Temperature Measurement Solution — GE IC200ALG630 | VersaMax Analog Input
Where This Product Is Used
The GE IC200ALG630 is a 4-channel thermocouple analog input module designed for the GE VersaMax PLC platform. It is widely deployed in applications where precise temperature monitoring is critical to process safety and product quality:
- Furnace & Kiln Control — Continuous temperature profiling in heat treatment, ceramics, and glass manufacturing
- Food & Beverage Processing — Pasteurization, sterilization, and cooking process temperature loops
- Plastics & Injection Molding — Barrel zone temperature control on extruders and injection molding machines
- HVAC & Building Automation — Duct and chiller temperature sensing integrated into BAS controllers
- Chemical & Petrochemical Plants — Reactor temperature monitoring with SIL-rated control loops
- Power Generation — Turbine exhaust and boiler flue gas temperature acquisition
- Pharmaceutical Manufacturing — Autoclave and clean-room temperature validation per FDA 21 CFR Part 11
Technical Specifications
| Part Number | IC200ALG630 |
| Manufacturer | General Electric (GE Automation / Emerson) |
| Series | VersaMax PLC |
| Module Type | Analog Input — Thermocouple |
| Number of Channels | 4 Channels (single-ended) |
| Thermocouple Types Supported | J, K, T, E, R, S, B |
| Resolution | 16-bit |
| Cold Junction Compensation | Built-in (automatic) |
| Input Isolation | Channel-to-channel isolated |
| Backplane Bus | VersaMax Local I/O Bus |
| Power Consumption | Supplied via backplane (no external 24 VDC required) |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | -40 °C to 85 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Weight | 200 g (approx.) |
| Certifications | UL, CE, cUL |
Why Engineers Specify This Model
- Native VersaMax Integration — Plug-and-play on any VersaMax carrier; no external signal conditioners required, reducing panel footprint and wiring cost
- Multi-Type Thermocouple Support — A single module handles J, K, T, E, R, S, and B types, eliminating the need for type-specific modules across mixed-sensor installations
- Built-in Cold Junction Compensation (CJC) — Eliminates external reference junction hardware and improves measurement accuracy in variable ambient conditions
- 16-Bit Resolution — Delivers high-fidelity temperature data suitable for tight PID control loops and alarm setpoint discrimination
- Channel Isolation — Prevents ground loops between sensors at different electrical potentials — essential in large industrial installations
- Proven Field Reliability — Thousands of units deployed globally in continuous-process industries with documented MTBF exceeding 10 years
Complete System Bill of Materials
To build a complete VersaMax temperature acquisition node, the following components are typically required alongside the IC200ALG630:
- VersaMax CPU — IC200CPUE05 / IC200CPUE05-AE (or compatible CPU carrier)
- VersaMax I/O Carrier — IC200CHS002 / IC200CHS022 (local expansion carrier)
- Power Supply Module — IC200PWR002 (24 VDC input, backplane power)
- Thermocouple Sensors — Type K or J (customer-supplied, per process requirement)
- Programming Software — GE Proficy Machine Edition (PME) with VersaMax target license
- Communication Module (optional) — IC200ETM001 (Ethernet TCP/IP) for SCADA integration
Contact Konmask for bundle pricing on complete VersaMax system builds.
Compliance & Industry Standards
- UL 508 — Industrial Control Equipment (UL Listed)
- CE Marking — EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU
- cUL — Canadian Standards compliance
- RoHS Compliant — Restriction of Hazardous Substances Directive 2011/65/EU
- IEC 61131-2 — Programmable Controllers: Equipment Requirements and Tests
- ATEX / IECEx — Not rated for Zone 0/1; use appropriate barriers for hazardous area installations
Quality Assurance & Sourcing
Konmask.com sources the IC200ALG630 through verified industrial distribution channels. Every unit offered is subject to the following quality controls:
- Visual inspection for physical damage, label integrity, and connector condition
- Firmware version verification against GE/Emerson release records
- Anti-static packaging with humidity indicator cards for long-term storage units
- Traceability documentation available upon request (batch records, test reports)
- Warranty: 12 months from date of shipment against manufacturing defects
We do not list units that cannot be verified. If stock is shown as available, it is physically on-hand or confirmed inbound from a primary distributor.
How to Source This Part
- Add to Cart — Select quantity and proceed to checkout for standard lead times
- Request a Quote — For orders of 5+ units, email support@konmask.com for volume pricing
- Urgent Requirement — Call or WhatsApp +0086 19859288691 for same-day shipping confirmation
- System Integration Support — Our engineers can assist with VersaMax system design, I/O mapping, and PME configuration guidance
- Export & Cross-Border Orders — We ship internationally with full commercial invoice and HS code documentation (HS: 8537.10)
Application-Specific FAQ
Q: Can the IC200ALG630 read millivolt signals from non-standard sensors?
A: The module is optimized for standard thermocouple types (J/K/T/E/R/S/B). For raw mV or RTD inputs, consider the IC200ALG620 (RTD) or IC200ALG240 (universal analog input) instead.
Q: Is cold junction compensation automatic or does it require configuration?
A: CJC is fully automatic. The module measures the terminal block temperature internally and applies compensation without any user configuration in PME.
Q: Can I mix thermocouple types across the 4 channels?
A: Yes. Each channel can be independently configured for a different thermocouple type via the PME hardware configuration tool.
Q: What is the maximum cable length for thermocouple wiring?
A: GE recommends thermocouple extension wire (not copper) up to 30 m per channel. Shielded, twisted-pair extension wire is mandatory in electrically noisy environments.
Q: Is this module compatible with VersaMax Micro or Nano CPUs?
A: No. The IC200ALG630 requires a standard VersaMax carrier (IC200CHS series). It is not compatible with VersaMax Micro (IC200UDR/UAL) or Nano platforms.
Q: Do you offer programming and commissioning support?
A: Yes. Konmask provides remote engineering support for VersaMax system configuration. Contact us with your project scope for a support quotation.
