Vibration & Shaft Displacement Monitoring Solution – EMERSON PR6424/002-130 CON021 | Epro Series
Where This Product Is Used
The EMERSON PR6424/002-130 CON021 eddy-current displacement sensor is deployed in mission-critical rotating machinery protection and condition monitoring systems across heavy industry. Typical installation environments include:
- Steam & Gas Turbines – Shaft radial vibration and axial position monitoring per API 670 requirements
- Centrifugal Compressors – Real-time rotor displacement tracking in petrochemical and LNG plants
- Large Pumps & Fans – Continuous bearing clearance surveillance in power generation facilities
- Gearboxes & Expanders – Differential expansion and eccentricity measurement in refineries
- Marine Propulsion Systems – Shaft monitoring in offshore platforms and vessel drive trains
- Hydro Turbines – Thrust bearing axial position sensing in hydroelectric stations
Wherever unplanned downtime carries six-figure-per-hour costs, engineers specify the PR6424 series for its proven reliability and direct compatibility with Epro MMS 6000 / 3000 series protection systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | EMERSON (Epro) |
| Part Number | PR6424/002-130 CON021 |
| Sensor Type | Eddy-Current (Non-Contact) Displacement Sensor |
| Probe Tip Diameter | 8 mm |
| Cable Length | 2 m (integral cable) |
| Extension Cable | CON021 (included / specified) |
| Measuring Range | 0 – 2 mm (nominal linear range) |
| Sensitivity | 8 mV/µm (typical, with matched driver) |
| Operating Temperature | -40 °C to +120 °C (probe); -40 °C to +85 °C (cable) |
| Target Material | Steel / Stainless Steel (AISI 4140 reference) |
| Supply Voltage | -24 VDC (via driver/proximitor) |
| Output Signal | Voltage proportional to gap (matched with PR6423/PR6424 driver) |
| Protection Rating | IP67 (probe body) |
| Weight | Approx. 200 g (probe + cable assembly) |
| Connector | CON021 standard Epro connector |
| Compliance | API 670, CE, ATEX (consult datasheet for zone rating) |
Specifications are reference values. Always verify against the official EMERSON Epro datasheet for your specific application.
Why Engineers Specify This Model
- Direct API 670 Compliance – Designed from the ground up to meet the machinery protection standard mandated by EPC contractors and end-users in oil & gas.
- System-Matched Accuracy – The PR6424/002-130 + CON021 combination is factory-calibrated as a matched set with EMERSON Epro drivers (PR6423 series), eliminating field calibration uncertainty.
- Non-Contact Measurement – Zero mechanical wear; sensor life is independent of shaft rotation speed or vibration amplitude.
- Robust Construction – IP67-rated probe body withstands oil mist, coolant splash, and high-humidity environments common in turbomachinery enclosures.
- Wide Temperature Range – Qualified from -40 °C to +120 °C, suitable for both arctic outdoor installations and hot-section turbine pedestals.
- Plug-and-Play with MMS 6000 / 3000 – Recognized natively by EMERSON Epro protection racks; no signal conditioning adapters required.
- Long Field Track Record – The PR6424 series has accumulated decades of installed-base hours in refineries, power plants, and offshore platforms worldwide.
Complete System Bill of Materials
A fully functional eddy-current displacement monitoring channel typically requires the following components. Konmask.com can source all items:
- Displacement Probe – PR6424/002-130 CON021 (this item)
- Proximitor / Driver – EMERSON Epro PR6423/010-000 or PR6423/010-010 (matched driver)
- Extension Cable – CON021 (integral to this assembly; verify total system cable length)
- Protection Rack Module – EMERSON MMS 6110 (radial vibration) or MMS 6120 (axial position)
- Power Supply – -24 VDC regulated supply or MMS rack PSU
- Mounting Hardware – Epro-compatible probe holder / bracket (application-specific)
- Relay Output Module – MMS 6823 or equivalent for alarm/trip relay outputs
Contact support@konmask.com with your full BOM for a consolidated quotation.
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (5th Edition) – primary design reference
- ISO 10816 / ISO 20816 – Mechanical vibration evaluation of machines
- IEC 60079 – Equipment for explosive atmospheres (ATEX; confirm zone classification with EMERSON datasheet)
- CE Marking – European conformity for electromagnetic compatibility and low-voltage directive
- RoHS – Restriction of Hazardous Substances compliance
Always request the current EMERSON Epro Declaration of Conformity and ATEX certificate for safety-critical installations.
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation and control system components for B2B buyers who cannot afford counterfeit or substandard parts in rotating machinery protection applications.
- Authorized & Verified Supply Chain – Parts sourced through documented distribution channels; traceability records available on request.
- Pre-Shipment Inspection – Each unit visually inspected and packaging integrity verified before dispatch.
- Authenticity Guarantee – Holographic labels, date codes, and serial numbers cross-referenced against manufacturer records where applicable.
- Warranty – 12-month warranty against manufacturing defects; replacement or full refund policy.
- Export Compliance – All shipments processed in accordance with applicable export control regulations (ECCN / HTS classification available on request).
How to Source This Part
- Add to Cart – Proceed directly if quantity and delivery timeline meet your requirements.
- Request a Quote – For orders of 2+ units, OEM pricing, or consolidated BOM quotations, email support@konmask.com with your PO number and required delivery date.
- Expedited Sourcing – If this part is showing out-of-stock or you need same-week dispatch, contact us via WhatsApp / phone: +0086 19859288691. We maintain relationships with multiple authorized distributors and can often locate stock within 24–48 hours.
- Technical Pre-Sales Support – Our engineers can confirm compatibility with your existing Epro rack configuration, cable lengths, and driver pairing before you commit to purchase.
Application-Specific FAQ
Q: Is the PR6424/002-130 CON021 compatible with non-EMERSON protection systems?
A: The probe outputs a standard voltage signal proportional to gap distance. It can interface with third-party monitors (Bently Nevada, Metrix, etc.) provided the driver/proximitor is matched and the input impedance is compatible. Consult your system integrator.
Q: What is the difference between PR6424/002-130 and PR6424/002-030?
A: The three-digit suffix after the hyphen denotes cable length in decimeters. /002-130 = 2 m probe + 130 cm (1.3 m) integral cable segment. Always verify total system cable length (probe + extension) matches your driver calibration.
Q: Can this sensor be used for axial position (thrust) measurement?
A: Yes. With the appropriate MMS 6120 axial position module and correct mounting orientation, the PR6424 series is widely used for thrust bearing axial position monitoring per API 670.
Q: What target material is required for accurate measurement?
A: The sensor is calibrated for AISI 4140 steel. Other ferromagnetic or conductive materials will shift the sensitivity curve. EMERSON provides correction factors for common alternative target materials.
Q: Do you provide installation and commissioning support?
A: Konmask.com provides remote technical support for installation queries. On-site commissioning services can be arranged through our partner network — contact us for details.
Q: What is the lead time for this part?
A: Standard lead time is 3–7 business days for in-stock units. Expedited options available. Contact us for real-time stock status.
