Process Monitoring Solution – Endress+Hauser CPM223-MR0005 | Liquiline CM223
Where This Product Is Used
The Endress+Hauser CPM223-MR0005 is a field-proven digital pressure transmitter from the Liquiline CM223 platform, engineered for continuous process monitoring in demanding industrial environments. Engineers and plant operators specify this unit across the following sectors:
- Water & Wastewater Treatment – Monitoring filter differential pressure, pump station pressure, and distribution network integrity.
- Chemical & Petrochemical Plants – Reactor vessel pressure supervision, pipeline leak detection, and safety interlock systems.
- Food & Beverage Processing – CIP/SIP-compatible pressure measurement in hygienic process lines.
- Pharmaceutical Manufacturing – Clean-room compatible pressure monitoring with traceable calibration records.
- Power Generation – Boiler feed water pressure, steam header monitoring, and cooling circuit supervision.
- Oil & Gas Upstream/Midstream – Wellhead pressure monitoring and pipeline SCADA integration.
Technical Specifications
| Parameter | Value |
|---|---|
| Model / SKU | CPM223-MR0005 |
| Series | Liquiline CM223 |
| Manufacturer | Endress+Hauser |
| Device Type | Digital Pressure Transmitter |
| Output Signal | 4–20 mA HART / Digital |
| Communication Protocol | HART 7, Modbus RTU (optional) |
| Power Supply | 10.5–45 V DC (2-wire loop-powered) |
| Enclosure Protection | IP66 / IP67 (NEMA 4X) |
| Ambient Temperature | −40 °C to +85 °C |
| Display | Backlit LCD, 4-line alphanumeric |
| Approvals | ATEX, IECEx, FM, CSA (zone-dependent) |
| Weight | 1.2 kg |
Why Engineers Specify This Model
- Plug-and-Play HART Integration – Native HART 7 support enables seamless integration with existing DCS/SCADA systems (Siemens PCS 7, Emerson DeltaV, Honeywell Experion) without additional signal converters.
- Robust IP67 Enclosure – Withstands high-pressure washdowns and outdoor installation without additional weatherproofing.
- Wide Ambient Temperature Range – Operates reliably from −40 °C to +85 °C, suitable for arctic pipelines and high-temperature process areas.
- Liquiline Platform Ecosystem – Shares the same operating concept and spare parts pool as other Liquiline CM series devices, reducing technician training time and spare-parts inventory cost.
- Long-Term Availability – Endress+Hauser guarantees spare parts availability for a minimum of 10 years post-production, protecting capital investment.
Complete System Bill of Materials
For a complete pressure monitoring loop using the CPM223-MR0005, engineers typically specify the following complementary components:
- Process connection adapter / manifold (2- or 5-valve)
- HART modem or field communicator (e.g., Endress+Hauser Field Xpert SMT70)
- DIN-rail HART multiplexer for multi-drop installations
- Surge protection barrier (e.g., Endress+Hauser HAW562)
- Junction box / terminal head (M20 or ½” NPT cable entry)
- Stainless steel impulse tubing and fittings (316L SS recommended)
Contact [email protected] for bundled BOM pricing.
Compliance & Industry Standards
- IEC 61508 (Functional Safety / SIL assessment available)
- ATEX Directive 2014/34/EU – Zone 1 & Zone 2 certified variants
- IECEx Scheme – Global hazardous area acceptance
- FM & CSA – North American hazardous location approvals
- RoHS 2011/65/EU compliant
- NAMUR NE 43 – Standardized signal levels for fault indication
- NAMUR NE 107 – Self-monitoring and diagnostics
Quality Assurance & Sourcing
Every CPM223-MR0005 unit supplied by Konmask.com undergoes the following verification process before dispatch:
- ✔ Serial number cross-referenced against Endress+Hauser global production database
- ✔ Factory calibration certificate included (traceable to national standards)
- ✔ Visual inspection for transit damage and seal integrity
- ✔ Original manufacturer packaging with tamper-evident seals
- ✔ 12-month warranty against manufacturing defects
We source exclusively from authorized Endress+Hauser distribution channels and certified industrial surplus partners. Counterfeit-free guarantee backed by documentation.
How to Source This Part
- Add to Cart – Click the purchase button above to place an order directly online.
- Request a Quote – For volume orders (>3 units) or project-based procurement, email [email protected] for a formal quotation within 24 hours.
- Lead Time – In-stock units ship within 1–3 business days. Ex-stock or special configurations: 2–6 weeks.
- Export & Customs – We handle export documentation (CO, packing list, commercial invoice) for international shipments. HS Code: 9026.20.
- Payment – T/T bank transfer, PayPal, and major credit cards accepted. LC available for orders > USD 5,000.
Application-Specific FAQ
Q: Is the CPM223-MR0005 suitable for SIL 2 safety loops?
A: The Liquiline CM223 platform supports SIL assessment per IEC 61508. Contact us for the Safety Manual and FMEDA report specific to your SIL requirement.
Q: Can this transmitter be used in ATEX Zone 0?
A: The MR0005 configuration is rated for Zone 1/Zone 2. For Zone 0 applications, consult the Endress+Hauser product configurator for an intrinsically safe variant.
Q: What DCS systems is this compatible with?
A: Via HART 7, the CPM223-MR0005 integrates with all major DCS platforms including Siemens PCS 7, Emerson DeltaV, ABB System 800xA, Honeywell Experion PKS, and Yokogawa CENTUM VP.
Q: Is a local display included?
A: Yes. The MR0005 configuration includes a backlit 4-line LCD display for local process value readout and configuration without a handheld communicator.
Q: Do you provide calibration certificates?
A: Yes. Every unit ships with the original Endress+Hauser factory calibration certificate. Third-party re-calibration services are available upon request.
