Industrial Automation Solution – FUJI NQ2P20R-14 | NQ2 Series Programmable Controller
Where This Product Is Used
The FUJI NQ2P20R-14 is a compact relay-output programmable logic controller from FUJI Electric’s NQ2 Series, engineered for demanding industrial environments. Typical deployment scenarios include:
- Machine Tool Control – Coordinating spindle, feed axis, and coolant sequencing on CNC lathes and milling centers
- Conveyor & Material Handling – Controlling start/stop, speed staging, and fault interlocks on production-line conveyors
- Packaging Machinery – Managing fill, seal, and label sequences in food and pharmaceutical packaging lines
- HVAC & Building Automation – Sequencing pumps, fans, and damper actuators in commercial building management systems
- Water Treatment Plants – Automating dosing pumps, valve control, and alarm logic in municipal or industrial water systems
- Injection Molding Machines – Controlling clamp, inject, cool, and eject cycles with precise relay-driven outputs
Technical Specifications
- Model: NQ2P20R-14
- Series: NQ2
- Manufacturer: FUJI Electric
- Controller Type: Programmable Logic Controller (PLC)
- Output Type: Relay Output
- I/O Points: 20 I/O (14 inputs / 6 relay outputs — verify against datasheet)
- Power Supply: AC 100–240 V (refer to official FUJI datasheet for exact ratings)
- Programming Standard: IEC 61131-3 compatible
- Communication: RS-485 / proprietary FUJI bus (model-dependent)
- Operating Temperature: 0 °C to 55 °C
- Storage Temperature: –20 °C to 70 °C
- Protection Rating: IP20 (panel-mount)
- Weight: Approx. 130 g
- Certifications: CE, UL (verify current listing)
Why Engineers Specify This Model
- Relay Output Reliability – Mechanical relay contacts handle inductive loads (motors, solenoids) without additional snubber circuits, reducing BOM complexity
- Compact Footprint – NQ2 form factor fits standard DIN-rail enclosures, minimizing panel space in retrofit projects
- FUJI Ecosystem Compatibility – Seamlessly integrates with FUJI inverters (FRENIC series), HMIs, and servo drives via native communication protocols
- Proven Field Reliability – FUJI Electric PLCs are widely deployed in Asian and European manufacturing facilities with documented MTBF exceeding 100,000 hours
- IEC 61131-3 Programming – Supports Ladder Diagram (LD) and Function Block Diagram (FBD), reducing re-training costs when migrating from other PLC brands
Complete System Bill of Materials
For a fully operational NQ2P20R-14 control node, engineers typically specify:
- FUJI NQ2P20R-14 – CPU / I/O base unit (this item)
- FUJI NQ2 Expansion I/O Module – for additional digital or analog points
- FUJI NQ-CBLS / programming cable – for PC-to-PLC connection
- FUJI NQ-Designer or SX-Programmer software – ladder logic development environment
- 24 VDC power supply (e.g., FUJI BW series or equivalent) – for sensor/input loop power
- DIN-rail mounting hardware and terminal blocks
- Surge protection module for relay output circuits (recommended for inductive loads)
Compliance & Industry Standards
- IEC 61131-3 – Programmable controller programming languages
- IEC 61010-1 – Safety requirements for electrical equipment for measurement, control, and laboratory use
- CE Marking – Conformity with EU Low Voltage Directive and EMC Directive
- RoHS Compliant – Restriction of Hazardous Substances
- UL Listed – Underwriters Laboratories (verify current listing status)
Quality Assurance & Sourcing
At Konmask.com, every FUJI NQ2P20R-14 unit is:
- Sourced from authorized distributors or verified surplus channels with full traceability documentation
- Inspected for physical integrity, label authenticity, and firmware version consistency prior to dispatch
- Shipped in anti-static packaging with original or equivalent protective materials
- Backed by our 30-day return policy and pre-shipment functional verification on request
How to Source This Part
Ready to order or need a formal quotation for your procurement team?
- Online: Add to cart directly on this page for immediate checkout
- Email RFQ: [email protected] – include quantity, required delivery date, and project details
- Phone / WhatsApp: +0086 19859288691 – available for urgent sourcing inquiries
- Lead Time: In-stock units ship within 1–3 business days; ex-stock orders subject to availability confirmation
Application-Specific FAQ
Q: Can the NQ2P20R-14 control a three-phase motor directly?
A: The relay outputs can switch motor contactors or starters; direct three-phase motor connection is not recommended. Use an appropriately rated contactor in the output circuit.
Q: Is this PLC compatible with FUJI FRENIC inverters?
A: Yes. The NQ2 Series supports RS-485 Modbus RTU communication, enabling direct parameter read/write and run/stop control of FRENIC-series inverters.
Q: What programming software is required?
A: FUJI NQ-Designer (Windows-based) is the standard development environment. Contact us if you need assistance sourcing the software license.
Q: Can I expand the I/O count beyond the base 20 points?
A: Yes. The NQ2 platform supports expansion modules for additional digital inputs, digital outputs, and analog I/O. Contact us for expansion module part numbers.
Q: Do you provide a warranty?
A: All units are covered by our 30-day inspection guarantee. Extended warranty arrangements are available for volume orders — contact our sales team.
