Emerson MVME215-3 – VMEbus 6U DRAM Memory Module | Motorola MVME200 Series
Engineering Background
The MVME215-3 is a VMEbus-compatible 6U memory expansion module developed under the Motorola Embedded Computing platform, now maintained under the Emerson Network Power (Artesyn) product lineage. Designed for mission-critical embedded computing environments, it provides reliable DRAM expansion for VME-based CPU boards operating in industrial control, process automation, and defense-grade applications.
Product Positioning
Targeted at procurement engineers and system integrators maintaining legacy VMEbus architectures, the MVME215-3 delivers a verified, drop-in memory upgrade path for MVME-series single-board computers. Konmask.com supplies this module from authenticated surplus and refurbished channels with full functional verification.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | MVME215-3 |
| Manufacturer | Motorola / Emerson Network Power |
| Series | MVME200 Memory Module Series |
| Form Factor | VMEbus 6U |
| Memory Type | DRAM (Dynamic RAM) |
| Memory Capacity | 4 MB |
| Bus Interface | VMEbus (IEEE 1014) |
| Data Width | 32-bit |
| Operating Voltage | +5 VDC (VMEbus standard) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Board Dimensions | 6U VME (233.35 mm × 160 mm) |
| Weight | Approx. 800 g (packaged) |
| Compliance | VMEbus IEEE 1014, CE |
| Condition | Surplus / Refurbished – Fully Tested |
Proven Application Environments
- DCS (Distributed Control Systems): Memory expansion for VME-based DCS controllers in oil & gas, chemical, and power generation plants.
- PLC & Motion Control: Supplemental DRAM for high-scan-rate PLC backplanes using VMEbus architecture.
- SCADA & HMI Systems: Extended memory for real-time data acquisition nodes in utility and water treatment infrastructure.
- Defense & Aerospace: Ruggedized VME memory expansion in radar, sonar, and avionics test systems.
- Telecommunications: Carrier-grade VME chassis memory augmentation for legacy switching and routing platforms.
Engineering Advantages
- Direct VMEbus Compatibility: Plug-and-play integration with all MVME-series CPU boards supporting VMEbus memory expansion slots.
- High Reliability DRAM: Industrial-grade DRAM ICs rated for extended temperature and vibration environments.
- Zero Firmware Modification: Recognized natively by MVME CPU boards without BIOS or firmware changes.
- Legacy System Longevity: Extends operational life of VMEbus systems without costly platform migration.
- ESD-Protected Design: Full electrostatic discharge protection on all signal lines per VMEbus specification.
System Architecture & Signal Flow
The MVME215-3 interfaces directly to the VMEbus P1/P2 connector rows, presenting its DRAM address space to the VMEbus master (CPU board) via the standard A32/D32 address and data lines. Memory arbitration is handled by the VMEbus system controller on the host CPU board. The module operates as a VMEbus slave device, responding to memory read/write cycles initiated by the master CPU. No additional configuration jumpers are required for standard 4MB address mapping; optional address offset jumpers allow conflict-free co-installation with other memory modules in multi-slot VME chassis.
Sourcing & Quality Verification
- Source: Authenticated surplus and decommissioned industrial system stock.
- Inspection: Visual inspection for PCB damage, corrosion, and component integrity.
- Functional Test: Full memory read/write cycle verification on VMEbus test bench prior to shipment.
- Packaging: Anti-static bag + foam-lined carton; humidity indicator card included.
- Traceability: Serial number and date code recorded per unit; available on request.
Procurement Process
- Submit RFQ via support@konmask.com or place order directly on Konmask.com.
- Receive stock confirmation and lead time within 1 business day.
- Pro-forma invoice issued; payment via T/T, PayPal, or credit card.
- Unit ships within 2–3 business days after payment clearance.
- DHL / FedEx express delivery; tracking number provided same day as dispatch.
- 30-day DOA (Dead on Arrival) warranty; technical support available post-delivery.
Technical FAQ
Q: Is the MVME215-3 compatible with MVME162 and MVME167 CPU boards?
A: Yes. The MVME215-3 is compatible with all MVME-series CPU boards that support VMEbus memory expansion via the P1/P2 connector, including MVME162, MVME167, MVME172, and MVME177.
Q: Can multiple MVME215-3 modules be installed in the same chassis?
A: Yes, provided the VME chassis has sufficient slots and the address maps are configured to avoid overlap using the onboard address offset jumpers.
Q: What is the difference between MVME215-1, MVME215-2, and MVME215-3?
A: The suffix denotes memory capacity variants: -1 = 1MB, -2 = 2MB, -3 = 4MB DRAM. The MVME215-3 is the highest-capacity variant in the MVME215 series.
Q: Do you provide a test report with the unit?
A: Yes. A functional test report is available upon request at no additional charge.
Q: What is the lead time for the MVME215-3?
A: In-stock units ship within 2–3 business days. For out-of-stock inquiries, typical sourcing lead time is 5–15 business days.
