Process Control Solution – FOXBORO AD916AE | I/A Series DCS
Where This Product Is Used
The FOXBORO AD916AE is a high-performance Analog Input module designed for deployment within the Foxboro I/A Series Distributed Control System (DCS). It is widely specified in mission-critical process environments where signal accuracy, loop integrity, and system reliability are non-negotiable.
Typical deployment sites include:
- Oil & Gas upstream/downstream processing facilities
- Petrochemical and chemical manufacturing plants
- Power generation stations (thermal, nuclear, combined-cycle)
- Pulp & paper and water treatment operations
- Pharmaceutical batch and continuous process lines
- LNG terminals and pipeline SCADA systems
Engineers specify the AD916AE when replacing legacy I/A Series analog input cards or expanding existing Foxboro DCS architectures without full system migration.
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | AD916AE |
| Manufacturer | Schneider Electric / Foxboro (I/A Series) |
| Module Type | Analog Input (AI) DCS Module |
| Input Channels | 16 channels (single-ended) / 8 channels (differential) |
| Input Signal Range | 4–20 mA, 0–5 V, 1–5 V, 0–10 V (configurable per channel) |
| Resolution | 16-bit A/D conversion |
| Accuracy | ±0.1% of full scale |
| Isolation | Channel-to-channel and channel-to-bus isolation |
| Communication Bus | Nodebus / Fieldbus (I/A Series backplane) |
| Power Supply | Supplied via I/A Series FBM carrier |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Humidity | 5% to 95% RH, non-condensing |
| Weight | 460 g |
| Form Factor | I/A Series FBM plug-in module |
| Certifications | CE, UL, FM (refer to compliance section) |
Why Engineers Specify This Model
- Drop-in I/A Series compatibility: The AD916AE slots directly into existing Foxboro FBM carriers — no rewiring, no reconfiguration of the host DCS required.
- 16-bit resolution: Delivers the measurement precision demanded by tight process control loops in refining and chemical applications.
- Per-channel configurability: Each channel can be independently set for signal type and range, reducing the need for signal conditioning hardware.
- Proven field reliability: The I/A Series platform has decades of installed base across global process industries, with the AD916AE being one of the most widely deployed analog input modules.
- Reduced downtime risk: Stocking a spare AD916AE eliminates extended lead times from OEM channels during unplanned shutdowns.
- Backward compatibility: Fully compatible with I/A Series software revisions, including Foxboro DCS V8.x and later.
Complete System Bill of Materials
The AD916AE operates as part of the Foxboro I/A Series FBM subsystem. A complete analog input node typically requires:
- AD916AE — Analog Input Module (this item)
- FBM carrier / baseplate — Mounts and powers the FBM module (e.g., P0914YE, P0914XS)
- Nodebus cable assembly — Connects FBM carrier to the I/A Series Nodebus
- Field termination assembly (FTA) — Marshalling panel for field wiring (e.g., FBM04 FTA)
- I/A Series workstation / AW — Application Workstation running Foxboro DCS software
- Power supply module — Redundant 24 VDC supply for FBM carrier rail
Contact support@konmask.com for assistance sourcing companion components.
Compliance & Industry Standards
- CE Marking — Compliant with EU EMC Directive and Low Voltage Directive
- UL Listed — Recognized for use in industrial control equipment (UL 508)
- FM Approved — Factory Mutual approval for applicable hazardous area classifications
- RoHS Compliant — Meets EU Directive 2011/65/EU on restriction of hazardous substances
- IEC 61131-2 — Programmable controller hardware standard compliance
- ISA-5.1 — Instrumentation symbols and identification standards alignment
Quality Assurance & Sourcing
Konmask.com sources the FOXBORO AD916AE through verified industrial surplus and authorized distribution channels. Every unit offered undergoes the following before shipment:
- Visual inspection: Board-level check for physical damage, corrosion, and component integrity
- Functional power-on test: Module is energized and communication verified on I/A Series test bench where applicable
- Firmware / revision verification: Hardware revision and firmware label documented and disclosed
- ESD-safe packaging: Shipped in anti-static bags with foam cushioning inside double-wall cartons
- Traceability documentation: Serial number, revision, and test record provided upon request
We do not sell counterfeit, remarked, or untested modules. All units are sold with a 90-day functional warranty unless otherwise stated.
How to Source This Part
Step 1 — Confirm your revision requirement: Check the label on your existing AD916AE or your I/A Series BOM for the required hardware revision (e.g., AD916AE Rev C).
Step 2 — Add to cart or request a quote: For single units, add directly to cart. For quantities of 2 or more, or for urgent shutdown requirements, email support@konmask.com for priority pricing.
Step 3 — Specify shipping urgency: We offer standard, expedited, and same-day dispatch options. International DDP shipping available to most regions.
Step 4 — Receive and verify: Each shipment includes a packing list with serial number and revision. Cross-reference against your system documentation before installation.
Phone / WhatsApp: +0086 19859288691
Email: support@konmask.com
Website: https://konmask.com
Application-Specific FAQ
Q: Is the AD916AE compatible with all I/A Series FBM carriers?
A: The AD916AE is designed for standard I/A Series FBM carriers. Verify your carrier model against Foxboro’s FBM compatibility matrix or contact us for confirmation.
Q: Can this module be used as a hot-standby replacement during live plant operation?
A: The I/A Series supports hot-swap of FBM modules in redundant configurations. Consult your DCS system integrator and Foxboro documentation (PSS 21H-2Z1 B4) before performing live swaps.
Q: What is the difference between AD916AE and AD916BE?
A: The AD916BE is a later revision with enhanced EMC performance and extended temperature tolerance. Both are functionally compatible with the same FBM carrier slots. Contact us if you need a specific revision.
Q: Do you provide a Certificate of Conformance (CoC)?
A: Yes. A CoC with serial number, revision, and test date is available upon request for all units. Please specify at time of order.
Q: What is the lead time for urgent orders?
A: In-stock units can ship within 24 hours of payment confirmation. Contact us directly for shutdown emergency sourcing.
