High Speed Counter Solution – GE IC220MDD840 | VersaMax Micro
The GE IC220MDD840 is a combination discrete I/O and high speed counter module designed for the GE VersaMax Micro PLC platform. With 8 DC inputs (24 VDC), 8 relay outputs, and a dedicated high speed counter channel capable of up to 100 kHz, this module is the go-to choice for engineers who need precise pulse counting and motion feedback in a compact, DIN-rail-mounted form factor.
Where This Product Is Used
The IC220MDD840 is deployed across a wide range of industrial automation applications where accurate, high-speed pulse counting is critical:
- Conveyor & Material Handling: Counting encoder pulses to track belt speed, product position, and throughput on packaging lines.
- CNC & Machine Tool Control: Capturing spindle encoder feedback for speed regulation and position verification.
- Bottling & Filling Lines: Counting fill cycles and container indexing pulses to ensure accurate batch control.
- Printing & Converting Machines: Synchronizing web tension and registration marks via encoder pulse counting.
- Pump & Flow Metering: Interfacing with turbine or paddle-wheel flow meters for volumetric measurement in water treatment and chemical dosing.
- Automotive Assembly: Monitoring rotary encoder signals on torque tools and test rigs for quality assurance.
- Elevator & Hoist Systems: Tracking motor shaft position and speed for safe, precise floor-level control.
Technical Specifications
- Part Number: IC220MDD840
- Series: VersaMax Micro
- Manufacturer: GE (General Electric Automation / Emerson)
- Module Type: Discrete I/O + High Speed Counter
- Digital Inputs: 8 × 24 VDC sinking/sourcing
- Digital Outputs: 8 × Relay (Form A), 2 A per point
- High Speed Counter Channels: 1 (dedicated)
- Maximum Count Frequency: 100 kHz
- Counter Modes: Up, Down, Up/Down (quadrature), Period/Frequency measurement
- Input Voltage Range: 20.4–28.8 VDC
- Output Relay Rating: 2 A @ 30 VDC / 250 VAC
- Backplane Connection: VersaMax Micro local I/O bus
- Mounting: DIN rail or panel mount
- Operating Temperature: 0 °C to 55 °C
- Weight: 680 g
- Certifications: UL, CE, cUL
Why Engineers Specify This Model
- 100 kHz counting bandwidth handles fast encoders without missing pulses — critical for high-speed servo and spindle applications.
- Integrated relay outputs eliminate the need for a separate output module, reducing panel footprint and wiring cost.
- Quadrature (A/B) encoder support enables direction-aware counting for bidirectional motion control.
- Native VersaMax Micro compatibility means zero configuration overhead — plug in and configure via Proficy Machine Edition.
- Compact DIN-rail form factor fits tight control cabinets common in OEM machine builds.
- Proven field reliability in 24/7 manufacturing environments with wide temperature tolerance.
Complete System Bill of Materials
For a complete VersaMax Micro high-speed counter application, engineers typically specify:
- IC220MDD840 — This module (HSC + 8DI + 8DO relay)
- IC200UDR005 / IC200UDR020 — VersaMax Micro CPU base unit
- IC200PWR002 — 24 VDC power supply module
- IC200CBL001 — Programming cable (RS-232 to RJ-45)
- Incremental rotary encoder (5–24 VDC, open collector or push-pull output)
- 24 VDC DIN-rail power supply (Siemens SITOP or equivalent)
- Proficy Machine Edition software license for programming
Compliance & Industry Standards
- UL Listed (UL 508)
- CE Marked (EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU)
- cUL (Canadian UL equivalent)
- RoHS compliant
- Suitable for use in Pollution Degree 2 environments per IEC 60664-1
Quality Assurance & Sourcing
Every IC220MDD840 unit shipped by Konmask.com undergoes the following verification process:
- Visual inspection for label authenticity, date codes, and physical condition
- Functional power-on test with VersaMax Micro CPU
- High-speed counter channel verification at 10 kHz and 100 kHz test frequencies
- All relay output points exercised and verified
- Shipped in anti-static packaging with original documentation where available
We source from authorized distributors, factory-surplus channels, and verified industrial resellers. Traceability documentation available on request.
How to Source This Part
To place an order or request a quote for the GE IC220MDD840:
- Online: Add to cart directly on this page — stock levels are updated in real time.
- Email RFQ: Send your BOM or quantity requirements to support@konmask.com
- Phone / WhatsApp: +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Lead Time: In-stock units ship within 1–2 business days; ex-stock orders within 5–7 business days.
- MOQ: 1 unit. Volume pricing available for orders of 5+ units.
Application-Specific FAQ
Q: Can the IC220MDD840 read quadrature (A/B) encoders?
A: Yes. The high speed counter channel supports quadrature mode, allowing direction-aware counting for bidirectional motion applications.
Q: What is the maximum encoder frequency this module can handle?
A: The dedicated HSC channel supports up to 100 kHz input frequency, suitable for most industrial incremental encoders.
Q: Is this module compatible with the IC200 VersaMax Micro series?
A: The IC220MDD840 belongs to the IC220 (VersaMax Micro) family and connects directly to the VersaMax Micro local I/O bus. It is not directly interchangeable with IC200 series modules without a compatible base unit.
Q: Can I use this module as a standalone discrete I/O module without the HSC function?
A: Yes. The 8 DC inputs and 8 relay outputs operate independently of the high speed counter channel and can be used for standard discrete I/O tasks.
Q: Do you provide a warranty?
A: Yes. Konmask.com provides a 90-day functional warranty on all modules. Extended warranty options are available — contact us for details.
Q: Can you supply a Certificate of Conformance (CoC)?
A: Yes, CoC and test reports are available upon request for orders of 3+ units.
