Arc Welding & Assembly Automation Solution – FANUC M-10iA | M-10i Series
Where This Product Is Used
The FANUC M-10iA is a high-speed, slim-body 6-axis articulated robot engineered for demanding industrial environments. Its compact wrist and hollow upper arm make it the preferred choice for applications where cable routing and confined-space access are critical:
- Arc Welding & MIG/TIG Welding Lines – Hollow wrist design routes welding cables internally, eliminating cable wear and improving weld repeatability in automotive and heavy fabrication plants.
- Robotic Assembly – Precise ±0.08 mm repeatability supports high-mix, low-volume electronics and mechanical sub-assembly cells.
- Material Handling & Pick-and-Place – 10 kg payload with 1422 mm reach covers standard conveyor-to-pallet transfer tasks in food, pharma, and consumer goods lines.
- Machine Tending – Slim arm profile allows deep reach into CNC machining centers and injection molding machines without fixture interference.
- Dispensing & Sealing – Smooth 6-axis motion path enables consistent bead application for adhesive, sealant, and coating processes.
- Inspection & Vision-Guided Handling – Compatible with FANUC iRVision for 2D/3D vision-guided pick, place, and quality inspection tasks.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | FANUC M-10iA |
| Series | M-10i Series |
| Axes | 6 |
| Payload Capacity | 10 kg |
| Maximum Reach | 1,422 mm |
| Repeatability | ±0.08 mm |
| Robot Mass | 130 kg |
| Mounting | Floor, Ceiling (inverted), Angle |
| Protection Rating | IP67 (wrist), IP54 (body) |
| Compatible Controller | FANUC R-30iA / R-30iB |
| Power Supply | 3-phase AC 200–230 V, 50/60 Hz |
| Ambient Temperature | 0–45 °C (operating) |
| Communication | EtherNet/IP, DeviceNet, PROFIBUS-DP, CC-Link |
Why Engineers Specify This Model
- Hollow Wrist & Arm Design – Internal cable/hose routing reduces external interference, extends cable life, and simplifies cell layout for welding and dispensing applications.
- High-Speed Cycle Performance – Optimized J4–J6 wrist inertia allows faster TCP speeds versus comparable payload-class robots, directly reducing cycle time.
- FANUC iRVision Ready – Native vision integration without third-party middleware reduces integration cost and commissioning time.
- Proven MTBF – FANUC robots are rated for 80,000+ hours MTBF; the M-10iA is widely deployed in 24/7 automotive production environments.
- Compact Footprint – 130 kg robot mass with a small installation envelope enables dense cell packing and easy retrofit into existing lines.
- Multi-Protocol Fieldbus – Native support for EtherNet/IP, PROFIBUS, DeviceNet, and CC-Link ensures compatibility with Siemens, Allen-Bradley, Mitsubishi, and Omron PLC architectures.
Complete System Bill of Materials
A fully operational FANUC M-10iA cell typically requires the following components:
- FANUC M-10iA Robot Manipulator (this unit)
- FANUC R-30iA or R-30iB Robot Controller
- iPendant Touch Teach Pendant
- Robot Mounting Base / Riser Plate
- End-of-Arm Tooling (EOAT) – gripper, welding torch, or dispense head per application
- Fieldbus Interface Module (EtherNet/IP, PROFIBUS, or DeviceNet)
- Safety Fencing / Light Curtain System (ISO 10218-2 compliant)
- Cable Dress Package (internal routing kit for welding or process cables)
- FANUC iRVision Camera Kit (optional, for vision-guided applications)
Contact support@konmask.com for bundled BOM pricing and availability.
Compliance & Industry Standards
- ISO 10218-1 – Robots and robotic devices: Safety requirements for industrial robots (manipulating robots)
- IEC 61508 / IEC 62061 – Functional safety of E/E/PE safety-related systems
- CE Marking – Compliant with EU Machinery Directive 2006/42/EC
- RoHS Compliant – Restriction of Hazardous Substances
- IP67 Wrist / IP54 Body – IEC 60529 ingress protection ratings
- ANSI/RIA R15.06 – American National Standard for Industrial Robots and Robot Systems (for North American deployments)
Quality Assurance & Sourcing
Konmask.com sources FANUC M-10iA units through authorized industrial automation distribution channels. Each unit offered is:
- Inspected for completeness of mechanical and electrical assemblies prior to listing
- Documented with available service history or factory refurbishment records where applicable
- Shipped with original FANUC documentation, teach pendant, and controller where included in the listed configuration
- Supported by our technical team for pre-sale specification verification and post-sale integration queries
We specialize in sourcing legacy and current-generation FANUC robots for system integrators, OEMs, and end-users requiring fast delivery of hard-to-find automation hardware.
How to Source This Part
- Confirm Configuration – Specify whether you require the robot only, robot + controller, or a complete cell package. Note your required fieldbus protocol and any special wrist options (e.g., M-10iA/7L extended reach variant).
- Request a Quote – Email support@konmask.com or call +0086 19859288691 with your project timeline and quantity.
- Lead Time & Shipping – In-stock units ship within 3–5 business days. Ex-works Xiamen, China; DDP and DAP Incoterms available for international orders.
- Payment – T/T bank transfer, PayPal, and trade assurance options available. Proforma invoice issued upon order confirmation.
Application-Specific FAQ
Q: Is the FANUC M-10iA suitable for arc welding without additional sealing?
A: Yes. The IP67-rated wrist and internal cable routing make the M-10iA one of FANUC’s most popular arc welding platforms. No additional sealing is required for standard MIG/TIG environments.
Q: Which controller is compatible with the M-10iA?
A: The M-10iA is compatible with the FANUC R-30iA and R-30iB controller families. The R-30iB Plus offers enhanced motion performance and is recommended for new installations.
Q: Can the M-10iA be mounted inverted (ceiling mount)?
A: Yes. The M-10iA supports floor, ceiling (inverted), and angled mounting configurations, enabling flexible cell layout design.
Q: What is the difference between the M-10iA and M-10iA/12?
A: The M-10iA/12 variant offers a 12 kg payload capacity with a slightly reduced reach envelope. The standard M-10iA (10 kg) provides the longest reach (1422 mm) in the M-10i family.
Q: Do you provide FANUC system integration support?
A: Konmask provides pre-sale technical consultation for hardware selection and compatibility. For full system integration services, we can refer you to certified FANUC system integrators in your region.
