GE IC200CPUE05 – VersaMax Micro PLC Processor Module with Embedded Ethernet | VersaMax Micro Series
Engineering Background
The GE IC200CPUE05 is the flagship CPU of the GE Fanuc VersaMax Micro PLC platform — a compact, high-performance programmable logic controller series engineered for demanding industrial automation environments. Introduced as part of GE’s commitment to scalable, network-ready control architecture, the IC200CPUE05 integrates an embedded Ethernet port directly into the CPU, eliminating the need for a separate communications module and reducing panel footprint without sacrificing connectivity.
Product Positioning
Designed for procurement engineers and system integrators sourcing reliable, spec-verified automation components, the IC200CPUE05 occupies the performance tier of the VersaMax Micro family. It is the preferred choice for applications requiring deterministic Ethernet communications, substantial I/O expansion, and robust ladder/function block logic execution — all within a DIN-rail-mountable form factor. Konmask.com supplies this module as a genuine, quality-inspected unit with full traceability documentation available upon request.
Complete Technical Specifications
| Part Number | IC200CPUE05 |
| Manufacturer | GE Fanuc / GE Automation & Controls |
| Series / Platform | VersaMax Micro PLC |
| Module Type | CPU / Processor Module |
| User Logic Memory | 14 KB (ladder logic / function block) |
| Maximum I/O Points | Up to 512 discrete I/O (with expansion) |
| Embedded Communications | 10/100 Mbps Ethernet (RJ-45), RS-232 serial port |
| Supported Protocols | SRTP, Modbus TCP, EGD (Ethernet Global Data) |
| Programming Software | GE Proficy Machine Edition (PME) |
| Programming Languages | Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL) |
| Scan Time | ~0.6 ms/K (Boolean), ~1.0 ms/K (floating point) |
| Supply Voltage | 24 VDC (via base unit) |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Mounting | DIN rail or panel mount (via VersaMax Micro base) |
| Approx. Weight | 300 g |
| HS Code | 853710 |
| Country of Origin | United States |
| Certifications | CE, UL, cUL |
Proven Application Environments
- Discrete Manufacturing: Assembly line sequencing, conveyor control, and machine interlocking where Ethernet supervisory access is required.
- Water & Wastewater: Pump station control with remote SCADA connectivity via Modbus TCP or SRTP over Ethernet.
- Building Automation: HVAC control, access control integration, and energy monitoring in commercial facilities.
- Food & Beverage: Batch process control in washdown-adjacent environments with compact panel requirements.
- OEM Machine Control: Embedded in custom machinery where a small-footprint, network-ready PLC is specified by the OEM.
- Retrofit & Modernization: Drop-in replacement for legacy VersaMax Micro CPUs requiring Ethernet upgrade without full panel redesign.
Engineering Advantages
- Embedded Ethernet eliminates add-on modules — reduces BOM cost, wiring complexity, and potential failure points.
- Dual-port communications (Ethernet + RS-232) enable simultaneous SCADA network connection and local HMI/programming access.
- EGD (Ethernet Global Data) support enables peer-to-peer data exchange between PLCs without a dedicated master, ideal for distributed control architectures.
- Compact DIN-rail form factor with full VersaMax Micro I/O expansion capability — scale from 28 to 512 I/O points without changing the CPU.
- Proficy Machine Edition compatibility ensures seamless integration into existing GE automation ecosystems with unified programming and diagnostics.
- Proven field reliability across 15+ years of industrial deployment in harsh environments.
System Architecture & Signal Flow
The IC200CPUE05 mounts directly onto a VersaMax Micro base unit (e.g., IC200UDR005, IC200UDD064) which provides the power supply interface and local I/O. The CPU executes the user program cyclically, scanning inputs, executing logic, and updating outputs each scan cycle.
- Ethernet Port (RJ-45): Connects to plant LAN/SCADA network. Supports SRTP for Proficy HMI/SCADA, Modbus TCP for third-party SCADA/HMI, and EGD for peer PLC communications.
- RS-232 Serial Port: Used for local programming via PME, HMI connection (SNP/SNPX protocol), or serial device communications.
- I/O Expansion: Additional VersaMax Micro expansion modules connect directly to the base, extending discrete and analog I/O capacity up to 512 points.
- Memory Architecture: 14 KB user logic memory with battery-backed retentive data registers for process variable persistence across power cycles.
Sourcing & Quality Verification
All IC200CPUE05 units supplied by Konmask.com undergo a structured incoming inspection process:
- Visual inspection for physical damage, counterfeit indicators, and label authenticity.
- Part number and date code verification against manufacturer documentation.
- Functional power-on test where applicable.
- Packaging in anti-static ESD-safe materials with moisture barrier protection.
Traceability documentation (including supplier chain records) is available upon request for regulated industries. Units are sourced from authorized distribution channels and verified surplus inventory with documented provenance.
Procurement Process
- Confirm Part Number: Verify IC200CPUE05 against your BOM or existing system documentation. Cross-reference with GE catalog IC200CPUE05-AA if firmware revision is critical.
- Request Quote: Contact support@konmask.com for volume pricing, lead time confirmation, and documentation packages.
- Place Order: Orders processed within 1 business day. Export documentation (commercial invoice, packing list, COO) provided for international shipments.
- Shipping: Ships from China warehouse via DHL Express, FedEx International, or sea freight for bulk orders. Typical transit: 3–7 business days (express).
- Incoming Inspection: Recommend customer incoming inspection per IPC-A-610 or equivalent standard. Konmask supports RMA process for any quality discrepancies within 30 days of receipt.
Technical FAQ
Q: Is the IC200CPUE05 compatible with GE Proficy Machine Edition (PME) v9.x and later?
A: Yes. The IC200CPUE05 is fully supported in PME v8.0 through current releases. Ensure the VersaMax Micro hardware library is installed in your PME environment.
Q: Can the IC200CPUE05 communicate with third-party HMIs (e.g., Weintek, Proface, Siemens)?
A: Yes, via Modbus TCP over Ethernet or SNP/SNPX protocol over the RS-232 port. Most major HMI brands include native GE SRTP or Modbus TCP drivers.
Q: What is the maximum number of EGD exchanges supported?
A: The IC200CPUE05 supports up to 32 EGD producer/consumer exchanges, suitable for distributed multi-PLC architectures.
Q: Is a battery required for retentive memory?
A: The VersaMax Micro base unit supports an optional battery backup for retentive %R and %M registers. Without battery, retentive data is lost on power cycle.
Q: Can this module replace an IC200CPUE05-AA or IC200CPUE05-AB?
A: The base part number IC200CPUE05 is hardware-compatible across dash-number revisions. Firmware version may differ; confirm with your system integrator if firmware revision is critical to your application.
Q: What is the typical lead time for stock orders?
A: In-stock units ship within 1–2 business days. Contact support@konmask.com for real-time availability confirmation.
