Machine & Process Automation Solution – FATEK FBS-24XYR | FBS Series I/O Expansion Module
Where This Product Is Used
The FATEK FBS-24XYR is a 24-point relay output expansion module engineered for demanding industrial environments. It is widely deployed in:
- Packaging machinery – controlling conveyor drives, solenoid valves, and pneumatic actuators in high-cycle operations
- Injection molding & plastics – managing mold open/close sequences, ejector pins, and temperature relay switching
- HVAC & building automation – fan coil unit control, chiller staging, and damper actuator switching
- Water treatment & pumping stations – pump start/stop sequencing, valve control, and alarm relay outputs
- Textile & printing equipment – multi-axis relay coordination for web tension and registration control
- Food & beverage processing – hygienic relay switching for filling, capping, and labeling lines
- Material handling & AGV systems – relay-based zone control and safety interlock outputs
Technical Specifications
- Model: FBS-24XYR
- Series: FATEK FBS
- Module Type: Digital Output Expansion Module
- Output Points: 24 relay output points
- Output Type: Relay (Form A – NO contact)
- Rated Load: 2A / 250VAC or 2A / 30VDC per point
- Max Simultaneous ON Points: 24 (all points)
- Response Time: ≤10 ms (ON/OFF)
- Isolation: Optical isolation between input logic and relay coil
- Power Consumption: Supplied via FBS backplane bus
- Operating Temperature: 0°C to 55°C
- Storage Temperature: -25°C to 70°C
- Humidity: 5% to 95% RH (non-condensing)
- Mounting: DIN rail via FBS expansion bus connector
- Weight: 4,460 g (shipping weight)
- Certifications: CE, RoHS
- Compatible Host PLCs: FATEK FBS-10MA, FBS-14MA, FBS-20MA, FBS-32MA, FBS-60MA, FBS-10MN, FBS-14MN, FBS-20MN, FBS-32MN, FBS-60MN
Why Engineers Specify This Model
- High relay density – 24 independent relay outputs in a single compact module reduces panel footprint vs. discrete relay banks
- AC & DC load compatibility – relay contacts switch both AC (250V) and DC (30V) loads without additional interface relays
- Plug-and-play expansion – connects directly to the FBS host CPU via the proprietary expansion bus; no additional power supply required for the module
- Robust isolation – optical isolation protects the PLC CPU from inductive load transients and ground loops common in motor and solenoid circuits
- Long mechanical life – rated for ≥10 million operations, suitable for high-cycle packaging and assembly applications
- Proven FATEK ecosystem – fully supported by WinProladder and FvDesigner programming software with no additional licensing fees
Complete System Bill of Materials
A typical FBS-series control panel using the FBS-24XYR includes:
- FATEK FBS-32MA (or equivalent) host CPU module
- FATEK FBS-24XYR expansion module (this item)
- FATEK FBS-8XYT or FBS-16XYT for high-speed transistor outputs (optional)
- FATEK FBS-8AD analog input module (for process variable feedback)
- FATEK FBS-4DA analog output module (for VFD speed reference)
- 24VDC DIN rail power supply (e.g., Mean Well MDR-60-24)
- Programming cable: USB-232 or FBS-232P0
- WinProladder programming software (free download)
Compliance & Industry Standards
- CE Marking – compliant with EU Low Voltage Directive (LVD) and EMC Directive
- RoHS – free of restricted hazardous substances per EU Directive 2011/65/EU
- IEC 61131-2 – programmable controller equipment standard
- UL Recognized – suitable for UL-listed panel builds (verify current listing with FATEK)
Quality Assurance & Sourcing
All FATEK modules supplied by Konmask.com are sourced through authorized distribution channels. Each unit undergoes incoming inspection including:
- Visual inspection for physical damage and label authenticity
- Firmware version verification against FATEK official release notes
- Functional relay contact continuity check prior to dispatch
- Anti-static packaging with humidity indicator card
We do not supply grey-market, refurbished, or counterfeit components. Certificate of Conformance (CoC) available upon request.
How to Source This Part
- In-stock orders: Add to cart and complete checkout – standard lead time 1–3 business days for dispatch
- Bulk / project orders: Contact us for volume pricing and project BOM support
- Urgent requirements: Email support@konmask.com or call +0086 19859288691 for expedited sourcing
- International shipping: Available to most regions; DDP (Delivered Duty Paid) options available for EU and US customers
Application-Specific FAQ
Q: Can the FBS-24XYR be used with the FBS-10MA host?
A: Yes. The FBS-10MA supports up to 7 expansion modules. The FBS-24XYR connects via the right-side expansion bus connector.
Q: What is the maximum number of FBS-24XYR modules per system?
A: Up to 7 expansion modules total per FBS host CPU, subject to the host’s maximum I/O point count (typically 256 I/O points).
Q: Are the relay outputs suitable for driving 220VAC solenoid valves directly?
A: Yes. Each relay contact is rated 2A / 250VAC, sufficient for standard 220VAC solenoid valves with coil currents below 2A. For higher-current loads, use an intermediate contactor.
Q: Does this module require separate 24VDC power?
A: No. The FBS-24XYR draws logic power from the FBS expansion bus. Only the relay load circuits require external power supply appropriate to the load voltage.
Q: Is WinProladder compatible with Windows 10/11?
A: Yes. WinProladder v2.x and above supports Windows 10 and Windows 11 (64-bit). Download is free from the FATEK official website.
Q: Can I mix FBS-24XYR with transistor output modules in the same system?
A: Yes. FATEK FBS expansion modules of different types can be mixed freely on the same host CPU, allowing relay outputs for power loads and transistor outputs for high-speed or low-voltage signals.
