ERNI EM-DIO-02 (9609 / 2445400132LS) – Digital Input/Output Module | EM Series Platform
Engineering Background
ERNI Electronics is a globally recognized Swiss-origin connector and electronic module manufacturer with decades of deployment in industrial automation, rail, and defense-grade control systems. The EM Series modular I/O platform was engineered to deliver deterministic digital signal handling in space-constrained panel environments, meeting the rigorous demands of IEC 61131-compliant PLC architectures.
Product Positioning
The EM-DIO-02 (part number 2445400132LS, catalog reference 9609) is a compact digital input/output expansion module designed for integration into ERNI EM Series backplane systems. It serves as a field-side interface between PLC controllers and discrete sensors, actuators, and relay-driven loads — making it a critical building block for machine builders, panel integrators, and OEM automation designers who require reliable, high-density I/O expansion without sacrificing signal integrity.
Complete Technical Specifications
| Manufacturer | ERNI Electronics |
| Series | EM Series Modular I/O |
| Model | EM-DIO-02 |
| Catalog Number | 9609 |
| Part Number | 2445400132LS |
| Module Type | Digital Input / Output (DIO) |
| I/O Configuration | Mixed Digital I/O (DI + DO) |
| Mounting | EM Series Backplane / DIN Rail compatible |
| Signal Standard | IEC 61131-2 compliant discrete I/O |
| Operating Voltage | 24 V DC (nominal) |
| Operating Temperature | -20°C to +60°C |
| Protection Class | IP20 (panel-mounted) |
| Weight | approx. 900 g (packaged) |
| Compliance | CE, RoHS |
| Condition | New / Surplus New / Refurbished (specify on inquiry) |
Note: Full datasheet available upon request. Specifications subject to revision per ERNI product bulletins.
Proven Application Environments
- Machine Tool & CNC Control Panels — discrete I/O expansion for spindle, axis, and safety interlocks
- Packaging & Conveyor Automation — sensor feedback and actuator control in high-cycle environments
- Building Automation Systems (BAS) — HVAC, lighting, and access control signal routing
- Rail & Transportation Control — vibration-tolerant I/O in rolling stock and trackside cabinets
- Process Industry (Oil, Gas, Water) — field device interfacing in IEC 61131-compliant SCADA/DCS architectures
- OEM Panel Builders — standardized I/O expansion across multi-project platforms
Engineering Advantages
- Modular Scalability — snap-on EM Series backplane expansion without rewiring; add I/O channels as system scope grows
- High Signal Density — compact form factor maximizes channel count per DIN rail unit width
- Deterministic Response — low-latency digital I/O suitable for time-critical PLC scan cycles
- Robust Isolation — optocoupler-based input isolation protects controller backplane from field-side transients
- Simplified Wiring — clearly labeled terminal blocks reduce commissioning time and wiring errors
- Long Service Life — ERNI’s industrial-grade component selection ensures MTBF performance in 24/7 operations
System Architecture & Signal Flow
The EM-DIO-02 integrates into the ERNI EM Series backplane via a direct bus connector, receiving power and communication from the host controller module. Field-side digital inputs are optically isolated before being presented to the backplane data bus; digital outputs are driven via solid-state or relay output stages (confirm output type with datasheet). The module is addressed automatically by the EM Series controller during backplane enumeration — no manual DIP-switch addressing required in standard configurations.
Typical Signal Flow: Field Sensor/Actuator → Terminal Block → Input Isolation Stage → Backplane Bus → PLC Controller → Output Driver → Terminal Block → Field Actuator/Load
Sourcing & Quality Verification
- All units sourced through verified industrial distribution and OEM surplus channels
- Physical inspection performed: housing integrity, connector condition, label legibility, and part number cross-check against ERNI catalog
- Functional test available on request for refurbished units
- Original manufacturer packaging preserved where available
- Certificate of Conformance (CoC) and test reports available for qualified orders
- Anti-counterfeit verification: ERNI holographic labels and date codes inspected prior to shipment
Procurement Process
- Confirm Compatibility — verify your EM Series controller model and backplane slot availability against the EM-DIO-02 datasheet
- Request Quote — contact support@konmask.com for volume pricing, lead time, and condition confirmation
- Place Order — purchase directly via this listing or via PO for B2B accounts
- Shipping & Documentation — units ship with packing list, CoC (on request), and tracking; export documentation available for international orders
- After-Sales Support — technical assistance available post-delivery for integration questions
Technical FAQ
Q: Is the EM-DIO-02 compatible with all ERNI EM Series controllers?
A: The EM-DIO-02 is designed for the ERNI EM Series backplane ecosystem. Compatibility depends on your specific controller firmware version and backplane configuration. Please share your controller model number for a definitive compatibility check.
Q: What is the difference between catalog number 9609 and part number 2445400132LS?
A: Catalog number 9609 is ERNI’s internal product line reference; 2445400132LS is the full ordering part number including packaging and specification suffix. Both refer to the same EM-DIO-02 module.
Q: Can I mix DI and DO channels on this module?
A: Yes — the EM-DIO-02 provides a mixed digital I/O configuration. Refer to the ERNI datasheet for the exact DI/DO channel split and electrical ratings per channel.
Q: Do you offer volume discounts for OEM or panel builder orders?
A: Yes. Contact us at support@konmask.com or call +0086 19859288691 for volume pricing and blanket order arrangements.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. For sourced or special-order quantities, lead time is typically 5–15 business days depending on availability.
