EMERSON KJ3241X1-BA1 – DeltaV Serial Interface Card | DeltaV S-Series Platform
Engineering Background
The KJ3241X1-BA1 (part number 12P2506X072) is a serial interface card engineered by Emerson Electric for integration within the DeltaV distributed control system (DCS) platform. Designed to bridge legacy serial communication protocols with modern DeltaV S-Series controllers, this card enables seamless data exchange between field devices and the DeltaV control network in demanding process environments.
Product Positioning
Targeted at process automation engineers and system integrators managing brownfield upgrades or multi-protocol plant architectures, the KJ3241X1-BA1 delivers reliable serial I/O connectivity without requiring full system replacement. It is the preferred interface solution for facilities operating Emerson DeltaV S-Series controllers where RS-232/RS-485 serial device integration is required.
Complete Technical Specifications
- Manufacturer: Emerson Electric (Emerson Process Management)
- Part Number: KJ3241X1-BA1
- Reference Number: 12P2506X072
- Module Type: Serial Interface Card
- Platform Compatibility: Emerson DeltaV S-Series DCS
- Communication Protocol: RS-232 / RS-485 Serial
- Form Factor: DeltaV S-Series card module
- Weight: Approx. 200 g
- Country of Origin: United States
- Condition: New / Refurbished OEM (specify at inquiry)
- Warranty: 12-month Konmask quality guarantee
Proven Application Environments
- Oil & gas upstream/downstream process control
- Chemical and petrochemical plant automation
- Power generation and utilities DCS integration
- Pharmaceutical batch process control systems
- Pulp, paper, and continuous manufacturing lines
- Brownfield DeltaV migration and serial device retrofit projects
Engineering Advantages
- Protocol Bridging: Connects RS-232/RS-485 serial field devices directly to the DeltaV S-Series backplane without external converters.
- Hot-Swap Capable: Supports DeltaV’s standard card replacement procedures, minimizing process downtime during maintenance.
- OEM Firmware Compatibility: Fully compatible with DeltaV system software; no custom driver development required.
- Robust Industrial Design: Rated for continuous operation in high-vibration, high-humidity industrial environments.
- Backward Compatibility: Integrates legacy serial instrumentation into modern DeltaV architectures, protecting existing capital investment.
System Architecture & Signal Flow
The KJ3241X1-BA1 installs into a DeltaV S-Series controller carrier and communicates via the DeltaV internal bus. Serial field devices connect to the card’s RS-232/RS-485 port. Data is processed by the DeltaV controller and transmitted over the DeltaV control network to operator workstations and historian servers. The card supports standard DeltaV module addressing and is configured via DeltaV Explorer, requiring no additional hardware or software licenses beyond the standard DeltaV system.
Sourcing & Quality Verification
- All units sourced from authorized distributors or directly from decommissioned OEM-maintained installations.
- Each card undergoes incoming inspection: visual check, label verification (part number, revision, date code), and functional power-on test where applicable.
- Serialization and firmware revision documented prior to shipment.
- Anti-static packaging with humidity indicator card included.
- Certificate of conformance available upon request.
Procurement Process
- Inquiry: Submit your RFQ via the product page or email support@konmask.com with quantity and required condition (new/refurbished).
- Quotation: Receive a formal quotation with lead time, unit price, and shipping options within 24 business hours.
- Order Confirmation: Confirm PO; payment via T/T, PayPal, or credit card accepted.
- Quality Check & Dispatch: Unit inspected, documented, and dispatched with tracking within 1–3 business days.
- After-Sales Support: 12-month warranty; technical support available via email or phone.
Technical FAQ
Q: Is the KJ3241X1-BA1 compatible with DeltaV M-Series controllers?
A: No. This card is designed specifically for the DeltaV S-Series platform. For M-Series compatibility, please contact us for the correct interface card model.
Q: What serial protocols does this card support?
A: The card supports RS-232 and RS-485 serial communication. Specific protocol support (Modbus RTU, etc.) depends on the DeltaV system configuration and licensed protocol drivers.
Q: Can I use this card in a redundant DeltaV controller configuration?
A: Please confirm your controller redundancy configuration with our technical team prior to ordering to ensure full compatibility.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. Out-of-stock lead times vary; contact us for current availability.
Q: Do you provide a test report or certificate of conformance?
A: Yes. Documentation is available upon request at no additional charge.
