GE Fanuc IC693APU302 Motion Mate Axis Positioning Module – Series 90-30 PLC
Imagine a high-speed packaging line suddenly losing synchronization — servo axes drifting out of position, product jams cascading down the line, and production halting while engineers scramble to diagnose the fault. Without a reliable axis positioning module, even the most sophisticated PLC system becomes blind to motion feedback, unable to execute precise point-to-point moves or maintain velocity profiles. The GE Fanuc IC693APU302 eliminates this vulnerability by delivering dedicated, deterministic single-axis motion control directly within the Series 90-30 rack — keeping your machinery moving with the precision your process demands.
The IC693APU302 occupies a specialized position within the GE Fanuc Series 90-30 motion control family. As the single-axis variant of the Motion Mate APU line, it is engineered for applications where cost-effective, tightly integrated axis control is paramount — from CNC auxiliary axes and conveyor indexing to robotic end-of-arm tooling. Backed by GE Fanuc’s decades of industrial automation heritage, the Series 90-30 platform remains one of the most widely deployed mid-range PLC architectures globally, and the IC693APU302 continues to be a critical spare and upgrade component across manufacturing, oil & gas, and material handling sectors worldwide.
Technical Specifications
- Part Number: IC693APU302
- Manufacturer: GE Fanuc (General Electric)
- Series: Series 90-30 (90-30 PLC)
- Module Type: Motion Mate Axis Positioning Module (APU)
- Axes Supported: Single axis
- Backplane Interface: Series 90-30 I/O bus
- Encoder Input: Incremental quadrature encoder (A/B/Z)
- Output Type: Analog ±10 VDC velocity command
- Motion Modes: Point-to-point positioning, velocity control, homing
- Programming: Configured via Logicmaster 90 / Proficy Machine Edition
- Power Consumption: Supplied via Series 90-30 backplane
- Weight: 320 g (approx.)
- Operating Temperature: 0°C to 60°C
- Form Factor: Single-slot Series 90-30 module
Key Features & Benefits
- Dedicated Motion Processor: Offloads axis control from the CPU, ensuring deterministic motion execution independent of PLC scan time.
- Seamless Series 90-30 Integration: Plugs directly into any Series 90-30 base, sharing power and communications without external wiring complexity.
- Incremental Encoder Feedback: Accepts standard quadrature encoder signals for closed-loop position verification and error correction.
- Analog Velocity Output: ±10 VDC command output is compatible with virtually all servo amplifiers and variable-frequency drives.
- Multiple Motion Modes: Supports point-to-point moves, jog, homing, and velocity control — covering the majority of single-axis application requirements.
- Proven Platform Longevity: The Series 90-30 ecosystem has an extensive installed base, ensuring long-term parts availability and engineering support.
- Simplified Commissioning: Configured through familiar GE Fanuc programming environments, reducing engineering time and training overhead.
Industry & Equipment Applications
- Packaging Machinery: Indexing conveyors, form-fill-seal machines, labeling stations
- Material Handling: Automated storage and retrieval systems (AS/RS), palletizers, sortation lines
- CNC & Machine Tools: Auxiliary axis control on lathes, mills, and grinding machines
- Oil & Gas: Valve actuator positioning, wellhead control panels
- Automotive Assembly: Weld gun positioning, transfer line indexing
- Printing & Converting: Web tension control, register correction systems
- Food & Beverage: Filling machine indexing, portioning and slicing equipment
System Integration & Compatible Parts
The IC693APU302 is designed to operate within the GE Fanuc Series 90-30 control system. Compatible and commonly paired components include:
- CPUs: IC693CPU311, IC693CPU313, IC693CPU323, IC693CPU331, IC693CPU340, IC693CPU341, IC693CPU350, IC693CPU360, IC693CPU363, IC693CPU374
- Power Supplies: IC693PWR321, IC693PWR322, IC693PWR330, IC693PWR331
- Bases: IC693CHS391, IC693CHS392, IC693CHS393 (5, 10, 12-slot bases)
- Communications: IC693CMM301 (Genius Bus Controller), IC693CMM311 (Ethernet Interface)
- Programming Software: Proficy Machine Edition (ME), Logicmaster 90-30
Our Quality Assurance Process
At Konmask.com, every GE Fanuc IC693APU302 unit undergoes a rigorous multi-stage inspection before shipment:
- Visual Inspection: Board-level examination for physical damage, corrosion, or component anomalies.
- Label & Firmware Verification: Part number, revision level, and firmware version confirmed against GE Fanuc documentation.
- Functional Bench Test: Module powered and tested in a Series 90-30 rack to verify backplane communication and I/O integrity.
- Anti-Static Packaging: Shipped in ESD-safe bags with foam cushioning to prevent transit damage.
- Traceability: Each unit is logged with inspection records available upon request.
How to Order
- Submit your inquiry via the Contact Us form or email [email protected].
- Provide your required quantity, delivery timeline, and destination country.
- Receive a formal quotation with lead time and shipping options within 24 business hours.
- Confirm the order and receive proforma invoice for payment processing.
- Module ships with full inspection documentation and tracking information.
For urgent requirements or large-volume orders, please call or WhatsApp: +0086 19859288691.
Why Choose Konmask.com?
- Specialized Industrial Focus: We stock and source PLC, DCS, servo, and motion control components from leading global brands — not a generalist marketplace.
- Verified Sourcing: All units are sourced from traceable supply chains with documentation available for compliance-sensitive industries.
- Global Export Experience: We ship to over 50 countries with experience in export documentation, customs declarations, and international logistics.
- Technical Pre-Sales Support: Our engineers can assist with compatibility verification, cross-referencing, and application guidance before you commit to an order.
- Responsive Communication: Inquiries answered within 24 hours; urgent requests handled same business day.
- Competitive Pricing: Direct sourcing relationships allow us to offer market-competitive pricing on both single units and bulk orders.
Frequently Asked Questions
Q: Is the IC693APU302 compatible with all Series 90-30 bases?
A: Yes. The IC693APU302 is compatible with all standard Series 90-30 5-slot, 10-slot, and 12-slot bases (IC693CHS391/392/393) and expansion bases.
Q: What servo amplifiers are compatible with the IC693APU302?
A: Any servo amplifier or drive accepting a ±10 VDC analog velocity command input is compatible, including units from Fanuc, Siemens, Allen-Bradley, Yaskawa, and others.
Q: Can the IC693APU302 control stepper motors?
A: The IC693APU302 outputs an analog velocity command and is designed for closed-loop servo systems. For stepper motor control, GE Fanuc offers separate pulse-output motion modules.
Q: Do you supply new or refurbished units?
A: We supply both new (factory-sealed where available) and professionally refurbished units. All refurbished units pass our full inspection and functional test protocol. Unit condition is clearly stated in the quotation.
Q: What is the typical lead time for the IC693APU302?
A: In-stock units ship within 1–3 business days. For sourced units, lead time is typically 5–15 business days depending on origin. Contact us for current availability.
Q: Can you provide a certificate of conformance or test report?
A: Yes. Inspection records and certificates of conformance are available upon request for all units.
