GE IC610MDL156 – Discrete Output Module | Series One PLC Platform
Engineering Background
The IC610MDL156 is a discrete output module designed for GE’s Series One programmable logic controller (PLC) family — one of GE’s foundational industrial automation platforms widely deployed across North American manufacturing, utilities, and process industries from the 1980s through the 2000s. This module provides the critical interface between the PLC’s logic processor and field-level actuators, solenoids, motor starters, and indicator devices.
Product Positioning
Targeted at maintenance engineers, MRO procurement teams, and system integrators responsible for sustaining legacy Series One PLC installations, the IC610MDL156 delivers a direct, drop-in replacement solution without requiring controller reprogramming or rack redesign. Konmask.com stocks verified units sourced from controlled supply chains to support unplanned downtime recovery and planned lifecycle extension projects.
Complete Technical Specifications
- Part Number / SKU: IC610MDL156
- Manufacturer: GE (General Electric) — Automation & Controls Division
- Series / Platform: Series One PLC
- Module Type: Discrete Output Module
- Output Type: Relay / Solid-State (confirm with datasheet for specific variant)
- Number of Output Points: Per GE Series One I/O specification
- Operating Voltage: Per field wiring requirements (AC/DC as rated)
- Backplane Interface: GE Series One I/O rack compatible
- Weight: 1,130 g (approx.)
- Country of Origin: United States
- Compliance: UL listed; CE marking per applicable directives
Proven Application Environments
- Discrete manufacturing lines (automotive, metal fabrication, assembly)
- Water and wastewater treatment facilities
- Oil & gas upstream and midstream control panels
- Pulp and paper process control systems
- Building automation and HVAC control panels
- Legacy MRO replacement for Series One rack-based systems
Engineering Advantages
- Direct Drop-In Compatibility: Fits existing Series One I/O racks without hardware modification
- Zero Reprogramming Required: Maintains existing ladder logic and I/O addressing
- Robust Output Isolation: Protects PLC backplane from field-side transients and surges
- Proven Field Reliability: Thousands of units in continuous industrial service globally
- Immediate Availability: In-stock at Konmask.com for same-day or next-day dispatch
System Architecture & Signal Flow
The IC610MDL156 interfaces directly with the GE Series One CPU or remote I/O scanner via the standard Series One backplane bus. Output commands issued by the PLC program are latched in the module’s output register and drive the corresponding field output circuits. Each output channel is individually fused or protected, and status LEDs provide real-time field-side indication for rapid fault diagnosis without test equipment.
Signal Flow: PLC CPU → Backplane Bus → IC610MDL156 Output Register → Output Driver Circuit → Field Device (Solenoid / Relay / Indicator)
Sourcing & Quality Verification
- All units inspected for physical integrity: connector pins, housing, label legibility
- Functional power-on verification performed prior to shipment
- Sourced from decommissioned industrial sites, authorized distributors, and OEM surplus — never counterfeit channels
- Serialized tracking maintained for full traceability
- 90-day warranty against defects in materials and workmanship
Procurement Process
- Confirm Part Number: Verify IC610MDL156 against your existing rack label or GE Series One BOM
- Request Quote: Contact support@konmask.com with quantity and delivery requirements
- Order Placement: Purchase order, credit card, or wire transfer accepted
- Dispatch: Ships within 1–2 business days from Hong Kong warehouse
- Documentation: Commercial invoice, packing list, and test report provided on request
Technical FAQ
Q: Is the IC610MDL156 compatible with GE Series One Plus or Series Six racks?
A: The IC610MDL156 is designed for the GE Series One rack form factor. Compatibility with Series One Plus or Series Six requires physical and electrical verification — contact our engineers before ordering.
Q: Can I mix IC610MDL156 with other Series One I/O modules in the same rack?
A: Yes. Series One I/O modules are slot-addressable and can be mixed within the same rack, subject to power budget constraints.
Q: Do you provide a test report or certificate of conformance?
A: Yes. A functional test report is available upon request at no additional charge.
Q: What is the lead time for bulk orders (>5 units)?
A: Bulk availability varies by stock level. Contact us for a real-time inventory check and volume pricing.
Q: Can Konmask.com assist with full Series One system sourcing?
A: Yes. We specialize in complete legacy PLC system sourcing including CPUs, power supplies, I/O modules, and programming cables.
