Process Control Solution – EMERSON SPMD1402 | DeltaV Series Universal Digital I/O Module
Where This Product Is Used
The EMERSON SPMD1402 Universal Digital I/O Module is engineered for demanding industrial environments where reliable digital signal management is critical. Typical deployment sites include:
- Oil & Gas Processing Plants – Monitoring valve open/close status, pump run/stop signals, and emergency shutdown (ESD) logic.
- Chemical & Petrochemical Facilities – Integrating field device status into DeltaV DCS for continuous process oversight.
- Power Generation & Utilities – Capturing breaker status, relay outputs, and interlock signals across high-voltage switchgear panels.
- Pharmaceutical Manufacturing – Supporting FDA-compliant batch control systems with discrete I/O for agitators, dosing pumps, and CIP valves.
- Water & Wastewater Treatment – Managing pump station controls, level switch inputs, and motor control center (MCC) feedback.
- Pulp & Paper / Mining – Handling high-density digital I/O in harsh, electrically noisy environments.
Technical Specifications
- Part Number / SKU: SPMD1402
- Manufacturer: Emerson Electric Co.
- Series: DeltaV™ Distributed Control System (DCS)
- Module Type: Universal Digital I/O
- I/O Channels: 16 configurable digital channels (input or output per channel)
- Input Voltage Range: 24 VDC nominal field signals
- Output Type: Solid-state discrete output (sourcing)
- Communication Bus: DeltaV internal backplane bus
- Isolation: Channel-to-channel and channel-to-bus optical isolation
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Humidity: 5% to 95% non-condensing
- Mounting: DeltaV carrier / backplane slot
- Weight: Approx. 700 g
- Certifications: CE, UL, FM (Class I, Div. 2), ATEX (Zone 2)
Why Engineers Specify This Model
- Universal Channel Flexibility: Each of the 16 channels can be independently configured as digital input or output — eliminating the need for separate DI and DO modules and reducing spare-parts inventory.
- Hot-Swap Capability: Supports online insertion and removal without process interruption, critical for high-availability continuous process plants.
- Native DeltaV Integration: Plug-and-play on DeltaV carriers with automatic module recognition; no manual addressing required.
- Robust Isolation: Optical isolation on every channel protects the controller backplane from field-side transients and ground loops.
- Diagnostics & HART Pass-Through: Built-in channel-level diagnostics surface faults directly in DeltaV Explorer for rapid troubleshooting.
- Proven Field Record: Widely deployed across Emerson’s global installed base in refining, LNG, and specialty chemical sectors.
Complete System Bill of Materials
For a fully operational DeltaV digital I/O node, engineers typically specify the following alongside the SPMD1402:
- DeltaV M-Series or S-Series Controller (e.g., MD Plus, SD Plus)
- DeltaV 8-Slot or 12-Slot Carrier (EMERSON VE4001S2T1B4 or equivalent)
- DeltaV Power Supply Module (PS2 or PS5)
- DeltaV Redundant Power Supply (optional, for SIL-rated loops)
- Marshalling Cabinet / Terminal Blocks (Phoenix Contact or Weidmüller)
- DeltaV Workstation with DeltaV Operate / DeltaV Configure licenses
- Fieldbus Junction Box (for FOUNDATION Fieldbus segments, if applicable)
Compliance & Industry Standards
- IEC 61131-2 – Programmable controllers: Equipment requirements and tests
- IEC 61508 / IEC 61511 – Functional safety (SIL 2 capable in safety-instrumented system configurations)
- ATEX Directive 2014/34/EU – Zone 2 Group IIC T4 (with appropriate barriers)
- FM Class I, Division 2 – North American hazardous location approval
- CE Marking – EMC Directive 2014/30/EU compliance
- UL Listed – UL 508 industrial control equipment
- RoHS Compliant – Restriction of Hazardous Substances Directive
Quality Assurance & Sourcing
At Konmask.com, every EMERSON SPMD1402 unit is subject to our multi-point quality protocol before dispatch:
- ✔ Visual inspection for physical damage, pin integrity, and label authenticity
- ✔ Firmware version verification against Emerson’s published release matrix
- ✔ Anti-static packaging with humidity indicator cards
- ✔ Traceable lot documentation available on request
- ✔ 90-day functional warranty on all stocked units
We source exclusively from authorized distributors and verified surplus channels. Counterfeit-risk screening is applied to every incoming batch.
How to Source This Part
- Add to Cart – Click the purchase button above to place an order directly.
- Request a Quote – For volume orders (5+ units) or project-based procurement, email support@konmask.com for a formal quotation within 24 hours.
- Lead Time – In-stock units ship within 1–3 business days. Out-of-stock items: estimated 2–6 weeks depending on Emerson’s supply chain.
- Export & Cross-Border – We support international shipping with full commercial invoice, packing list, and HS code documentation for customs clearance.
- Payment – T/T (wire transfer), PayPal, and major credit cards accepted. Letter of Credit (L/C) available for orders above USD 10,000.
Application-Specific FAQ
Q: Can the SPMD1402 replace an older EMERSON MD Plus digital I/O module in an existing DeltaV system?
A: Yes, the SPMD1402 is backward-compatible with DeltaV v10.3 and later. Verify your DeltaV system version and carrier slot type before installation.
Q: Is the SPMD1402 suitable for SIL 2 safety loops?
A: The module can participate in SIL 2 safety instrumented functions when used with a certified DeltaV SIS controller and appropriate safety logic. Consult Emerson’s SIL data sheet (document D800001X012) for PFD values.
Q: What is the maximum cable length for field wiring to the SPMD1402?
A: Emerson recommends a maximum of 300 m (1,000 ft) for 24 VDC digital signals using 0.5 mm² (20 AWG) shielded twisted-pair cable. Longer runs require voltage drop calculations.
Q: Does the module support NAMUR-level sensors (IEC 60947-5-6)?
A: The SPMD1402 is designed for standard 24 VDC discrete signals. For NAMUR proximity sensors, an external NAMUR signal conditioner/barrier is required before the module input.
Q: Can I mix input and output channels within the same module?
A: Yes. Each channel is independently configurable as DI or DO via DeltaV Explorer software — no hardware jumpers required.
