatibility with Emerson AMS Suite for predictive maintenance and HART device health monitoring.
Complete System Bill of Materials
For a complete DeltaV S-Series Analog Output HART subsystem, the following components are typically required:
- KJ3221X1-BA1 — Analog Output HART Module (this item)
- KJ3001X1-BA1 — DeltaV S-Series 8-Slot Carrier
- KJ3002X1-BA1 — DeltaV S-Series Power Supply Module
- KJ3003X1-BA1 — DeltaV S-Series Controller Module
- VE3008 — DeltaV S-Series I/O Subsystem Termination Assembly
- AMS Device Manager — Emerson asset management software for HART diagnostics
- Marshalling Cabinet / Field Junction Box — Site-specific; consult your system integrator
Konmask.com can source multiple BOM line items. Contact us for bundle pricing on complete subsystem packages.
Compliance & Industry Standards
- HART Protocol — HART Communication Foundation certified (Rev. 5, 6, 7 compatible)
- CE Marking — Compliant with EU Machinery Directive and EMC Directive
- UL Listed — Underwriters Laboratories certification for North American markets
- FM Approved — Factory Mutual approval for hazardous area applications (verify area classification)
- ATEX / IECEx — Consult Emerson documentation for zone-rated variants
- IEC 61511 / IEC 61508 — Suitable for use in SIL-assessed safety loops (SIL rating per Emerson SIL datasheet)
- RoHS Compliant — Restriction of Hazardous Substances Directive compliant
Quality Assurance & Sourcing
At Konmask.com, every module undergoes a structured verification process before shipment:
- Physical Inspection — Label verification (part number, revision, serial number), housing integrity check, and connector pin inspection.
- Provenance Verification — Supply chain documentation reviewed; modules traced to authorized distributors or decommissioned OEM installations where applicable.
- Functional Pre-Check — Where test equipment is available, modules are powered and basic I/O functionality is confirmed prior to dispatch.
- Secure Packaging — ESD-safe anti-static bags, foam-lined boxes, and moisture-barrier packaging for international shipment.
We maintain transparent sourcing records and can provide available documentation upon request. All modules are sold with a 90-day return-to-base warranty against DOA (Dead on Arrival) defects.
How to Source This Part
- Confirm Your Requirement — Verify the part number (KJ3221X1-BA1 / 12P2531X122) against your DeltaV system documentation or existing module label.
- Request a Quote — Email support@konmask.com or call +0086 19859288691 with your quantity and required delivery timeline.
- Receive Availability & Pricing — We respond within 1 business day with stock status, pricing in your preferred currency, and lead time.
- Order Confirmation — Purchase order or proforma invoice issued; payment via T/T, PayPal, or other agreed terms.
- Shipment & Tracking — Dispatched via DHL / FedEx / UPS with full tracking. Export documentation (commercial invoice, packing list, COO) provided for customs clearance.
- After-Sales Support — Technical support available post-delivery for installation queries and compatibility confirmation.
Application-Specific FAQ
Q: Is the KJ3221X1-BA1 compatible with DeltaV M-Series or Classic DeltaV controllers?
A: No. This module is designed specifically for the DeltaV S-Series I/O subsystem. It is not backward-compatible with DeltaV M-Series or Classic (pre-S-Series) hardware. For M-Series, the equivalent module is the KJ3221X1-BA1’s M-Series counterpart — contact us to confirm the correct part for your system.
Q: Can this module be used in SIL 2 safety loops?
A: The KJ3221X1-BA1 may be suitable for SIL-assessed applications depending on your safety architecture. Refer to the Emerson DeltaV SIL datasheet and consult your functional safety engineer. Konmask.com does not provide SIL certification services.
Q: Do you supply new or refurbished modules?
A: We supply both new (surplus/unused) and professionally refurbished modules. Condition is clearly stated in your quotation. All modules are tested and verified before shipment regardless of condition grade.
Q: What is the lead time for this part?
A: Lead time depends on current stock. In-stock items ship within 3–5 business days. Out-of-stock items typically have a 2–6 week lead time depending on global sourcing. Contact us for real-time availability.
Q: Can you supply the matching DeltaV S-Series carrier and power supply?
A: Yes. Konmask.com can source complete DeltaV S-Series subsystem components. Provide your full BOM and we will quote accordingly.
Q: Do you provide export documentation for international orders?
A: Yes. We provide commercial invoice, packing list, certificate of origin, and HS code declaration for all international shipments. We ship to over 50 countries.
