Turbine Flame Detection Solution – General Electric DS200FCGDH1BAA | Mark V/VI Speedtronic Series
Where This Product Is Used
The GE DS200FCGDH1BAA is a dedicated flame detection circuit board engineered for gas turbine control systems operating under GE’s Mark V and Mark VI Speedtronic platform. It is deployed across a wide range of mission-critical industrial environments where reliable combustion monitoring is non-negotiable:
- Combined-Cycle Power Plants (CCPP) – Continuous flame supervision during startup, load transitions, and shutdown sequences in multi-shaft configurations.
- Simple-Cycle Peaker Plants – Fast-start turbine applications where flame detection response time directly impacts grid reliability.
- LNG & Petrochemical Facilities – Hazardous-area turbine-driven compressor trains requiring SIL-rated flame monitoring.
- Offshore Oil & Gas Platforms – Marine-grade turbine packages where board reliability under vibration and humidity is critical.
- Industrial Cogeneration (CHP) – Continuous-duty turbines in chemical, paper, and steel plants requiring uninterrupted flame signal integrity.
- Refinery Utility Turbines – Fuel-flexible turbines burning refinery gas, requiring adaptive flame detection logic.
Technical Specifications
| Part Number | DS200FCGDH1BAA |
| Manufacturer | General Electric (GE) |
| Series | Mark V / Mark VI Speedtronic Turbine Control |
| Board Function | Flame Detection & Combustion Monitoring |
| Form Factor | PCB Module – Rack-Mount Card |
| Compatible Chassis | Mark V TCCA / TCCB / TCCC Panels; Mark VI Packs |
| Input Signal Type | UV / IR Flame Scanner Analog & Digital Inputs |
| Communication Interface | Internal Speedtronic Backplane Bus |
| Operating Temperature | 0°C to +60°C (panel ambient) |
| Weight | 300 g (approx.) |
| Condition Available | New OEM / Refurbished / Tested Exchange |
Why Engineers Specify This Model
- OEM-Matched Signal Processing – Designed exclusively for GE Speedtronic architecture; no signal conditioning adapters required.
- Redundancy-Ready – Supports TMR (Triple Modular Redundancy) flame voting logic in Mark V three-panel configurations (R, S, T).
- Deterministic Response – Sub-cycle flame loss detection prevents uncontrolled fuel admission, protecting turbine and downstream equipment.
- Proven Field History – Deployed in thousands of GE Frame 5, Frame 6, Frame 7, and Frame 9 turbine installations globally.
- Drop-In Replacement – Maintains original firmware compatibility; no re-engineering of control logic required on swap.
- Reduced Downtime Risk – Stocking this board eliminates multi-week OEM lead times during unplanned outages.
Complete System Bill of Materials
The DS200FCGDH1BAA operates within a broader Mark V/VI control architecture. Engineers sourcing this board typically also require:
- DS200TCQAG1BHF – Turbine Control Processor Board (TCQA)
- DS200SDCCG1AFB – Speed Detector & Contact Converter Board
- DS200IOCAG1A – I/O Controller Board
- DS200EXPSG1ADA – Expansion Power Supply Board
- DS200TBQCG1AAA – Terminal Board for I/O Connections
- IS200TSVOH1A – Mark VI Servo & Trip Output Board (Mark VI upgrades)
Contact support@konmask.com for complete panel BOM support and cross-reference assistance.
Compliance & Industry Standards
- IEC 61511 – Functional Safety for Process Industry Sector (SIL compliance framework)
- NFPA 85 – Boiler and Combustion Systems Hazards Code (flame safeguard requirements)
- API 670 – Machinery Protection Systems (applicable to turbine-driven equipment)
- ISO 55001 – Asset Management (supports predictive maintenance programs)
- GE Speedtronic Design Specification GEI-100679 – OEM internal design standard
Quality Assurance & Sourcing
Every DS200FCGDH1BAA unit offered through Konmask.com undergoes a structured verification process before dispatch:
- ✔ Visual Inspection – Component-level check for corrosion, burnt traces, and mechanical damage.
- ✔ Functional Bench Test – Power-on verification and I/O signal simulation where applicable.
- ✔ Firmware Version Logging – Revision recorded and disclosed prior to shipment.
- ✔ ESD-Safe Packaging – Anti-static bag, foam insert, and double-wall carton for international transit.
- ✔ Traceability Documentation – Test report and sourcing declaration available on request.
We source from decommissioned OEM-maintained panels, authorized distributors, and certified repair facilities. We do not sell counterfeit or unmarked boards.
How to Source This Part
- Submit a Quote Request – Email support@konmask.com with your required quantity, condition preference (new / refurbished / exchange), and delivery timeline.
- Receive Availability & Pricing – Our team responds within 1 business day with stock status, unit price, and lead time.
- Confirm Order & Payment – We accept T/T wire transfer, PayPal, and trade credit for qualified accounts.
- Dispatch & Tracking – Units ship via DHL / FedEx Express with full tracking. Export documentation (commercial invoice, packing list, COO) included.
- Post-Delivery Support – 90-day warranty on refurbished units. Technical installation support available via email.
Application-Specific FAQ
Q: Is the DS200FCGDH1BAA compatible with both Mark V and Mark VI systems?
A: The board is primarily designed for Mark V Speedtronic panels. Mark VI compatibility depends on the specific I/O pack configuration. Contact us with your panel serial number for confirmation.
Q: Can this board be used in a TMR (Triple Modular Redundancy) configuration?
A: Yes. Mark V TMR systems use three identical panels (R, S, T), each requiring one FCGDH1BAA board. We can supply matched sets.
Q: What flame scanner types does this board support?
A: The board is compatible with GE-approved UV and IR flame scanners used in standard Speedtronic combustion monitoring configurations. Consult your turbine’s control specification for scanner model compatibility.
Q: Do you offer an exchange program?
A: Yes. Send your faulty unit to us and receive a tested replacement at a reduced exchange price. Lead time for exchange units is typically 3–5 business days.
Q: What is the warranty on refurbished units?
A: All refurbished DS200FCGDH1BAA boards carry a 90-day warranty covering functional defects. New OEM units carry the standard manufacturer warranty where applicable.
© 2026 Konmask.com. All rights reserved.
Original Source: https://Konmask.com
Contact: support@konmask.com | +0086 19859288691
